DURABILITY • POWER • PERFORMANCE
EV E N HEAT ™
B A R BE CU E
S M A L L S PA C E S
ASSEMBLY MANUAL
85-3046-2 (G35301) Propane
85-3047-0 (G35302) Natural Gas
LIMITED 5-YEAR WARRANTY
Read and save manual for future reference.
Assemble your grill immediately. Missing or damaged parts
should be claimed within 30 days of purchase.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-800-275-4617.
www.colemanbbqs.com
Manual Revision #: 04252011 PD
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Coleman 85-3046-2 (G35301) Propane
Summary of Contents for Coleman 85-3046-2 (G35301) Propane
- Page 1 EV E N HEAT ™ B A R BE CU E S M A L L S PA C E S ASSEMBLY MANUAL 85-3046-2 (G35301) Propane 85-3047-0 (G35302) Natural Gas LIMITED 5-YEAR WARRANTY Read and save manual for future reference.
-
Page 2: Hardware Pack
HARDWARE PACK TOOLS NEEDED FOR ASSEMBLY No. Description Part Number Qty. ¼”-20UNCX38 Screw 20120-13038-250 • #2 Phillips screwdriver (long and short) ¼”-20UNCX16 Screw 20120-13016-250 • ¼” Slotted screwdriver (long and short) ø7 Lock Washer 41400-07000-250 • Adjustable wrench ø7 Washer 40300-07000-250 1/4”-20UNC Nut 30220-13000-250... - Page 3 Door assembly G353-7000-01 Carryover assembly G353-0005-01 Door handle G415-0001-02 Even Heat™ heat distribution G522-0072-01 Bottom shelf-LP G353-0500-01 plate Locking castor G350-0023-01 Coleman® signature cooking G522-0023-01 Castor G350-0024-01 grate Door magnet assembly G501-00F2-02 Warming rack G350-0009-01 Match holder G608-0019-01 Hardware pack G353-B001-01...
- Page 4 Even Heat™ burners G522-4900-01 Right side panel G353-0400-01 Carryover assembly G353-0005-01 Door assembly G353-7000-01 Even Heat™ heat distribution G522-0072-01 plate Door handle G415-0001-02 Coleman® signature cooking G522-0023-01 Bottom shelf-NG G353-0800-01 grate Locking castor G350-0023-01 Warming rack G350-0009-01 Castor G350-0024-01 Match holder G608-0019-01...
-
Page 5: You Will Need
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Separate the 2 different types of castors: Attach the front brace (CG) to the left 2 locking castors (EF) and 2 regular and right cart side panels (EA & EB). castors (EG). The top of the front brace (CG) can be To tighten casters insert the Pin (#11) identified by two clips located on the top into one of the Regular Castors (EF), as... - Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS THIS STEP REQUIRES 3 PEOPLE. DO Assemble the left and right tracks NOT ATTEMPT ALONE. EXTREMELY (CL and CM) for the Quick Clean™ HEAVY! grease tray (CH), as shown in figure A, B and C. a. Position the top lid assembly and burner box assembly (A &...
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Assemble the door support rail (CN) to Left and Right side shelf assembly the left and right upper side panels (EA and EB), as shown. a. Assemble the side shelf support bracket A (DA-front) and side shelf WARNING: This part may have sharp support bracket B (DB- back) to the edges.
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Electronic Ignition Assembly a. Assemble the door assembly (EC), to the bottom shelf (EE) by inserting the a. Remove the ignition battery cover fixed pin (bottom of door) into the (CC2) and the plastic nut from the hole provided (figure B).
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS FOR PROPANE MODEL ONLY a. Position the Quick Clean™ grease tray (CH) onto the right and left tracks (CL For natural gas model, follow step 15. and CM), as shown. Attach the regulator (CB) coupling nut b.
-
Page 10: Additional Warnings
ADDITIONAL WARNINGS You have now completed the Assembly of your COLEMAN® EVEN HEAT™ BARBECUE. NEXT STEPS: 1. Position your BARBECUE 2. Read SAFE USE CARE MANUAL 3. Perform Grill Safety Check-list WARNING HOT SURFACES: WARNING: FOR YOUR FAMILIES SAFETY, DO NOT ATTEMPT TO LIGHT...
