Product Specifications; General Information - Sharp R-220EW Service Manual

R - 2 2 0 E W
R - 2 3 0 E K
R - 2 3 0 E W
ITEM
Power Requirements
Power Consumption
Power Output
Case Dimensions
Cooking Cavity Dimensions
(0.8 Cubic feet)
Control Complement
Oven Cavity Light
Safety Standard
This oven is equipped with a three prong grounding plug. It must be plugged into a wall receptacle that is properly installed
and grounded in accordance with the National Electrical Code and local codes and ordinances.
In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the
electric current.
WARNING: Improper use of the grounding plug can result in a risk of electric shock.
Electrical Requirements
The electrical requirements are a 115 -120 volt 60 Hz, AC only,
PRODUCT DESCRIPTION
SPECIFICATIONS
120 Volts
60 Hertz
Single phase, 3 wire grounded
1200W / Approx. 10.2 Amperes
800 W nominal of RF microwave energy (IEC Test procedure)
Operating frequency 2450 MHz
Width 18-1/8"
Height 11-3/8"
Depth 14-5/8"
Width 12-3/8"
Height 8-3/8"
Depth 13"
Touch Control System
Clock (1:00 - 12:59)
Timer (0 - 99 minutes 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
P-HI ................................... Full power throughout the cooking time
P-90 .................................................... approx. 90% of FULL Power
P-80 .................................................... approx. 80% of FULL Power
P-70 .................................................... approx. 70% of FULL Power
P-60 .................................................... approx. 60% of FULL Power
P-50 .................................................... approx. 50% of FULL Power
P-40 .................................................... approx. 40% of FULL Power
P-30 .................................................... approx. 30% of FULL Power
P-20 .................................................... approx. 20% of FULL Power
P-10 .................................................... approx. 10% of FULL Power
P-0 ...................................... No power throughout the cooking time
POPCORN pad, MINUTE PLUS pad
REHEAT CENTER pad, Instant Start pads
EXPRESS DEFROST pad [R-220EW], COMPU DEFROST pad [R-230EK/W]
Number selection pads, CLOCK pad
KITCHEN TIMER pad, POWER LEVEL pad
STOP/CLEAR pad, START pad
Yes
UL Listed.
FCC Authorized
DHHS RUles, CFR, Title 21, Chapter 1, Subchapter J

GENERAL INFORMATION

GROUNDING INSTRUCTIONS
4
DESCRIPTION
