BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on your purchase of this SPECTRUM
are sure to experience years of reliable operation from this equipment. To ensure best results, it is important that you read and follow the
instructions in this manual carefully. It is important to keep these instructions in a safe place for future reference.
GAS COUNTERTOP EQUIPMENT,
NATURAL / LP
Operating Instruction Manual
NGCB-24R
Total
Pressure
Orifice
BTU/HR
IN. W.C
Size
70,000
Nat #36
105,000
4" / 10"
LP #49
140,000
Charbroiler. When used as intended, and with proper care and maintenance, you
TM
CHARBROILERS
Optional Accessories
NGCB-P11-2/3/4
NGCB-36R
NGCB-P11-2
NGCB-P11-3
NGCB-P11-4
NGCB-P7
Overall Dimensions
Length
Depth*
Height
24"
(609.6mm)
36"
29-1/8"
15-1/4"
(914.4mm)
(739.7mm)
(386.1mm)
48"
(1219.2mm)
NGCB-36R
NGCB-P7
24"Briquette Rock Kit
36"Briquette Rock Kit
48"Briquette Rock Kit
Replacement Briquettes (24/bag)
Grate Surface
Weight
Length
Depth
24"
104 lbs
(609.6mm)
(52 kg)
36"
20"
144 lbs
(914.4mm)
(510mm)
(71 kg)
48"
211 lbs
(1219.2mm)
(104 kg)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winco Spectrum NGCB-24R
Summary of Contents for Winco Spectrum NGCB-24R
-
Page 1: Specifications
GAS COUNTERTOP EQUIPMENT, CHARBROILERS NATURAL / LP Operating Instruction Manual NGCB-24R NGCB-36R Optional Accessories NGCB-P11-2/3/4 NGCB-P7 NGCB-36R NGCB-P11-2 24"Briquette Rock Kit NGCB-P11-3 36"Briquette Rock Kit NGCB-P11-4 48"Briquette Rock Kit NGCB-P7 Replacement Briquettes (24/bag) SANITATION Overall Dimensions Grate Surface BTU/ Total Pressure Orifice Model... -
Page 2: Warnings
GAS CHARBROILER Important For Future Reference Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or parts, this information is required. Model Number Serial Number Date Purchased WARNING: For your safety, do not store or use gasoline AVERTISSEMENT: Pour votre sécurité, ne pas stocker ni or other flammable vapors or liquids in the vicinity of utiliser d'essence ou d'autres vapeurs ou liquides... -
Page 3: Table Of Contents
If you have questions concerning the installation, operation, maintenance or LOCATION OF DATA PLATE service of this product, please contact WINCO®. The data plate is located on the rear or side panel. IMMEDIATELY INSPECT FOR SHIPPING DAMAGE All containers should be examined for damage before and during unloading. -
Page 4: Safety Precautions
Safety Precautions DANGER: This symbol warns of imminent hazard which Risque: Ce symbole avertit du danger imminent qui peut will result in serious injury or death. entraîner des blessures graves ou la mort. WARNING: This symbol refers to a potential hazard AVERTISSEMENT: Ce symbole indique un danger potentiel or unsafe practice, which could result in serious injury ou une pratique dangereuse, qui peut entraîner des... -
Page 5: Installation
Installation These instructions should be followed at all times. Failure to follow these Leg Installation: instructions could result in injury to yourself and others. The Charbroiler must not be operated without the legs attached. INSTALLATION CODES AND STANDARDS 1. Install adjustable legs by screwing leg post into recess nut at each corner The Charbroiler must be installed in accordance with: of unit frame. - Page 6 Gas Connection: WARNING 1. The data plate on rear or side of the Charbroiler indicates the type of gas DO NOT use an open flame to check for leaks. Check all gas piping the unit is equipped to burn. DO NOT connect to any other gas type. for leaks with a soap and water solution before operating unit.
-
Page 7: Conversion
Note Conversion PLEASE CHECK LEAKAGE BEFORE RE-INSTALLING CONTROL PANEL. These instructions are for the conversion from Natural Gas to Propane (L.P.) of Lighting Instructions the unit and kit provided. The conversion should be done before connecting the unit to the gas supply. LIGHTING PILOT WARNING The pilot light on the appliance has been set at the factory. -
Page 8: Safety
To clean burners, boil them in a strong solution of lye water for 15 to 20 minutes. Then either brush with a wire brush or clean If the machine is damaged, it must be repaired by a WINCO Approved gas ports with a sharp-pointed metal instrument to ensure open ports. -
Page 9: Troubleshooting
Parts protected by the manufacturer or its agent are not to be adjusted by the installer unless the installer is an authorized service agent. If you have any questions or problems DO NOT send unit to WINCO® without first contacting our customer service department. -
Page 10: Exploded Views
Exploded Views MODEL SHOWN: NGCB-SERIES 24" unit shown Internal External Cast Iron Grate Spare Parts List MODELS: NGCB-24R / NGCB-36R / NGCB-48R GAS GRIDDLE NGCB-24R NGCB-36R NGCB-48R GAS GRIDDLE NGCB-24R NGCB-36R NGCB-48R NO. DESCRIPTION PART # PART # PART # NO. -
Page 11: Briquette Rock Kit Assembly Instructions
Briquette Rock Kit Assembly Instructions NGCB-P11-2 / NGCB-P11-3 / NGCB-P11-4 1. Prepare front and rear hangers, briquettes, and cast iron racks. CONTENTS NGCP-P11-2 24” Charbroiler 5 Racks 40 Briquettes NGCP-P11-3 36” Charbroiler 8 Racks 64 Briquettes NGCP-P11-4 48” Charbroiler 11 Racks 88 Briquettes NGCB-P7 Replacement Briquettes... -
Page 12: Limited Warranty
This warranty is given only to the first purchaser from a retail dealer. No 4. Use of generic or after-market parts. warranty is given to subsequent transferees. 5. Repairs made by anyone other than a WINCO® designated service provider. Warranty does not cover product failures caused by: failure to maintain, 6. Lubrication.
