CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 8:30 a.m. to 5 p.m. EST (except holidays)
Hutch
Costa Collection | Model 428724
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-523-3987
.
For things 'n such.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 548256
Purchased: __________________
10/15/20
Advertisement
Related Manuals for Sauder Costa 428724
Summary of Contents for Sauder Costa 428724
- Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-523-3987 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 8:30 a.m.
- Page 2 No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identification Assembly Steps 5-22 Hammer Not actual size Français 23-25 Español 26-28 Nail holder (provided) Safety 29-30 Tape Measure Warranty Electric drill with 3/16" bit (ONLY in indicated step) Page 2 428724 www.sauder.com/service...
- Page 3 Use this part identification to help identify similar parts. END (2) ADJUSTABLE SHELF (2) BRACE (1) FRONT LEG (2) ADJUSTABLE SHELF MOLDING (2) RIGHT REAR LEG (1) END MOLDING (2) BACK (1) K2 TOP (1) VALANCE (1) LEFT REAR LEG (1) www.sauder.com/service 428724 Page 3...
- Page 4 CAM COVER - 16 105P FASTENER COVER - 4 METAL PIN - 8 RUBBER SLEEVE - 8 FURNITURE TIPPING RESTRAINT KIT - 1 BLACK 9/16" LARGE HEAD SCREW - 3 BLACK 9/16" FLAT HEAD SCREW - 4 Page 4 428724 www.sauder.com/service...
- Page 5 Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor. å To begin assembly, push a SAUDER TWIST-LOCK® FASTENER (37F) into the large holes in the ENDS (A) and VALANCE (D).
- Page 6 Push twenty-four HIDDEN CAMS (1F) into the edges of the ENDS (A), BRACE (I), and ADJUSTABLE SHELVES (E). (24 used) Arrow Arrow Arrow Arrow Hole Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 6 428724 www.sauder.com/service...
- Page 7 Step 3 å Turn twenty CAM SCREWS (8F) into the LEGS (B, H, and J) and SHELF MOLDINGS (F). Remember: (20 used) Righty tighty. Lefty loosey. www.sauder.com/service 428724 Page 7...
- Page 8 Shoulder These edges should be even. Apply pressure with your hands as you guide the MOLDINGS over the SCREWS and onto the ENDS. BLACK 9/16" FLAT HEAD SCREW Shoulder (4 used in this step) Page 8 428724 www.sauder.com/service...
- Page 9 END (A). This END (A) will become the left END (A). S u r f a c i t h H I D D E N These surfaces Edge with should be even. TWIST-LOCK® FASTENERS www.sauder.com/service 428724 Page 9...
- Page 10 Step 6 å Fasten the right END (A) to the TOP (K2). Tighten two How to use the SAUDER TWIST-LOCK FASTENER ® TWIST-LOCK® FASTENERS. 1. Insert the dowel end of the FASTENER into the å hole of the adjoining part.
- Page 11 Push a WOOD DOWEL (15F) into the RIGHT REAR LEG (J). å Fasten the BRACE (I) to the RIGHT REAR LEG (J). Tighten the HIDDEN CAM. å NOTE: Be sure the WOOD DOWEL inserts into the edge of the BRACE. www.sauder.com/service 428724 Page 11...
- Page 12 NOTE: Be sure the WOOD DOWEL inserts into the edge of the BRACE. å Using your hammer, gently tap a TWIST-LOCK® FASTENER COVER (105P) onto each visible TWIST-LOCK® FASTENER. 105P (4 used) For support, place packing foam and magazines here. Page 12 428724 www.sauder.com/service...
- Page 13 REAR LEG. The CAM SCREWS should be closer to this edge. Lower edge of REAR LEG View shown without the LEFT END for clarity. For support, place packing foam and magazines here. www.sauder.com/service 428724 Page 13...
- Page 14 CLIPS should bite into the BRACES as you tighten the screws. Offset edge Nail Nail slot holder 2" Bead Bead Lower edge 2" Bead Lower edge (3 used) NAIL BLACK 9/16" LARGE HEAD SCREW (12 used in this step) (3 used in this step) Page 14 428724 www.sauder.com/service...
- Page 15 Base and the 428191 Lateral File. å Go to Step 13 if your 428192 Library Base or the 428191 Lateral File is assembled. å Go to Step 14 if your 428192 Library Base or the 428191 Lateral File is not assembled. www.sauder.com/service 428724 Page 15...
- Page 16 Drill through these two small holes. Drill through these two small holes. Drill through these two small holes. Drill through these two small holes. Page 16 428724 www.sauder.com/service...
- Page 17 BACK EDGE OF TOP templates only if your 428192 Library Base or the 428191 Lateral File is assembled. å Cut out the two templates along the dashed lines and go LEFT TEMPLATE RIGHT TEMPLATE to Step 14. www.sauder.com/service 428724 Page 17...
- Page 18 This page was intentionally left blank. Cette page a été intentionnellement laissée vierge. Esta página fue dejada en blanco intencionalmente. Page 18 428724 www.sauder.com/service...
- Page 19 LEFT TEMPLATE outside edge. Drill through the two circles closest to the outside edge. Drill through these four LEFT TEMPLATE circles farthest away from the outside edge. RIGHT TEMPLATE RIGHT TEMPLATE www.sauder.com/service 428724 Page 19...
- Page 20 And, you know, your Library Base or Lateral File. your arms. å With the help of another person, carefully lift your HUTCH and place it over the CAM SCREWS (8F). Tighten four HIDDEN CAMS. (4 used) Page 20 428724 www.sauder.com/service...
- Page 21 NOTE: Before moving your unit to a different location, unscrew the SAFETY DRYWALL ANCHOR from your wall. The nylon sheath will remain behind your wall. Washer Safety Short screw Warning drywall anchor For safety purposes, the hutch must be placed against a wall. Safety strap www.sauder.com/service 428724 Page 21...
- Page 22 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or (8 used) (16 used)
- Page 23 REFERENCE DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en EXTRÉMITÉ ..............2 EXCENTRIQUE ESCAMOTABLE ....24 ce qui concerne cet PIED AVANT..............2 VIS D'EXCENTRIQUE ..........24 élément, faire référence MOULURE D’EXTRÉMITÉ ........2 37F FIXATION TWIST-LOCK® ........6 au numéro de lot et...
- Page 24 éviter d'endommager l'élément ou le sol. l’EXCENTRIQUE ESCAMOTABLE. Pour commencer l'assemblage, enfoncer une FIXATION REMARQUE : S’ a ssurer d’insérer la CHEVILLE EN BOIS dans le TWIST-LOCK® SAUDER (37F) dans les gros trous des EXTRÉMITÉS (A) et LAMBREQUIN (D). chant de l'ENTRETOISE. ÉTAPE 8 ÉTAPE 2...
- Page 25 Base de bibliothèque ou du Classeur Latéral. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Avec l’ a ide d’une autre personne, soulever soigneusement le SURMEUBLE et le placer sur les VIS D'EXCENTRIQUE (8F). Serrer quatre EXCENTRIQUES ESCAMOTABLES. www.sauder.com/service 428724 Page 25...
- Page 26 EXCÉNTRICO ESCONDIDO ......24 su referencia futura. Si necesita ponerse en PATA DELANTERA ............2 BIELA DE EXCÉNTRICO ........24 contacto con Sauder en MOLDURA DE EXTREMO ........2 37F SUJETADOR TWIST-LOCK®........6 cuanto a esta unidad, CORNISA ................1 15F PASADOR DE MADERA .........2 refiérase al número...
- Page 27 Fije la CORNISA (D) al PANEL SUPERIOR (K2). Apriete dos SUJETADORES TWIST-LOCK®. Para comenzar el ensamblaje, empuje un SUJETADOR TWIST-LOCK® SAUDER (37F) dentro de los agujeros grandes de Cómo utilizar el SUJETADOR TWIST-LOCK® SAUDER los EXTREMOS (A) y de la CORNISA (D).
- Page 28 Base de Biblioteca o el Archivero Lateral. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. Page 28 428724 www.sauder.com/service...
- Page 29 à mortelles. Les téléviseurs peuvent être un téléviseur. cet effet. particulièrement lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/service 428724 Page 29...
- Page 30 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 30 428724 www.sauder.com/service...
- Page 31 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
- Page 32 BEFORE MAKING ANY RETURNS TO THE RETAILER. So, how did it go? Dear Valued Customer: Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
