sauder.com

BEFORE MAKING ANY RETURNS TO THE STORE.

BEFORE MAKING ANY RETURNS TO THE RETAILER.

sauder.com/service

Visit

Prefer the phone? Give us a ring at

Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)

Credenza

Manhattan Gate Collection | Model 429256

Sauder.com

Share your journey!

to order replacement parts, view video assembly tips, or chat with a live rep.

1-800-445-1527

Store behind

closed doors.

NOTE: THIS INSTRUCTION

BOOKLET CONTAINS IMPORTANT

SAFETY INFORMATION.

PLEASE READ AND KEEP FOR

FUTURE REFERENCE.

English pg 1-30

Français pg 31-35

Español pg 36-40

Lot # 565102

Purchased: __________________

04/29/21

Summary of Contents for Sauder Manhattan Gate 429256

Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-445-1527 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m.
Page 2 Table of Contents Assembly Tools Required Part Identiﬁ cation No. 2 Phillips Screwdriver Hardware Identiﬁ cation Tip Shown Actual Size Hardware Usage Guide Assembly Steps 6-30 Français 31-35 Español 36-40 Safety 41-42 Warranty Page 2 www.sauder.com/service 429256...
Page 3 FILE HANGER (1) RIGHT END (1) LOWER BACK (1) LEFT DOOR (2) LEFT END (1) BOTTOM (1) RIGHT DOOR (2) SLIDING SHELF (1) SKIRT (2) PULL (4) FIXED SHELF (1) SMALL SPACER (2) UPRIGHT (1) LARGE SPACER (2) 429256 www.sauder.com/service Page 3...
Page 4 1-3/4" FLAT HEAD SCREW - 12 1" FLAT HEAD SCREW - 12 SILVER 1/2" FLAT HEAD SCREW - 48 BLACK 1/2" FLAT HEAD SCREW - 8 3/8" PAN HEAD SCREW - 12 1/4" MACHINE SCREW - 6 Page 4 www.sauder.com/service 429256...
Page 5 The arrow in the HIDDEN CAM must point Arrow toward the hole in the edge of the board. Hidden Cam Hole Insert the CAM SCREW or CAM DOWEL into the HIDDEN CAM. Tighten the HIDDEN CAM. 429256 www.sauder.com/service Page 5...
Page 6 Look for this icon. It means a video assembly tip is Step 1 available at www.sauder.com/service/tips Find the numbered video or scan the QR code. Assemble your unit on a carpeted ﬂ oor or on the empty å carton to avoid scratching your unit or the ﬂ oor.
Page 7 å BOTTOM insert into the SKIRTS. D E N H I D i t h f a c S u r D E N H I D i t h f a c S u r 429256 www.sauder.com/service Page 7...
Page 8 1" FLAT HEAD SCREWS (12). NOTE: Be sure the SHORT WOOD DOWELS in the å UPRIGHT insert into the SMALL SPACER. 1" FLAT HEAD SCREW (3 used in this step) These holes must be here. Page 8 www.sauder.com/service 429256...
Page 9 NOTE: The EXTENSION SLIDES will be used later for the DRAWERS. å Open end Push the black lever and pull the SLIDE from the RAIL. Use these holes 3/8" PAN HEAD SCREW (3 used in this step) Open end These holes must be here. 429256 www.sauder.com/service Page 9...
Page 10 NOTE: Be sure the LONG WOOD DOWELS in the UPRIGHT insert into the FIXED SHELF. å Arrow Arrow i t h f a c S u r D E N H I D These edges must be even. Page 10 www.sauder.com/service 429256...
Page 11 LOWER BACK (H). Push the UPPER BACK (G) onto the LONG WOOD DOWELS (5) in the å LOWER BACK (H). Push eight HIDDEN CAMS (4) into the BACKS (G and H). å Arrow Arrow Notch Arrow 429256 www.sauder.com/service Page 11...
Page 12 NOTE: You should start each SCREW a few turns before å completely tightening any of them. i t h f a c S u r D E N H I D 1-3/4" FLAT HEAD SCREW (6 used in this step) Page 12 www.sauder.com/service 429256...
Page 13 Meet Parts (B and C). These components have been engineered to be lighter, stronger, faster… well ok. Not technically faster. But deﬁ nitely makes for a sturdier Credenza that’ s easier to assemble and friendlier to the environment. Arrow 429256 www.sauder.com/service Page 13...
Page 14 Fasten the RIGHT END (B) to the FIXED SHELF (E), BACKS (G and H), and å BOTTOM (J). Tighten six HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the RIGHT END insert into the å FIXED SHELF, BACKS, and BOTTOM. Page 14 www.sauder.com/service 429256...
Page 15 NOTE: Be sure the LONG WOOD DOWELS in the LEFT å END insert into the LARGE SPACER. NOTE: You should start each SCREW a few turns before å completely tightening any of them. 1-3/4" FLAT HEAD SCREW (3 used in this step) 429256 www.sauder.com/service Page 15...
Page 16 RAIL in to ﬁ nd the other holes that lines up with the holes in the LARGE SPACER. Turn a SCREW into these holes. Open end Use these holes 3/8" PAN HEAD SCREW (3 used in this step) Open end Page 16 www.sauder.com/service 429256...
Page 17 Tighten four HIDDEN CAMS. NOTE: Be sure the LONG WOOD DOWELS in the LEFT END insert å into the BACKS and BOTTOM. S u r f a c i t h o u t h o l e 429256 www.sauder.com/service Page 17...
Page 18 Step 13 Turn ten CAM SCREWS (3) into the TOP (A). å Now might be a good time to refresh your drink. Part (A). Another sturdier, easier, friendlier component! Page 18 www.sauder.com/service 429256...
Page 19 Fasten the TOP (A) to the ENDS (B and C), UPRIGHT (F), and UPPER å BACK (G). Tighten ten HIDDEN CAMS. NOTE: Be sure the LONG WOOD DOWELS in the TOP insert into the å ENDS, UPRIGHT, and UPPER BACK. 429256 www.sauder.com/service Page 19...
Page 20 NOTE: You should start each SCREW a few turns before completely tightening any of them. å See below for detail 1-3/4" FLAT HEAD SCREW (3 used in this step) 1" FLAT HEAD SCREW (3 used in this step) This view is shown for clarity of the above view. Page 20 www.sauder.com/service 429256...
Page 21 EXTENSION RAIL in to ﬁ nd the other holes that lines up with the holes in the SPACERS (L and M). Turn a SCREW into these holes. Open end Use these holes See below for detail Open end Open end 3/8" PAN HEAD SCREW (6 used in this step) 429256 www.sauder.com/service Page 21...
Page 22 å six 1/4" MACHINE SCREWS (16) through the holes shown in the enlarged diagram. Open end 1/4" MACHINE HEAD SCREW (6 used in this step) Open end Open end This hole is closer to this edge. Page 22 www.sauder.com/service 429256...
Page 23 SHELF (D). Use six 1" FLAT HEAD SCREWS (12) through the holes shown in the enlarged diagram. Open end 1" FLAT HEAD SCREW (6 used in this step) Open end Notch Open end This hole is closer to this edge. 429256 www.sauder.com/service Page 23...
Page 24 Repeat this step to insert the FILE HANGER (N). The FILE å HANGER will accommodate both letter and legal size ﬁ les. L e g t e r L e t Page 24 www.sauder.com/service 429256...
Page 25 Fasten the HINGES (7) to the DOORS (P and Q). Use å eight SILVER 1/2" FLAT HEAD SCREWS (13). SILVER 1/2" FLAT HEAD SCREW (8 used in this step) BLACK 1/2" FLAT HEAD SCREW (4 used in this step) 429256 www.sauder.com/service Page 25...
Page 26 Fasten a LEFT DOOR (P) to the LEFT END (C) and a å RIGHT DOOR (Q) to the RIGHT END (B) as shown. Use Mounting screw sixteen SILVER 1/2" FLAT HEAD SCREWS (13). Adjusting screw Hinge SILVER 1/2" FLAT HEAD SCREW (16 used in this step) Page 26 www.sauder.com/service 429256...
Page 27 Fasten the HINGES (8) to the DOORS (P and Q). Use å eight SILVER 1/2" FLAT HEAD SCREWS (13). SILVER 1/2" FLAT HEAD SCREW (8 used in this step) BLACK 1/2" FLAT HEAD SCREW (4 used in this step) 429256 www.sauder.com/service Page 27...
Page 28 HEAD SCREWS (13). Fasten the LEFT DOOR (P) to the right surface of å the UPRIGHT (F). Use eight SILVER 1/2" FLAT Hinge HEAD SCREWS (13). SILVER 1/2" FLAT HEAD SCREW (16 used in this step) Page 28 www.sauder.com/service 429256...
Page 29 To adjust the DOORS in or out (depth), loosen the mounting å Mounting screw (depth) screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Adjusting screw (horizontal) 429256 www.sauder.com/service Page 29...
Page 30 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. å And to celebrate, why not share your success story at sauder.com or Page 30 www.sauder.com/service 429256...
Page 31 REFERENCE DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en DESSUS ................1 (ENSEMBLE DE GLISSIÈRE ILLUSTRÉ À PART) ce qui concerne cet EXTRÉMITÉ DROITE ..........1 GLISSIÈRE D'EXTENSION ........4 élément, faire référence EXTRÉMITÉ GAUCHE ..........1 COULISSE D'EXTENSION ........4...
Page 32 REMARQUE : S'assurer de bien insérer les LONGUES CHEVILLES EN BOIS situées sur l'ARRIÈRE INFÉRIEUR et le MONTANT dans le DESSOUS. REMARQUE : Il est préférable de donner quelques tours de tournevis à chaque VIS avant de les serrer toutes à bloc. Page 32 www.sauder.com/service 429256...
Page 33 DOSSIERS (N). Utiliser six VIS À MÉTAUX 6 mm (16) à travers les DESSOUS (J). Serrer quatre EXCENTRIQUES ESCAMOTABLES. trous comme l'indique les schémas agrandis. REMARQUE : S’ a ssurer d’insérer les LONGUES CHEVILLES EN BOIS de l’EXTRÉMITÉ GAUCHE dans les ARRIÈRES et le DESSOUS. 429256 www.sauder.com/service Page 33...
Page 34 PORTE DROITE (Q) à l’EXTRÉMITÉ DROITE (B) comme l'indique le Répéter cette étape pour insérer le SUPPORT POUR DOSSIERS (N). schéma. Utiliser seize VIS TÊTE PLATE 13 mm ARGENTÉES (13). Le SUPPORT POUR DOSSIERS s'adaptera à la fois au format lettre et légal. Page 34 www.sauder.com/service 429256...
Page 35 PORTES (P et Q) une fois fermées. REMARQUE : Prière de lire les informations importantes sur la sécurité ﬁ gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. 429256 www.sauder.com/service Page 35...
Page 36 PANEL SUPERIOR ............1 (JUEGO DE EXTENSIÓN SE MUESTRA POR su referencia futura. Si SEPARADO) necesita ponerse en EXTREMO DERECHO ..........1 contacto con Sauder en RIEL DE EXTENSIÓN ..........4 EXTREMO IZQUIERDO ..........1 cuanto a esta unidad, CORREDERA DE EXTENSIÓN ......4 ESTANTE DESLIZANTE ...........1 reﬁ...
Page 37 Fije el ESTANTE INMÓVIL (E) al PARAL (F). Apriete dos en el FONDO se inserten en los FALDONES. EXCÉNTRICOS ESCONDIDOS. NOTA: Asegúrese de que los PASADORES DE MADERA LARGOS ﬁ jados al PARAL se inserten en el ESTANTE INMÓVIL. 429256 www.sauder.com/service Page 37...
Page 38 A continuación, deslice el cartucho interno del RIEL DE EXTENSIÓN hacia el interior para encontrar los otros agujeros que se alinean con los agujeros del ESPACIADOR GRANDE. Atornille un TORNILLO dentro de estos agujeros. Page 38 www.sauder.com/service 429256...
Page 39 NOTA: Asegúrese de que los PASADORES DE MADERA LARGOS del EXTREMO DERECHO se inserten en el ESPACIADOR GRANDE. NOTA: Debe apretar cada TORNILLO unas vueltas antes de apretar cualquier tornillo ﬁ rmemente. 429256 www.sauder.com/service Page 39...
Page 40 PARAL (F). Utilice ocho TORNILLOS PLATEADOS DE CABEZA PERDIDA de 13 mm (13). Fije la PUERTA IZQUIERDA (P) a la superﬁ cie derecha del PARAL (F). Utilice ocho TORNILLOS PLATEADOS DE CABEZA PERDIDA de 13 mm (13). Page 40 www.sauder.com/service 429256...
Page 41 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. 429256 www.sauder.com/service Page 41...
Page 42 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 42 www.sauder.com/service 429256...
Page 43 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
Page 44 BEFORE MAKING ANY RETURNS TO THE RETAILER. Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
