Hitachi Highly

Rollkolbenverdichter

Rotary Compressors

Spezifikation

Installation Manual

WHP15600VSDPC9EQ

R 410A- R 452B- R 454C - R 454B

42 cm3/rev

900 - 7200 min-1

DC / BLDC

RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY

Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de

10/19

Need help?

Do you have a question about the Hitachi Highly WHP15600VSDPC9EQ and is the answer not in the manual?

Questions and answers

Summary of Contents for Ries Hitachi Highly WHP15600VSDPC9EQ

Page 1 R 410A- R 452B- R 454C - R 454B 42 cm3/rev 900 - 7200 min-1 DC / BLDC RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de 10/19...
Page 2 Table of Contents ——————— 1～4 I.WHP15600VSDPC9EQ Specifications 1.Application area 2.Compressor specifications 3.Motor parameters 4.Parts and drawings list 5.General characteristics II.: Heat pump water heater dedicated 5 - 15 compressor reference III. Acceptance ----------———— 16 Acceptance basis Acceptance rules IV. the drawings ————————————...
Page 3 S U B J E C T PAGE：1/30 M o d e l W H P 1 5 6 0 0 V S D P C 9 E Q S P E C I F I C A T I O N SCOPE T h i s s p e c i f i c a t i o n i s a p p l i e d t o S H A N G H A I H I G H L Y H e a t pump water heater compressor.
Page 4 S U B J E C T M o d e l W H P 1 5 6 0 0 V S D P C 9 E Q S P E C I F I C A T I O N PAGE：2/30 *.COP= Heating capacity Motor input (W)
Page 5 S U B J E C T PAGE：3/30 S P E C I F I C A T I O N M o d e l W H P 1 5 6 0 0 V S D P C 9 E Q Inductance Ld（mH）...
Page 6: Parts Name
S U B J E C T PAGE：4/30 M o d e l W H P 1 5 6 0 0 V S D P C 9 E Q S P E C I F I C A T I O N PARTS AND DRAWING LIST PARTS NAME QTY/SET...
Page 7 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：5/30 COMPRESSOR CRITERIA 1 Strictly observe the specification The compressor should be used in specifications written in this “compressor specification”...
Page 8 PAGE：6/30 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A The oil should be continuously returning to the compressor to oil, and there should be no oil storage part in the refrigeration system construction.
Page 9 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：7/30 R410A R452B + R 454B - 3 5 - 3 0...
Page 10 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：8/30 8 Discharge pipe temperature Discharge pipe temperature is measured at a distance 300mm from the surface of compressor and should be less than 110℃.
Page 11 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：9/30 14 Impurities in refrigerating system （1）The weight of residue on the inside surface of the heat exchanger and tube should be less than 0.01g/m .
Page 12 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：10/30 Non-liquid compression sound, current increase, vibration increase, etc. occur. In order to prevent liquid compression, auxiliary reservoirs can be added or the amount of refrigerant enclosed can be reduced.
Page 13 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：11/30 23 Avoid refrigerant migration The refrigerant migration to compressor shell should be avoided during the heat pump water heatersystem shut down periods, It’s suggested that the electric heating belt should be used around the shell bottom when necessary.
Page 14 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：12/30 （6）The compressor can’t be used in the place with corrosive atmosphere such as hot spring and chemical warehouse.
Page 15 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：13/30 (14) SHEC will not take any responsibility against accident that is caused by the accessories equipped by yourselves.
Page 16 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：14/30 (21) Use the refrigerant of specified brand. When the refrigerant not specified used, it will possibly cause trouble of the performance and reliability of the compressor by the impurities in the refrigerant.
Page 17 H E A T P U M P W A T E R H E A T E R C O M P R E S S O R C R I T E R I A PAGE：15/30 （27）The fuse or/and breaker should be equipped in the main circuit. (28) The thickness of the refrigerating system using tube the tube thickness as followed External diameter(mm)
Page 18 C h e c k u p o n D e l i v e r y PAGE：16/30 1. Basis for Checking upon Delivery The Performance test will be carried out in accordance with this “compressor Specification”. The Safety Performance in accordance with GB4706.1 Safety of household and similar electrical appliances General requirements and GB 4706.17 Safety of household and similar electrical appliances Particular requirements for motor-compressor.
Page 19 17/30...
Page 20 18/30...
Page 21 .19/30...
Page 22 20/30...
Page 23 21/30...
Page 24 22/30...
Page 25 23/30...
Page 26 24/30...
Page 27 25/30...
Page 28 26/30...
Page 29 raph 1 （MPa） Pd limit Rotational speed (rpm) R410A R452B R454C 3.07 2.90 2.02 2000 4.76 4.49 3.47 5400 4.76 4.49 3.47 7200 3.51 3.32 2.31 27/30...
Page 30 28/30...
Page 31 CHART 3 Instructions for Inverter rotary compressor revolutions change 29/30...
Page 32 tsaug = to = tumg = tc = tu = Luftgeschwindigkeit 30/30...
Page 33 规格书修改经历 Specification Revision Record 序页码日期修订理由客户承认日期号 Page in Date Revision Reason Conclusion Date Spec...
