TRENDnet TEW-610APB Quick Installation Manual

TRENDnet TEW-610APB Quick Installation Manual

108mbps 802.11g mimo wireless access point
Hide thumbs Also See for TEW-610APB:

Advertisement

Table of Contents

See also: User Manual
TEW-610APB
Quick Installation Guide
Version 8.19.2005
TRENDnet
TRENDware, USA
What's Next in Networking
Copyright ©200 .
5 All Rights Reserved.
TRENDware International, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEW-610APB and is the answer not in the manual?

Questions and answers

Related Manuals for TRENDnet TEW-610APB

Summary of Contents for TRENDnet TEW-610APB

  • Page 1 TEW-610APB Quick Installation Guide Version 8.19.2005 TRENDnet TRENDware, USA What's Next in Networking Copyright ©200 . 5 All Rights Reserved. TRENDware International, Inc.

  • Page 2: Table Of Contents

    Table of Contents English ... 1. Prepare for Installation ... 2. Install Hardware ... 3. Configure TCP/IP Settings ... 4. Configure the Access Point ... 5. Configure your Wireless Network Adapter ... Troubleshooting...

  • Page 3: English

    English QIG 1. Prepare for Installation Thank you for purchasing TRENDnet's TEW-610APB 108Mbps 802.11g MIMO Wireless Access Point. This guide will help you set-up your Access Point quickly and easily. Just follow the step-by-step instructions below, and enjoy the benefits of accessing the Internet/network without ever being tied down to wires! If you run into problems, please refer to the Troubleshooting section.

  • Page 4: Install Hardware

    NOTE: If you are using a wired computer to configure the Access Point, please connect this computer to the same Switch or Hub the TEW-610APB is connected to. Verify Hardware Installation Make sure the front panel lights are on: Power, LAN, MIMO.

  • Page 5: Configure Tcp/Ip Settings

    3. Configure TCP/IP Settings Before the Access Point can be accessed and configured, the computer's TCP/IP settings need to be changed. (That includes your wireless card's IP address, too.) Windows 2000/XP 1. Find the Start button located on the Desktop. 2.
  • Page 6 6. Click on Use the following IP address. Enter 192.168.0.50 for IP address and 255.255.255.0 for Subnet, and click OK. 7. Click OK. 8. Your computer is now ready to access and configure the Access Point. English...

  • Page 7: Configure The Access Point

    4. Configure the Access Point From a Wired Computer Open a web browser (Internet Explorer or Netscape) and enter http://192.168.0.100 at the address bar, then press the Enter key. Type admin for username, and type admin for your password. Click OK. 2.

  • Page 8: Configure Your Wireless Network Adapter

    5. Configure your Wireless Network Adapter In this example, the TEW-601PC Wireless Utility will connect to the TEW-610APB. 1. Double-click the wireless computer icon in your system tray (next to the clock in the bottom right corner of your screen).

  • Page 9: Troubleshooting

    I specified the IP address http://192.168.0.100 in my Internet browser's address bar, but error message says "The page cannot be displayed". How can I get into the TEW-610APB's web configuration page? Please check your hardware and TCP/IP settings again by following the instructions sections 1~3, make sure the Power, LAN, MIMO on the Access Point's front panel are on and the TCP/IP configurations are correct.
  • Page 10 TRENDnet TRENDware, USA What's Next in Networking Product Warranty Registration Please take a moment to register your product online. Go to TRENDware’s website at http://www.TRENDNET.com TRENDnet Technical Support US/Canada Support Center Contact Telephone: 1(310) 626-6252 Fax: 1(310) 626-6267 Email: support@trendnet.com...
