Giorik FLG72 Series Instructions For Installation, Use And Maintenance Manual

Gas fry top

Advertisement

Quick Links

EN -
FLG72.. - FRG72.. - FMG72..
FLG92.. - FRG92.. - FMG92..
ENGLISH: Installation, Use and Maintenance Manual
GAS FRY TOP
FLG74.. - FRG74.. - FMG74..
FLG94.. - FRG94.. - FMG94..
03/2017
rev.02/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLG72 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Giorik FLG72 Series

  • Page 1 GAS FRY TOP EN - FLG72.. - FRG72.. - FMG72.. FLG74.. - FRG74.. - FMG74.. FLG92.. - FRG92.. - FMG92.. FLG94.. - FRG94.. - FMG94.. ENGLISH: Installation, Use and Maintenance Manual 03/2017 rev.02/2018...
  • Page 3: Table Of Contents

    Contents 1. INSTALLATION 1.1 General and safety warnings ..........5 1.2 Positioning ................. 9 1.3 Equipotential ..............10 1.4 Smoke exhaust ..............10 1.5 Gas connection ..............11 1.6 Transformation for use with Different Gas ......13 2. TECHNICAL SPECIFICATIONS 3. GENERAL INSTRUCTIONS FOR USE 3.1 Commissioning ..............17 3.2 Functioning of models with plate in mild steel and compound 17 3.2.1 Ignition ................17...
  • Page 5: Installation

    1. INSTALLATION 1.1 General and safety warnings • Read this manual thoroughly technical assistance or your before installation local dealer immediately. oven, • As the packaging material provides important is potentially dangerous, instructions regarding its it must be kept out of the safe installation, use and reach of children or animals maintenance.
  • Page 6 must only be performed necessary experience by professionally qualified knowledge unless they are personnel following supervised or instructed in manufacturer's the use of the equipment by instructions. a person who is responsible for their safety. • During assembly of the equipment, the transit or •...
  • Page 7 by an assistance centre previous warnings authorised compromise both your manufacturer and original safety and the safety of the spare parts must be used. equipment. • ATTENTION: the floor near • Interventions, tampering or the appliance must not be modifications not expressly slippery.
  • Page 9: Positioning

    1.2 Positioning The appliance was designed to be installed in enclosed spaces. It cannot be used outdoors and must be exposed to atmospheric agents. The place designated for the installation of the appliance must have a rigid, level and horizontal surface, which must be able to safely support the weight of the appliance (approx.
  • Page 10: Equipotential

    1.3 Equipotential The appliance must be included within an equipotential system whose efficiency is checked in compliance with the standards in force. For connection there is a clamp, located on the frame and marked with the symbol of Fig. 3. Fig.
  • Page 11: Gas Connection

    1.5 Gas connection G25.3 G30 G31 G20 G25 G25.3 COUNTRY Check on the rating plate (Fig. 5), Pmbar 30 30 / placed on the side in the bottom 2L3B/P m³/h Pmbar 30 30 left corner, that the appliance has 2EK3B/P been tested and approved for the G30 G31 G20 G25 COUNTRY type of gas that the user uses.
  • Page 12 Control of the Nominal Heat Input: During initial installation and during maintenance or adaptation to another type of gas nominal heat input must be measured. It can be measured using the volumetric method with the aid of a litre counter or chronometer. GAS TYPE PRESSURE IN mbar.
  • Page 13: Transformation For Use With Different Gas

    company to test main gas supply pressure. A pressure adjuster may need to be inserted upstream of the appliance. 1.6 Transformation for use with Different Gas If the appliance must be connected to a different type of gas than that for which it has been prepared, the nozzles must be replaced.
  • Page 14 Primary air regulation The primary air is properly regulated if flame stability is ensured or, in other words, if there are no breaks in the flame with the burner cold and if there is no backfiring with the burner hot. The distance envisioned for adjustment of the primary air is indicated in Fig.9 and in Tab.4 Unscrew the injector “G”...
  • Page 15: Technical Specifications

    2. TECHNICAL SPECIFICATIONS MODEL F.G72.. F.G74.. F.G741.. Rated output N. tops Construction type Total gas consumption G20 Natural Gas m3/h 0.74 1.48 G30 LPG Kg/h 0.55 1.10 Tab.2 MODEL F.G92.. F.G94.. F.G941.. Rated output N. tops Construction type Total gas consumption G20 Natural Gas m3/h 0.85...
  • Page 17: General Instructions For Use

    3. GENERAL INSTRUCTIONS FOR USE 3.1 Commissioning The appliance must be used only for the purpose for which it was designed. Any other use is improper. Before putting the appliance into operation, you should carefully carry out all the necessary checks to ascertain the conformity of the equipment, of the installation of the appliance as provided by law and according to the technical and safety instructions given in this manual.
  • Page 18: Switch-Off

    button until the pilot flame ignites. Ignition Knob: can be observed through the peephole on the instrument panel. Hold the knob down for a further 15-20 seconds. If the flame should pilot flame go out when the knob is released, repeat the operation;...
  • Page 19: Switch-Off

    Turn the temperature regulation knob and hold it pressed in the pilot position . At the same time, repeatedly press the ignition button for approximately 20 seconds until all air in the pipes has escaped and the pilot turns on. Ignition can be observed through the peephole on the instrument panel.
  • Page 20: Maintenance And Cleaning

    4. MAINTENANCE and CLEANING Disconnect the appliance from the gas supply before performing any cleaning or maintenance operations. At the end of the working day, clean the appliance, both for reasons of hygiene and to prevent operating faults. The appliance must never be cleaned with direct or high pressure jets of water.
  • Page 21: Disposal Of The Appliance

    5. DISPOSAL OF THE APPLIANCE At the end of its life span, the appliance must be disposed of in accordance with legal obligations. The symbol in Fig. 17 specifies that, at the end of its life span, the appliance must be disposed of according to the indications of the European Parliament Directive 2012/19/EU dated 04/06/2012.
  • Page 24 THE MANUFACTURER SHALL NOT BE HELD LIABLE FOR ANY DAMAGES DUE TO IMPROPER INSTALLATION, TAMPERING WITH THE APPLIANCE, MISUSE, IMPROPER MAINTENANCE, FAILURE TO COMPLY WITH APPLICABLE STANDARDS AND INTENDED USE. THE MANUFACTURER RESERVES THE RIGHT TO MAKE CHANGES TO THE PRODUCT AT ANY TIME IT DEEMS NECESSARY OR USEFUL.
