OWNER'S MANUAL & INSTALLATION GUIDE
ClearPlus™ Premium Series Tannin & Organics Filters
APPLICABLE MODELS: CPT-5810SXT Series
PLEASE READ THIS MANUAL CAREFULLY BEFORE
ATTEMPTING INSTALLATION. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY AFFECT THE PERFORMANCE OF YOUR
SYSTEM, VOID YOUR WARRANTY, AND RESULT IN
PROPERTY DAMAGE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ClearPlus Premium Series and is the answer not in the manual?

Questions and answers

Related Manuals for Home Plus ClearPlus Premium Series

Summary of Contents for Home Plus ClearPlus Premium Series

  • Page 1 OWNER’S MANUAL & INSTALLATION GUIDE ClearPlus™ Premium Series Tannin & Organics Filters APPLICABLE MODELS: CPT-5810SXT Series PLEASE READ THIS MANUAL CAREFULLY BEFORE ATTEMPTING INSTALLATION. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY AFFECT THE PERFORMANCE OF YOUR SYSTEM, VOID YOUR WARRANTY, AND RESULT IN PROPERTY DAMAGE.
  • Page 2 Congratulations on the purchase of your ClearPlus™ Premium Series tannin and organics filter. You have purchased one of the finest water treatment systems on the market today. This manual is designed to provide owners, installers, and service technicians with detailed information about the installation, start-up, and operation of your new water treatment system.

  • Page 3: Table Of Contents

    Table of Contents: GENERAL WARNINGS ……………………………………………………………………………………………...….. …….. OPERATING CONDITIONS …………………………………………………………………………………………….…... INSTALLATION ………………………………………………………………………………………………………….…..…..….. Step 1 – Pre-Installation Inspection ……………………………………………………………..……… Step 2 – Selecting an Installation Location ………………………………………………..…..Step 3 – Prepare Treatment Tank ………………………………………………………………..……… Step 4 – Turn off the Water & Electric Water Heaters ………………………………….… Step 5 –...

  • Page 4: General Warnings

    GENERAL WARNINGS Do not allow children or pets to play on or around the water filter. Do not install or store this filter system where it will be exposed to freezing temperatures. Do not tamper with controls. Do not repair, replace, or attempt to service any part of the system unless specifically instructed to in this manual and you have the understanding, tools, and skills necessary to carry out the procedure.

  • Page 5: Operating Conditions

    OPERATING CONDITIONS The following chart provides guidance on the conditions required for successful operation of your ClearPlus™ system. USE OF THIS EQUIPMENT OUTSIDE OF THESE OPERATING CONDITIONS MAY ADVERSELY AFFECT THE PERFORMANCE OF YOUR SYSTEM, RESULT IN SYSTEM DAMAGE INCLUDING WATER LEAKS AND CORRESPONDING PROPERTY DAMAGE, AND MAY VOID YOUR WARRANTY.
  • Page 6 ClearPlus™ 5810SXT Series Tannin & Organics Filter, Specifications Flow Rates & Backwash Requirements: Model 9-48 10-54 12-52 13-54 14-65 Lbs of Salt Per Regeneration @ dose of 10 lbs/CF: Resin Volume 0.75 1.25 (Cubic Feet): Neutralizing Media Volume 0.25 0.25 (Cubic Feet): Total Media Volume (Cubic Feet):...

  • Page 7: Installation

    INSTALLATION WE RECOMMEND THAT YOU READ THIS ENTIRE MANUAL BEFORE STARTING THE ACTUAL INSTALLATION. WHILE WE STRONGLY RECOMMEND THAT A LICENSED PLUMBER PERFORM ALL INSTALLATION WORK, A MECHANICALLY-INCLINED HOMEOWNER WITH SUITABLE PLUMBING KNOWLEDGE CAN INSTALL THIS SYSTEM. IN ALL CASES, IT IS CRITICAL THAT THE INSTALLATION BE DONE IN ACCORDANCE WITH THESE INSTRUCTIONS AND ALL APPLICABLE PLUMBING AND ELECTRICAL CODES.

  • Page 8: Step 2 - Selecting An Installation Location

    Step 2. – Selecting an Installation Location While exterior installation in warm climate areas is possible, we strongly recommend interior installation only. The system cannot be allowed to freeze or severe system damage could occur. The system should not be exposed to rain and it should not be installed in direct sunlight, as long-term exposure to UV light could damage components of the system.
  • Page 9 IF YOU HAVE OTHER WATER TREATMENT EQUIPMENT, YOU SHOULD DISCUSS THE ORDER OF YOUR TREATMENT EQUIPMENT WITH YOUR DEALER PRIOR TO INSTALLATION. Select a location for installation of your water filter that is within close proximity to the main incoming water line of the home. The location should have a firm, level surface with enough space for the unit itself including the brine tank and sufficient space surrounding the unit to facilitate maintenance.

  • Page 10: Step 3 - Prepare Treatment Tank

    You will also need access to a standard, non-switched, grounded 120 volt (60 Hz) electrical outlet. An extension cord may be used to reach a suitable electrical outlet. If this option is used, ensure that the extension cord is UL/CSA certified and of an appropriate wire gauge for the application.
  • Page 11 For the following steps, we recommend that you wear a dust mask. Take the bag/box of gravel and, using a small scoop, add the gravel to the tank through the funnel to completely cover the lower distributor. Use all of the gravel. Be sure to provide some downward pressure on the riser tube while adding the gravel to ensure that the distributor does not shift out of its recess or rise up.

  • Page 12: Step 4 - Turn Off The Water & Electric Water Heaters

    Attach the upper screen to the underside of the control valve. Be sure to twist clockwise and lock it into place. Apply a small amount of lubricant to the top inch of the outside of the riser tube and to the tank o-ring seal. Note: Only use food-grade silicone lubricant.

  • Page 13: Step 5 - Prepare And Install Inlet And Outlet Plumbing Connection

    Step 5. – Prepare and Install Inlet and Outlet Plumbing Connections TEFLON® TAPE IS THE ONLY SEALANT TO BE USED ON THE 1” NPT CONNECTOR YOKES AND DRAIN FITTINGS. IF YOU WISH TO USE COPPER PIPING FOR YOUR INSTALLATION AND WILL BE SOLDERING THE JOINTS, DO NOT APPLY HEAT NEAR YOUR CONTROL VALVE, BYPASS ASSEMBLY, 1”...
  • Page 14 flow and attach the bypass valve to the control valve. The in and out arrows on the bypass should be pointing the same direction as the in and out arrows on the outside of the control valve. BE VERY CAREFUL TO MAKE SURE YOU PLUMB THE SYSTEM IN THE RIGHT DIRECTION. The bypass assembly is secured to the control valve using threaded fittings.

  • Page 15: Step 6 - Drain Line Installation

    Place the bypass in the “bypass” position as pictured above. Step 6. – Drain Line Installation NOTE: NEVER CONNECT THE DRAIN LINE DIRECTLY INTO A DRAIN. ALLOW AN AIR-GAP OF A MINIMUM OF 1 INCH (CHECK LOCAL CODES) BETWEEN THE DRAIN LINE AND WASTE LINE TO PREVENT THE POSSIBILITY OF BACK-SIPHONING.

  • Page 16: Step 7 - Brine Tank Connections

    the fitting first to make sure you line up the drain line properly with the drain port on the control valve if you are using rigid pipe. Re-insert the DLFC into the control valve and securely lock into place with the retaining clip when done.
  • Page 17 1. Make sure that the end of the brine tubing is cut square and that the tubing coating is smooth, unmarred, and undamaged. 2. Slide the GFN compression nut onto the end of the brine tubing with the open end facing the end of the tubing.

  • Page 18: Step 8 - Connect The Brine Tank Overflow To Drain

    If you have an excessive length of brine line, you should trim it to a more appropriate length first. The brine tubing should be as short and straight as possible. Make sure that the end of the brine tubing is cut square and that the tubing coating is smooth, unmarred, and undamaged.

  • Page 19: Step 9 - Control Valve Set-Up

    Step 9 – Control Valve Set-up During cold weather, the control valve should be warmed to room temperature before operating. Note: All electrical connections must be done according to local codes. Plug the control valve into a standard, grounded 120 volt (60 Hz) electrical outlet. Be certain that the outlet is uninterrupted and not controlled by a switch.

  • Page 20: Step 10 - Initial Start-Up And Leak Testing

    The digital display should be alternating between the current time setting (which is probably incorrect), and the number of gallons remaining until the next regeneration cycle. You will also see the “service” icon which appears as a small faucet in the bottom left corner of the display window.
  • Page 21 Once you add salt, the brine tank will be difficult to move, so it is important that it be located in the desired location now. Do not add salt yet! Position the brine tank in its permanent location and add water to it until the water level is roughly 4 inches above the top of the salt grid.
  • Page 22 Once you have confirmed that you have a proper brine draw and you have waited at least 15 minutes, press the EXTRA CYCLE button to advance to the RAPID RINSE (“RR”) cycle. Allow this cycle to run for its full duration. When the RAPID RINSE (“RR”) cycle is complete, the control valve will enter the BRINE FILL (“BF”) cycle.

  • Page 23: Regeneration

    REGENERATION Tannin and organics filters remove the minerals responsible for hard water through a process called ion exchange. The resin attracts negatively charged tannin and organic ions. These contaminants cling to the resin and are removed from the water stream. As the resin becomes saturated with contaminants over time, the system is designed to perform an automatic a self-cleaning process called regeneration on a periodic basis.
  • Page 24 Please consult your dealer for advice if you would like to re-configure your system at a high capacity and salt dose. Be aware that such changes will result in a less efficient water ssystem and higher salt consumption. During each step of regeneration, the digital display on the control valve will indicate the cycle currently underway and the amount of time remaining in that cycle.

  • Page 25: Salt

    During the regeneration process, you can advance to the next step by pressing the EXTRA CYCLE button. The control valve will continue to keep time and the passage of days for a minimum of 48 hours in the event of power failure. SALT You must keep salt in the brine tank.

  • Page 26: Changing Time Of Day

    Salt Bridging It is sometimes possible for the salt pellets to wedge against each other and fail to fall into the water at the bottom of the brine tank. This is called bridging and it will prevent the formation of an effective brine solution. The system will try to regenerate but will not properly recondition the resin.
  • Page 27 display is 12:01PM, you cannot enter the User Programming Mode – simply wait a minute before attempting. DAYS OVERRIDE The display will first show the DAYS OVERRIDE (parameter display code DO). This is the setting that determines the minimum frequency of backwash (measured in days). For systems used on city water supplies, this parameter is normally set at 14 days.
  • Page 28 FEED WATER “HARDNESS” The display will now show the FEED WATER HARDNESS (parameter display code H). Since tannin filter control valves are more commonly used for use with water softeners, the programming is based on hardness instead of your tannin or Total Organic Carbon Level (TOC).

  • Page 29: Master Programming Mode

    The system should now return to normal service mode. The unit will also return to normal operation after 5 seconds if no buttons are pressed. MASTER PROGRAMMING MODE THE MASTER PROGRAMMING MODE IS DESIGNED FOR PROFESSIONAL USE ONLY. UNLESS DIRECTED BY A WATER TREATMENT PROFESSIONAL FAMILIAR WITH THE SYSTEM, IT IS STRONGLY RECOMMENDED THAT YOU DO NOT MODIFY ANY OF THE MASTER PROGRAMMING MODE SETTINGS To enter the Master Programming Mode, first set the time of day to 12:01PM.

  • Page 30: Resets

    Reserve Selection Percentage Safety Factor Safety Factor Day Override See User Programming Mode Above Regeneration Time 12:30 12:30am Backwash 10 minutes Brine Draw/Slow Rinse 60 Minutes Rapid Rinse 6 minutes Brine Fill See Below* Flow Meter Type t1.2 1 1/4" Turbine Relay Relay * the brine fill cycle time is dependent upon your system size and is based on salt dose of 10...

  • Page 31: Operation During A Power Failure

    OPERATION DURING A POWER FAILURE The 5810SXT valve/controller includes integral power backup. In the event of power failure, the control shifts into a power-saving mode. The display and motor shut down, but it continues to keep track of the time and day for a minimum of 48 hours. The system configuration settings are stored in a non-volatile memory and are stored indefinitely with or without line power.

  • Page 32: Maintenance & Troubleshooting

    MAINTENANCE & TROUBLESHOOTING THE CONTROLLER MUST BE DEPRESSURIZED BEFORE REMOVING ANY QUICK CONNECTION CLIPS OR THE VALVE ITSELF FOR SERVICING. THE CONNECTOR SHOULD BE PUSHED TOWARD THE CONTROL VALVE WHILE REMOVING CLIPS. Service Recommendations It is imperative that the salt level in your brine tank be kept at the correct level. See “Regeneration”...
  • Page 33 and inspect seals and spacers and/or piston for damage. 5. Cloudy water and/or poor A. Additional backwash A. Perform 1 or more additional water pressure after initial required. manual backwash cycles. installation. 6. Continuous colored water at A. No salt A.
  • Page 34 dealer. D. Inspect brine tubbing for kinks or blockages, check brine tube connections for air leak, & check brine line flow control for blockage. 9. System regenerated at A. Power failure A. Reprogram correct time into unexpected time of day. controller.

  • Page 35: Warranty Information

    a manual regeneration. If the error re-occurs, unplug the unit and contact technical support. WARRANTY INFORMATION ClearPlus™ systems are backed by a comprehensive warranty program. The Fleck 5810SXT control valve and related bypass assembly and media tank are manufactured by Pentair LLC and are subject to Pentair LLC’s Limited Warranty. See Pentair’s Limited Warranty for details.
  • Page 36 Only products purchased from an Authorized Dealer or HomePlus Products Inc. directly are eligible for this warranty. The products must have been installed and operated in accordance with the instructions and operating conditions stated in the Owner's Manual. Customer must register his or her warranty with HomePlus products Inc. within 90 days of original purchase for the warranty to remain valid.
  • Page 37 damages (including, but not limited to, property damage or loss, loss of incomes, or loss of use damages) arising out of the manufacture, sale, or supplying of the products, even if HomePlus Products Inc. has been advised of the possibility of such damages or losses. These warranties are governed by the laws of the Province of British Columbia, Canada, and may change without notice.
