TASKING iSYSTEM ST SPC58 Hardware User Manual page 14

P2: Power supply configuration
Emulation Adapter Power supply is configured via the unshrouded 26-pin 2.54 mm header (P2).
Signal direction
Target
Target TVDD_HV_ADR_S
Target
Target
Target TVDD_HV_IO_MAIN
Target TVDD_HV_IO_ETH
Target TVDD_HV_IO_EMMC
Not connected
Not connected
Not connected
Ground
Ground
Ground
Refer to the microcontroller user's manual for more details which power supply designation in
the above table belongs to which power supply.
By default, all jumpers are set and connect target power supply coming from the target to the
microcontroller residing on the Emulation Adapter. In principle, pins 1-2, 3-4, 5-6, 7-8, 9-10, 11-12
and 13-14 must be bridged only but for the convenience and ease of use all jumpers are set, ex-
cept for pins 25-26. Pin 26 is the polarizer key preventing incorrect connection of the IEA-PS
power supply, when being connected.
If a different power source is to be used (e.g., in case of a standalone operation), all jumpers
must be removed and power source must be applied to:
·
VDD_HV_OSC (pin 2),
·
VDD_HV_ADR_S (pin 4),
·
VDD_HV_ADV_S (pin 6),
·
VDD_HV_FLA (pin 8),
The Emulation Adapter comes delivered together with the IEA-PS emulation adapter power sup-
ply, which simply plugs into the P2 header row, providing the necessary power supply for Emula-
tion Adapter standalone operation. Double check that the power supply is configured properly
for this particular Emulation Adapter.
Signal
TVDD_HV_OSC
VDD_HV_ADV_S
TVDD_HV_FLA
NC
NC
NC
GND
GND
GND
P2 Signal description
Pin Pin
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
·
VDD_HV_IO_MAIN (pin 10),
·
VDD_HV_IO_ETH (pin 12),
·
VDD_HV_IO_EMMC (pin 14),
·
GND (pins 22, 24, 26) signals.
Signal Signal direction
VDD_HV_OSC Emulation device
VDD_HV_ADR_S Emulation device
VDD_HV_ADV_S Emulation device
VDD_HV_FLA Emulation device
VDD_HV_IO_MAIN Emulation device
VDD_HV_IO_ETH Emulation device
VDD_HV_IO_EMMC Emulation device
NC Not connected
NC Not connected
NC Not connected
GND
GND
KEY
Ground
Ground
