CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Library Base
Manhattan Gate Collection | Model 429250
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
For things 'n such.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-18
Español pg 19-21
Lot # 565095
Purchased: __________________
04/13/21

Advertisement

loading

Related Manuals for Sauder Manhattan Gate 429250

Summary of Contents for Sauder Manhattan Gate 429250

  • Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-445-1527 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m.

  • Page 2: Table Of Contents

    Table of Contents Assembly Tools Required Part Identification No. 2 Phillips Screwdriver Hardware Identification Tip Shown Actual Size Hardware Usage Guide Assembly Steps 6-15 Hammer Not actual size Français 16-18 Español 19-21 Safety Warranty Page 2 www.sauder.com/service 429250...

  • Page 3: Part Identification

    Use this part identification to help identify similar parts. TOP (1) RIGHT END (1) LEFT END (1) ADJUSTABLE SHELF (1) BOTTOM (1) LOWER BACK (1) UPPER BACK (1) DOOR PULL (2) LEFT DOOR (1) RIGHT DOOR (1) 429250 www.sauder.com/service Page 3...

  • Page 4: Hardware Identification

    HIDDEN CAM - 16 WOOD DOWEL - 18 HINGE - 4 SHELF PIN - 4 APPLIQUE CARD - 1 BUMPER CARD - 1 BLACK 1/2" FLAT HEAD SCREW - 6 SILVER 1/2" FLAT HEAD SCREW - 24 Page 4 www.sauder.com/service 429250...

  • Page 5: Hardware Usage Guide

    The arrow in the HIDDEN CAM must point Arrow toward the hole in the edge of the board. Hidden Cam Hole Insert the CAM SCREW or CAM DOWEL into the HIDDEN CAM. Tighten the HIDDEN CAM. 429250 www.sauder.com/service Page 5...

  • Page 6: Assembly Steps

    Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
  • Page 7 NOTE: Be sure the WOOD DOWELS in the BACK insert into the BOTTOM. Edge with CAM SCREWS Edge with HIDDEN CAMS S u r f a c H I D D E N i t h o 429250 www.sauder.com/service Page 7...
  • Page 8 Not technically faster. But definitely makes for a sturdier Library Base that’ s easier to assemble and friendlier to the environment. Arrow Be sure the HIDDEN CAMS are inserted completely into the holes. Page 8 www.sauder.com/service 429250...
  • Page 9 BACKS (F and G). Tighten four HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the END insert into the BOTTOM and BACKS. Part (C). Another sturdier, easier, Arrow friendlier component! Be sure the HIDDEN CAMS are inserted completely into the holes. 429250 www.sauder.com/service Page 9...
  • Page 10 Fasten the TOP (A) to the ENDS (B and C) and UPPER BACK (G). Tighten six HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the TOP insert into the ENDS and BACK. Part (A). Another sturdier, easier, friendlier component! Page 10 www.sauder.com/service 429250...
  • Page 11 Step 6 å Peel APPLIQUES from the APPLIQUE CARD (6) and stick them onto each visible HIDDEN CAM inside your unit. 429250 www.sauder.com/service Page 11...
  • Page 12 SILVER 1/2" FLAT HEAD SCREW Fasten the HINGES (4) to the DOORS (J and K). Use eight (8 used for the HINGES) SILVER 1/2" FLAT HEAD SCREWS (9). BLACK 1/2" FLAT HEAD SCREW (6 used for the PULLS) Page 12 www.sauder.com/service 429250...
  • Page 13 å Fasten the DOORS (J and K) to the ENDS (B and C). Use Adjusting sixteen SILVER 1/2" FLAT HEAD SCREWS (9). screw SILVER 1/2" FLAT HEAD SCREW (16 used for the HINGES) 429250 www.sauder.com/service Page 13...
  • Page 14 To adjust the DOORS in or out (depth), loosen the mounting screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) Page 14 www.sauder.com/service 429250...
  • Page 15 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or (4 used) To raise a corner of your unit, rotate the LEVELER downward.

  • Page 16: Français

    REFERENCE DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en DESSUS ................1 VIS D'EXCENTRIQUE ..........16 ce qui concerne cet EXTRÉMITÉ DROITE ..........1 EXCENTRIQUE ESCAMOTABLE ....16 élément, faire référence EXTRÉMITÉ GAUCHE ..........1 CHEVILLE EN BOIS ..........18 au numéro de lot et...
  • Page 17 DESSOUS. Fixer le DESSUS (A) aux EXTRÉMITÉS (B et C) et à l’ARRIÈRE SUPÉRIEUR (G). Serrer six EXCENTRIQUES ESCAMOTABLES. REMARQUE : S’ a ssurer d’insérer les CHEVILLES EN BOIS du DESSUS dans les EXTRÉMITÉS et l’ARRIÈRE. 429250 www.sauder.com/service Page 17...
  • Page 18 VÉRIN vers le haut. REMARQUE : Prière de lire les informations importantes sur la sécurité figurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 18 www.sauder.com/service 429250...

  • Page 19: Español

    BIELA DE EXCÉNTRICO ........16 su referencia futura. Si necesita ponerse en EXTREMO DERECHO ..........1 EXCÉNTRICO ESCONDIDO ......16 contacto con Sauder en EXTREMO IZQUIERDO ..........1 PASADOR DE MADERA ........18 cuanto a esta unidad, ESTANTE AJUSTABLE ..........1 BISAGRA ................4 refiérase al número...
  • Page 20 Fije el PANEL SUPERIOR (A) a los EXTREMOS (B y C) y al DORSO SUPERIOR (G). Apriete seis EXCÉNTRICOS ESCONDIDOS. NOTA: Asegúrese de que los PASADORES DE MADERA en el PANEL SUPERIOR se inserten en los EXTREMOS y el DORSO. Page 20 www.sauder.com/service 429250...
  • Page 21 TORNILLOS PLATEADOS DE CABEZA PERDIDA de 13 mm (9). NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. 429250 www.sauder.com/service Page 21...

  • Page 22: Safety

    Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 22 www.sauder.com/service 429250...

  • Page 23: Warranty

    à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 24 BEFORE MAKING ANY RETURNS TO THE RETAILER. So, how did it go? Dear Valued Customer: Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
