TRENDnet TV-IP200 Frequently Asked Questions Manual

TV-IP200/TV-IP200W F.A.Q.
Q: How can I configure my TV-IP200 (w) through the web-based configuration?
A:
Open your web browser and type the IP address of the TV-IP200 in the address bar. The default IP
address is 192.168.0.20.
Q: What is the default IP address of my TV-IP200 (w)?
A:
The default IP address is 192.168.0.20
Q: How can I view the TV-IP200 (w) remotely if it's behind a router or firewall?
A:
Each camera behind a firewall or router will need one port forwarded for the video streaming. The
default port is: 80 (TCP) HTTP Port.
If you are installing multiple cameras you must change the port on the additional cameras.
Example: Camera 1 is using the default port 80 (TCP). Camera 2 must use a different port. For
example: ports 81 (TCP) and 8482 (TCP).
You can change the port on the camera on the System Administration tab in the web-configuration
page.
Step 1. Open your web browser and type the IP address of the TV-IP200 (w) in the address
bar. The default IP address is 192.168.0.20.
Step 2. Click on "System Administration".
