Summary of Contents for POD Point Twin Charger
- Page 1 Fast Charging Twin Charger Install Guide (Web Version) Twin Charger Installation Guide Twin Charger PP-D-210456-3 PP-D-150133-4 Installation Guide T-C-UK-IG...
-
Page 2: Legal Notice
Pod Point is not responsible for installation and/or commissioning works performed by a 3rd party In the absence of any negligence or other breach of duty by Pod Point, Pod Point is not responsible for any injury, loss or damage caused by any works, services, products or... -
Page 3: Safety Instructions
Physical damage to the product may result in unsafe conditions, ensure electricity supplies are ● isolated and the product is not used if damaged - consult Pod Point for further information and repair. DANGER! Hazardous Voltage - Never make any unauthorised modifications to the internal components of this product. -
Page 4: Technical Specifications
QR code. If you have any further questions, comments, or issues regarding Pod Point Products which are not covered by this installation guide, please try our help centre (help.pod-point.com) or contact our customer support team. You may be asked to provide the serial number of your Pod Point Twin Charger (located at the bottom of the charger). -
Page 5: Product Overview
6mA DC earth leakage protection is inbuilt (per socket) to allow the use of type A RCDs both within the Twin Charger (RCDs in the supply circuit will need to be specified in accordance with details provided on page 9 & 10) - this feature will disconnect the electricity supply to the vehicle in the event of DC earth leakage exceeding 6mA which in turn will prevent unintentional blinding of type A RCDs and ensure safe operation. -
Page 6: Tools Required
The presence of a 3G/4G router is determined by “-RO” at the end of the product SKU on the box and/or Twin Charger. When using mobile connectivity only 1 Twin Charger in 5 will require a Router providing the Twin Chargers are sited in adjacent parking bays i.e. within c.25m of uninterrupted line of sight. - Page 7 fitted correctly. The maximum duct size is 110mm. The Twin Charger and associated signage should not obstruct the pavement or other public footway. Under no circumstances should the width of a public footway be restricted to less than 1m, preferably not less than 1.5m.
-
Page 8: Electrical Connection
The Twin Charger is suitable for connection to the following earthing systems: TN-C-S (PME) The Pod Point Twin Charger has built in PME fault protection which means it can be connected to a PME (TN-C-S) earthing system PME fault protection is disabled when the Twin Charger forms part of an Array system. - Page 9 (1 supply circuit providing power to both charging sockets) this can be adjusted for dual supply installations. The Twin Charger connection points within the DBOX will initially be configured as in Fig 3. Twin Chargers specified with an RFID and/or...
- Page 10 Twin Charger. The Twin Charger must be protected against overcurrent and fault at the source of supply by a suitably rated MCB, MCCB or fuse (see below for current ratings).
- Page 11 / stress. Circuits and supply cables must be able to carry the nominal load current and combined prospective fault current for the Twin Charger. The Twin Charger must be protected against overcurrent and fault at the source of supply by a suitably rated MCB, MCCB or fuse (see below for current ratings).
-
Page 12: Three-Phase
22kW to 11kW or 7kW to 3.6kW. If this is required, you will need to replace the main decal sticker on the lid of the Twin Charger to indicate the true charging rate of 11kW or 3.6kW. -
Page 13: Electrical Testing
Ensure the foundation ground plate is securely fixed with bolts / nuts tightened to the correct torque value (see fixing manufacturer data), confirm that the foundation fixings have washers fitted and that one of the methods below is being used to ensure the Twin Charger does not become loose over time: Thread locking compound applied to foundation threads ❏... - Page 14 Wi-Fi password key (usually found on the Wi-Fi router) Testing of Functionality 2. Switch 1 side of the Twin Charger on, by turning on 1 out of 2 MCBs, while the other In order to test the functionality of the one is turned off.
-
Page 15: Maintenance
Failure to do so may invalidate the product warranty - please check the Pod Point Warranty Terms and Conditions for more information on this. To arrange a service visit by a Pod Point authorised engineer, please contact us via: www.pod-point.com/contact...
