9

Function

Pos: 40 /Beko Technische Dokumentation/Funktion/BEKOMAT/BM Ableitfunktion @ 0\mod_1183618031702_2901.docx @ 4032 @ @ 1
1 2
Pos: 41 /Beko Technische Dokumentation/Funktion/BEKOMAT/BM 32U/33U LED-Taster-Funktion @ 4\mod_1354691493582_2901.docx @ 29040 @ @ 1
BEKOMAT® 33U / 33U CO
3
Via the inlet line (1) the condensate flows into
the BEKOMAT ® 33U / 33U CO and accumulates
in the housing (2).
A capacitively functioning sensor (3) continuously
registers the filling level and relays a signal to the
electronic control as soon as the container is filled.
4
The pilot valve (4) is activated and the membrane (5)
opens the outlet line to discharge the condensate (6).
5
When the BEKOMAT
the outlet line is reclosed tightly in time before
6 unnecessary compressed-air losses occur.
Function
®
33U / 33U CO is empty,
11
