Hitachi Highly
Rollkolbenverdichter
Rotary Compressors
Spezifikation
Installation Manual
WHP09400PSV-C9EU
R 290
47,0 cm3/rev
220-240V/1/50Hz
RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY
Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de
Advertisement
Related Manuals for Ries Hitachi Highly WHP09400PSV-C9EU
Summary of Contents for Ries Hitachi Highly WHP09400PSV-C9EU
- Page 1 Hitachi Highly Rollkolbenverdichter Rotary Compressors Spezifikation Installation Manual WHP09400PSV-C9EU R 290 47,0 cm3/rev 220-240V/1/50Hz RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de...
-
Page 2: Application Range
Directory A: WHP09400PSV-C9EU Specifications —————1～4 Application range Compressor specifications Parts and drawings list General characteristics B: Heat pump water heater dedicated compressor use benchmark 5～12 1. System design restrictions 2. Process limit 3. other C: Acceptance ———————13 1. Acceptance basis 2. -
Page 3: Specification Of Compressor
SUBJECT Model WHP09400PSV-C9EU SPECIFICATION PAGE：1/25 1. SCOPE This specification is applied to SHANGHAI HITACHI Heat pump water heater compressor. SPECIFICATION OF COMPRESSOR 2.1 Model WHP09400PSV-C9EU 2.2 Rated Voltage/Frequency/Phase 220V～240V/50Hz/single 2.3 Application Heat pump water heater 2.4 Refrigerant R290 Forced air 2.5 Compressor Cooling 47.0ml/rev 2.6 Displacement... - Page 4 SUBJECT Model WHP09400PSV-C9EU SPECIFICATION PAGE：2/25 Heating capacity COP= Motor input 2.8 Allowable amount of refrigerant charge 1100 g 2.9 Amount of oil charge 875±20 ml(Initial) 2.10 Oil 5GSD-TB 2140 ml 2.11 Space volume of inner case 22.6 kg incl.oil 2.12 Net weight 1/4”quick connect type 2.13 Hermetic Terminal 2.14 Motor Type...
- Page 5 SUBJECT Model WHP09400PSV-C9EU SPECIFICATION PAGE：3/25 TABLE 1 Starting Conditions Spec Motor temperature Pressure Starting voltage MPa{kgf/ Cold-Starting Below 85% of rated voltage Cold state (room temperature) 1.027{9.44} Hot-Starting(Standard) Below 85% of rated voltage Hot state after operated under standard load condition 0.984{9.01} Hot-starting(Overload) Below 90% of...
- Page 6 SUBJECT Model WHP09400PSV-C9EU SPECIFICATION PAGE：4/25 3. PARTS AND DRAWING LIST Drawing code WHP09400PSV-C9EU Remarks Q’ty Dimensioned sketch Outline dwg. 4CYCH519 — Mounting accessories Rubber mount 4CYC00643 Bolt 4CYC00700 (M8) Electrical components Terminal cover 4CYC00987 4CYC00986 Sleeve Gasket 4CYC00102 3CYC00004 Rubber washer 4CYC00174 4CYC00124 Wiring diagram...
- Page 7 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：5/25 SYSTEM DESIGN LIMITATIONS 1.1 Power source and Voltage Voltage applied to hermetic terminal should be within the range mentioned in this specification. In the case of three phase, the phase imbalance should be within 3% among the compressor terminals.
- Page 8 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：6/25 There should be superheated gas returned to the compressor under all normal operating conditions. Table 2 Item Operating Envelope Discharge 2.59{25.39} MAX （see graph 1） pressure MPa{kgf/cm （condensing temperature 冷:70℃） 0.29~0.95 {1.94~8.67} Suction Pressure (Evaporation Temperature：-15℃~25℃)
- Page 9 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：7/25 -35 -30 -25 -20 -15 -10 E E E E v v v v a a a a p p p p o o o o r r r r a a a a t t t t i i i i n n n n g g g g t t t t e e e e m m m m p p p p e e e e r r r r a a a a t t t t u u u u r r r r e e e e ( ( ( ( ℃ ℃...
- Page 10 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：8/25 1.6 Temperature of Shell Bottom The Temperature of compressor shell Bottom must be 6 degrees higher than the corresponding saturated temperature of discharge pressure under normal operating conditions. 1.7 Avoid refrigerant migration The refrigerant migration to compressor shell should be avoided during the heat pump water heater system shut down periods, It’s suggested that the electric heating belt should be used around the shell bottom when necessary.
- Page 11 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：9/25 2.2 Prevent moisture from entering into the enclosed unit system. When the moisture entered into the unit, the refrigerant oil and the organic compound material presented in the hermetic motor will possibly decompose on the affecting of water . It will result in the capillary depositing and the reducing of insulation resistance.
- Page 12 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：10/25 Dry nitrogen should be charged in compressor before assembly of system. Welding should be finished within one minute after charge of nitrogen. Dry nitrogen needs to be charged again and weld if over one minute. Always purge the compressor with dry nitrogen during assembly of system .
- Page 13 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：11/25 The electric pulse should not be applied to the hermetic terminals when the compressor is under vacuum. The compressor should be kept in the clean place with low- moisture. The compressor must not be applied for transportation equipment, such as automobiles, trains, ships, and others.
- Page 14 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：12/25 3.13 The compressor should be kept out of the corrosive atmosphere such as in a chemicals storage, beside a hot spring and so on. 3.14 The lead wires should be connected to hermetic terminals without being touched on the surface of the compressor.
- Page 15 Check upon Delivery PAGE：13/25 1. Basis for Checking upon Delivery The Performance test will be carried out in accordance with this “compressor specification”. The Safety Performance in accordance with GB4706.1 Safety of household and similar electrical appliances General requirements and GB 4706.17 Safety of household and similar electrical appliances Particular requirements for motor-compressor.
- Page 16 14/25...
- Page 17 15/25 ·...
- Page 18 16/25...
- Page 19 17/25...
- Page 20 18/25...
- Page 21 19/25...
- Page 22 20/25...
- Page 23 21/25...
- Page 24 22/25...
- Page 25 23/25 （ （ （ （ 50Hz 220V） ） ） ） WHP09400PSV-C9EU Performance Curve Capacity （W）Q 18000 17000 （℃） 16000 15000 14000 13000 12000 11000 10000 9000 8000 7000 6000 5000 4000 3000 2000 1000 （°C） Evap. Temp. Motor input （W） 3200 （℃）...
- Page 26 24/25 Current （A） 18.00 （℃） 16.00 14.00 12.00 10.00 8.00 6.00 4.00 2.00 （°C） Evap. Temp. Flux （kg/h） （℃） （°C） Evap. Temp.
- Page 27 25/25 Specification Revision Record Page in Conclusion Date Revision Reason Spec Date...
