Mounting Instructions and Manual
SANX600
EA-Nr.:
– SANX600
7612979002355
EA-Nr.:
– SANX605
7612979002362
1. Important Notes
.
Before installation, the instructions have to be read and understood.
.
Installation, commissioning and maintenance are to be performed only by a
qualified technician according to the instructions provided and in accordance with
legal requirements and acknowledged rules of technology.
B1080 – SANX600/605/26.10.2010
SANX605
(1000x1000x1205mm)
(1000x1000x1290mm) with SD
2. Scope of supply
Qty
Part
1
SANX600
6 Person Circular Washtrough Manual Taps
1
SANX605
6 Person Circular Washtrough Manual Taps with Soap Dispensers
1
B4198
6
AQUA205
1
B1353
3
SD80
Soap Dispensers (For SANX605 Variant)
3. Dimensions
Designation
1 ½" S Tubular Trap
Aqualine S Taps
M5 Allen Key Security Pin
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Franke SANX600
Summary of Contents for Franke SANX600
- Page 1 Before installation, the instructions have to be read and understood. Installation, commissioning and maintenance are to be performed only by a qualified technician according to the instructions provided and in accordance with legal requirements and acknowledged rules of technology. B1080 – SANX600/605/26.10.2010...
- Page 2 Herbal Oils: < 1% Optimal the installer to connect their pipe Animal Fat: < 1% Viscosity: 1.000 ± 1000mPa.s work to. For repair/maintenance please refer to SD80 service manual (Included) B1080 – SANX600/605/26.10.2010...
- Page 3 For pressures in excess of 7 bar g. a flow control or pressure reducing valve T: +44-(0)1246-450255 should be fitted (Not supplied) F: +44-(0)1246-451276 For further repair/maintenance please refer to the taps service manual (Included) E: ws.uk@franke.com B1080 – SANX600/605/26.10.2010...
