Hitachi Highly
Rollkolbenverdichter
Rotary Compressors
Spezifikation
Installation Manual
WHP01100PSV-H3EUN
RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY
Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de
Advertisement
Related Manuals for Ries Hitachi Highly WHP01100PSV-H3EUN
Summary of Contents for Ries Hitachi Highly WHP01100PSV-H3EUN
- Page 1 Hitachi Highly Rollkolbenverdichter Rotary Compressors Spezifikation Installation Manual WHP01100PSV-H3EUN RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de...
- Page 2 Table of Contents WHP01100PSV-H3EUN 1～4 First Specifications Applications Compressor Specifications Parts list and drawings General Characteristics Second, the dedicated compressor heat pump water heater using a reference 5-12 System design constraints Process limits other Third, acceptance Basis for acceptance Acceptance rules 14～22 Fourth, drawing Fifth, experience modification...
-
Page 3: Specification Of Compressor
SUBJECT Model WHP01100PSV-H3EUN SPECIFICATION PAGE：1/23 1. SCOPE This specification is applied to SHANGHAI HITACHI Heat pump water heater compressor. SPECIFICATION OF COMPRESSOR 2.1 Model WHP01100PSV-H3EUN 2.2 Rated Voltage/Frequency/Phase 220V～240V/50Hz/single Heat pump water heater 2.3 Application 2.4 Refrigerant R-290 2.5 Compressor Cooling Forced air 2.6 Displacement 5.86ml/rev... - Page 4 SUBJECT Model WHP01100PSV-H3EUN SPECIFICATION PAGE：2/23 Heating capacity COP= Motor input 2.8 Allowable amount of refrigerant charge 2.9 Amount of oil charge 150 g 152±5 ml(Initial) 2.10 Oil 5GSD-TB or equivalent 2.11 Space volume of inner case 380 ml 5.62 kg incl.oil 2.12 Net weight 2.13 Hermetic Terminal 1/4”quick connect type...
- Page 5 SUBJECT Model WHP01100PSV-H3EUN SPECIFICATION PAGE：3/23 (1) Starting voltage shown in Table 1. Starting Performance (2) Starting pressure level must be between the suction pressure and discharge pressure Scale, and the table to be adjusted. (3) in the starting condition, the ambient temperature of the compressor to be maintained at above 20 ℃.
- Page 6 SUBJECT Model WHP01100PSV-H3EUN SPECIFICATION PAGE：4/23 3. PARTS AND DRAWING LIST WHP01100PSV-H3EUN Drawing code Remarks Q’ty 4CYCA0096 Outline dwg. Dimensioned sketch — Wiring diagram 4CYC01069 — Electrical components Running capacitor 12µF-450V 4CYC00173 Terminal parts accessories Terminal cover 4CYC01067 Packing 4CYC01068 Flange nut SC01D430 Rubber washer SC01DA63...
- Page 7 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：5/23 SYSTEM DESIGN LIMITATIONS 1.1 Power source and Voltage Voltage applied to hermetic terminal should be within the range mentioned in this specification. In the case of three phase, the phase imbalance should be within 3% among the compressor terminals.
- Page 8 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：6/23 Refrigerating machine oil should be continuing to return to the compressor, but can not remain in the refrigeration system. A compressor oil should be higher than the height of 7.5mm above the fuel supply port. Compressor operation, not to allow the two layers were separated oil and refrigerant.
- Page 9 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：7/23 -35 -30 -25 -20 -15 -10 Evaporating temperature(℃) raph 1 图 1 70℃ Condensing temperature 70℃ 25℃ 10℃ 10℃ Evaporation Temperature 25℃ 25℃ 10℃ -15℃ -15℃ 1.5 Discharge pipe temperature Discharge pipe temperature is measured at a distance 300mm from the surface of compressor and should be less than 110℃.
- Page 10 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：8/23 1.6 Temperature of Shell Bottom The Temperature of compressor shell Bottom must be 6 degrees higher than the corresponding saturated temperature of discharge pressure under normal operating conditions. 1.7 Avoid refrigerant migration The refrigerant migration to compressor shell should be avoided during the heat pump water heater system shut down periods, It’s suggested that the electric heating belt should be used around the shell bottom when necessary.
- Page 11 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：9/23 2.2 Prevent moisture from entering into the enclosed unit system . When the moisture entered into the unit, the refrigerant oil and the organic compound material presented in the hermetic motor will possibly decompose on the affecting of water .
- Page 12 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：10/23 Dry nitrogen should be charged in compressor before assembly of system. Welding should be finished within one minute after charge of nitrogen. Dry nitrogen needs to be charged again and weld if over one minute. Always purge the compressor with dry nitrogen during assembly of system .
- Page 13 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：11/23 3.5 The electric pulse should not be applied to the hermetic terminals when t h e c o m p r e s s o r i s u n d e r v a c u u m . 3.6 The compressor should be kept in the clean place with low-moisture.
- Page 14 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE：12/23 3.13 The compressor should be kept out of the corrosive atmosphere such as in a chemicals storage, beside a hot spring and so on. 3.14 The lead wires should be connected to hermetic terminals without being touched on the surface of the c o m p r e s s o r .
- Page 15 Check upon Delivery PAGE：13/23 1. Basis for Checking upon Delivery The Performance test will be carried out in accordance with this “compressor specification”. The Safety Performance in accordance with GB4706.1 Safety of household and similar electrical appliances General requirements and GB 4706.17 Safety of household and similar electrical appliances Particular requirements for motor-compressor.
- Page 16 14/23...
- Page 17 15/23...
- Page 18 16/23...
- Page 19 17/23...
- Page 20 18/23...
- Page 21 19/23...
- Page 22 20/23...
- Page 23 21/23...
- Page 24 22/23...
- Page 25 23/23 Specification Revision Record Page in Conclusion Date Revision Reason Spec Date...
