Domino D-Series
Product Manual
D120i
D320i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Domino D Series

  • Page 1 Domino D-Series Product Manual D120i D320i...
  • Page 2 Note: This manual L025317 is intended for use only with the second generation of the D-Series product with a BCP7 Controller. L025317 Issue 1 March 2011...
  • Page 3 WARNINGS: AS SUPPLIED, THIS CODER IS A CLASS 4 LASER PRODUCT. DURING OPERATION, IT WILL EMIT UP TO 100 WATTS OF PULSED INVISIBLE LASER RADIATION AT A WAVELENGTH BETWEEN 9 AND 11 MICRONS. AVOID EYE OR SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION. THIS CODER MUST BE FITTED WITH CLASS 1 LASER GUARDING TO SAFEGUARD AGAINST ACCIDENTAL EXPOSURE TO DIRECT OR SCATTERED RADIATION BEFORE...
  • Page 4 Reading and understanding this manual is required before operating this laser system. This manual, Domino Part No. L025317, has been produced for use in the maintenance and operation of the Domino D-Series Laser Coder, and to reinforce and complement any training program available with the product. It is not designed to replace any such training program.
  • Page 5 Compliance is dependent upon installation and use in accordance with the Product Manual supplied. Signed for and on behalf of Domino Laser GmbH, Fangdieckstrasse 75a, 22547 Hamburg / Germany November 2010 Dr. Wilhelm Specker Research & Development Director - Domino Laser GmbH...
  • Page 6 FCC NOTICE PART 18 USERS MANUAL STATEMENT This equipment has been tested and found to comply with the limits of ISM Equipment pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a typical installation.
  • Page 7 USER LICENSE AGREEMENT (“EULA”) • You have acquired a device (“DEVICE”) that includes software licensed by Domino Printing Sciences plc from Microsoft Licensing Inc. or its affiliates (“MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online” or electronic documentation (“SOFTWARE”) are protected by international...
  • Page 8 • Note on Java Support. The SOFTWARE may contain support for programs written in Java. Java technology is not fault tolerant and is not designed, manufactured, or intended for use or resale as online control equipment in hazardous environments requiring fail-safe performance, such as in the operation of nuclear facilities, aircraft navigation or communication systems, air traffic control, direct life support machines, or weapons systems, in which the failure of Java technology could lead...
  • Page 9 D-SERIES PRODUCT MANUAL CONTENTS Part 1 ... . . Health & Safety Part 2 ... . . Installation Part 3 ... . . Operation Part 4 .
  • Page 10 LIABILITIES AND WARRANTIES Warranty and liability rights for personal or material damages are precluded, if they are caused by one of the following: • Non-designated use of the laser marking system • The use of consumer-electronics (e.g. PDAs or Mobiles) as user interface for the marking laser systems is not recommended nor supported •...
  • Page 11 AMENDMENT RECORD Amendment Date All Parts at Issue 1 March 2011 L025317 Issue 1 March 2011 (11)
  • Page 12 (12) L025317 Issue 1 March 2011...
  • Page 13: Table Of Contents

    PART 1 : HEALTH & SAFETY CONTENTS Page GENERAL ..................DESIGNATED USE ................SAFETY SYMBOLS ................SPECIFIC DANGERS ..............Electrical Energy ................Compressed Air ................Laser Radiation ................Harmful Dusts and Vapours ............Touching the Lens ................CLASS 1 GUARDING ..............Access Guards ................
  • Page 14 HEALTH & SAFETY THIS PAGE INTENTIONALLY LEFT BLANK L025317 Issue 1 March 2011...
  • Page 15: General

    The equipment conforms to current technology and approved safety requirements. Domino D-Series Laser marking systems are produced by Domino Laser GmbH Germany. For Sales and support contact Domino. This safety standard, however, can only be achieved if all intended and required measures have been taken and are constantly observed.
  • Page 16: Designated Use

    HEALTH & SAFETY DESIGNATED USE The D-Series laser marking system is exclusively designated for fully automated marking of packaging materials and products by laser radiation. If the laser marking system is used for improper purposes, all liability claims will be refused. The technical specifications listed in “TECHNICAL REFERENCE”...
  • Page 17 HEALTH & SAFETY Before turning the laser equipment on, check and ensure that: • The laser system has been installed and guarded to Class 1 laser safety standards (EN60825), see “CLASS 1 GUARDING” on page 1-9 • Only authorised personnel should be present within the operating area of the laser marking system.
  • Page 18: Safety Symbols

    HEALTH & SAFETY SAFETY SYMBOLS In this manual the following safety symbols have been used to alert the reader to the text of the safety instruction next to it. This manual provides specific safety instructions for the operation of the laser marking system.
  • Page 19: Specific Dangers

    HEALTH & SAFETY SPECIFIC DANGERS Electrical Energy In the D-Series laser marking system, the maximum operating voltage is the connected mains voltage, which can pose a hazard to health. The mains voltage to be maintained is shown on the name plate. Work on live components must only be performed by authorised personnel.
  • Page 20: Harmful Dusts And Vapours

    HEALTH & SAFETY Class 2 The accessible laser radiation is visible and is harmless for accidental exposure to eyes for periods of less than 0.25 seconds. Class 2M The accessible laser radiation is visible and is harmless for accidental exposure to eyes for periods of less than 0.25 seconds, provided additional optical instruments are not used.
  • Page 21: Class 1 Guarding

    HEALTH & SAFETY CLASS 1 GUARDING The following type of guarding, using the recommended materials and construction techniques, is required to achieve a Class 1 installation. Access Guards Access guards are required to prevent direct human access to the laser beam. In practice, this requires full guarding of the area between, and including, the laser output lens and the area to be marked on the substrate.
  • Page 22: Materials

    These labels are supplied with the laser system. Additional labels are available from Domino Printing Sciences plc as part of the Guarding Labels Kit, Part Number L007628. 1-10...
  • Page 23: Specific Precautions During Maintenance Or Repair Work

    • Never look directly into the Laser beam (not even, when wearing protective goggles) • Never expose skin to laser radiation • Never insert flammable materials into the radiation beam. Laser protective goggles, approved for the respective intended purpose can be ordered from Domino. L025317 Issue 1 March 2011 1-11...
  • Page 24: System Naming Conventions

    HEALTH & SAFETY SYSTEM NAMING CONVENTIONS Complete system (laser and controller) Examples: D120i 8 STANDARD BCP7 10W laser head, 10.6μm, i-Tech 8mm scan head, fan cooled, standard BCP7 controller D120i 8 BLUE IP65 STANDARD BCP7 10W laser head, 9.3μm, i-Tech 8mm scan head, IP65, compressed air cooled, standard BCP7 controller D320i 8 BLUE IP65 IP55 BCP7 30W laser head, 9.3μm, i-Tech 8mm scan head, IP65, compressed air cooled,...
  • Page 25: Laser

    HEALTH & SAFETY Laser Examples: D120i 10W laser head, i-Tech 8mm scan head, 10.6μm, fan cooled D120i BLUE IP 10W Laser head, i-Tech 8mm scan head , 9.3μm, compressed air cooled D320i 30W laser head, i-Tech 8mm scan head, 10.6μm, fan cooled D320i BLUE IP 30W Laser head, i-Tech 8mm scan head , 9.3μm, compressed air cooled L025317 Issue 1 March 2011...
  • Page 26: Laser Warning And Information Signs

    HEALTH & SAFETY LASER WARNING AND INFORMATION SIGNS Warning signs are located at specific points on the laser marking system. They correspond to the afore mentioned standards and specify the potential hazards and the required safety measures. These warnings, additional information signs and their locations on the laser marking system are shown in the following illustrations.
  • Page 27 HEALTH & SAFETY Technical data (D) Technical data for D120i Blue Technical data for D120i and D120i Blue IP and D120i IP Technical data for D320i Technical data for D320i Blue and D320i IP and D320i Blue IP Controller branding (example) (E) L025317 Issue 1 March 2011 1-15...
  • Page 28: Location Of Controller Signs

    HEALTH & SAFETY Location of Controller signs Controller rear side (E) 1-16 L025317 Issue 1 March 2011...
  • Page 29: Location Of Laser Signs

    HEALTH & SAFETY Location of Laser signs D-Series 10 and 30 Watt heads L025317 Issue 1 March 2011 1-17...
  • Page 30 HEALTH & SAFETY 1-18 L025317 Issue 1 March 2011...
  • Page 31 PART 2 : INSTALLATION CONTENTS Page UNPACKING AND INVENTORY ..........ASSEMBLY ..................Environmental Conditions ............. Handling the Equipment ..............Laser Head Assembly ............... Removal of the transport locking device ........Control Unit ..................Power supply ................Installing the Main Cable: Controller to Laser ......... ELECTRICAL CONNECTIONS ............
  • Page 32 INSTALLATION FUME EXTRACTION SYSTEM ............ 2-41 GUARDING ..................2-42 INITIAL OPERATION ..............2-42 INSTALLATION WIZARD ............. 2-43 POSITIONING CODE ON THE PRODUCT ........ 2-44 Achieving Maximum Line Speed ............. 2-46 Making marks longer than one field size .......... 2-49 L025317 Issue 1 March 2011...
  • Page 33: Unpacking And Inventory

    INSTALLATION UNPACKING AND INVENTORY Prior to and while unpacking the control unit and laser assembly, visually check for damage that has occurred during transportation, in particular; loose parts, dents, scratches and missing parts. ASSEMBLY CAUTION: The assembly, i.e. the mounting and the installation of the laser marking system must only be performed by personnel qualified for this task and in accordance with the valid regulations...
  • Page 34: Laser Head Assembly

    INSTALLATION Laser Head Assembly The laser head must be mounted correctly on the support profile provided for this purpose (depending on the used laser system). A mechanical de-coupler must be provided to prevent damage to the laser head, or its mounting, during shock or shaking motions of the packaging machine.
  • Page 35: Control Unit

    INSTALLATION Control Unit CAUTION: Do not expose the control unit to any vibrations. The control unit must be installed on a stable base. The control unit has three internal blow-out fuses. The operation voltage is 96V to 264V at 47Hz to 63Hz. Two fuses (F1 and F2) for the input AC power •...
  • Page 36: Installing The Main Cable: Controller To Laser

    INSTALLATION Installing the Main Cable: Controller to Laser Controller front view without main cable Main cable with IP seal Open the controller and insert the main cable into the controller L025317 Issue 1 March 2011...
  • Page 37 INSTALLATION Lock the flange Overview View to the main cble connectors inside the controller front L025317 Issue 1 March 2011...
  • Page 38 INSTALLATION Cable management for the 20 pin IDC connector Cable management for the power connector Close the controller cabinet. Controller with main cable L025317 Issue 1 March 2011...
  • Page 39: Electrical Connections

    INSTALLATION ELECTRICAL CONNECTIONS The following cables are part of the delivered package: • Mains connection cable • Connector plug to the machine control (X4) Type: 12-pole cable socket, solder connection, strain relief PG11 • USB and Ethernet Connections • Connector plugs for X23, X59, X7, X28, X3, X6, X4, X2 , X29, X58 Laser On / Off On/Off Ethernet...
  • Page 40 INSTALLATION Note: To prevent incorrect connections, different male and female connectors have been installed and clearly marked (X...). When connecting the cables, ensure that plugs are correctly connected, to prevent damage to the pins. 2-10 L025317 Issue 1 March 2011...
  • Page 41: Connecting Laser Head Cable To X11

    INSTALLATION Connecting Laser Head Cable to X11 The flange socket (X11) on the laser head is located on the front panel. If the groove on the flange socket is not properly aligned, the cable should be turned, not the plug. Twists in the cable are to be avoided by properly routing the cable.
  • Page 42: X2 Connector Schematic - Beacons

    INSTALLATION X2 Connector Schematic - Beacons 2-12 L025317 Issue 1 March 2011...
  • Page 43 INSTALLATION The D-Series laser marking system offers a DC beacon interface for 24V Domino standard beacons with 4 colours. Connector Type: IEC 60130-9 Type 5 way female Mating Cable Connector (IP67 Types) : • Lumberg: 033205-1 Pin description • Pin 1 BLUE - Blue Lamp +24V Output •...
  • Page 44: X3 Connector Schematic - Product Detector And X6 Connector Schematic - Shaft Encoder

    INSTALLATION X3 Connector Schematic - Product Detector and X6 Connector Schematic - Shaft Encoder 2-14 L025317 Issue 1 March 2011...
  • Page 45 INSTALLATION The product detect interface offers NPN or PNP standard wiring. Different types of product detect sensors (optical, magnetic, etc.) can be connected to this input. A shaft encoder may be connected here. Connector Type: IEC 60130-9 Type 08 way female Mating Cable Connector (IP67 Types) : •...
  • Page 46 INSTALLATION The Shaft Encoder input is directly connected in parallel with the Product Detect Interface. For this reason the electrical specification is identical as well. For the same reason, the standard encoder cable has no “Z” connection in order not to get signal collision with the product detector. If needed e.g. in labeller applications, the isolated leads may be soldered to the scheduled pins, or a fully connected cable (Z- version) may be ordered.
  • Page 47: X4 Connector Schematic - Machine Control

    INSTALLATION X4 Connector Schematic - Machine Control L025317 Issue 1 March 2011 2-17...
  • Page 48 INSTALLATION The machine interface delivers inputs and outputs to control the print process and provides status information. It can be used to communicate with a PLC or to harness external NPN or PNP type control elements. Connector Type: IEC 60130-9 12 way male Mating Cable Connector (IP67 Types) : •...
  • Page 49 INSTALLATION Pin H OUT_+COM - Positive common This pin offers the positive supply input of all output opto couplers. Pin J PRINTER_READY - Laser Ready to Print DC output This output opto coupler is switched on when the printer is ready to print. In multi head systems this pin shows the logical “AND”...
  • Page 50: X7 Connector Schematic - Fume Extraction

    INSTALLATION X7 Connector Schematic - Fume Extraction 2-20 L025317 Issue 1 March 2011...
  • Page 51 INSTALLATION The drawing shows two different ways how to connect a fume extraction system: • with relay or • logic input. Connector Type: IEC 60130-9 Type 6 way male Mating Cable Connector (IP67 Types) : • Lumberg: 032206 Pin description Pin 1 VAC_OK - Extraction system running input A correctly running extraction system delivers a high level signal at this pin.
  • Page 52: X23 Connector Schematic - Rs232 Com1

    INSTALLATION X23 Connector Schematic - RS232 COM1 2-22 L025317 Issue 1 March 2011...
  • Page 53 INSTALLATION Connector Type: IEC 60130-9 Type 8 way male Mating Cable Connector (IP67 Types) : • Lumberg: 032208-1 Pin description • Pin 1 DCD - Data Carrier Detect • Pin 2 TXD - Transmit Data • Pin 3 RXD - Receive Data •...
  • Page 54: X28 Connector Schematic - Air Chiller Control

    INSTALLATION X28 Connector Schematic - Air Chiller Control 2-24 L025317 Issue 1 March 2011...
  • Page 55 INSTALLATION Connector Type: IEC 60130-9 Type 6 way female Mating Cable Connector (IP67 Types) : • Lumberg: 033206 Pin description Pin 1 AIR_OK - Air_OK or Water_Level_OK input A correctly running air system delivers a high level signal at this pin. Input Impedance: 1kOhm;...
  • Page 56: X58 Connector Schematic - Power Extension

    INSTALLATION X58 Connector Schematic - Power Extension Only needed to connect the power extension box for 55 Watt systems. Do not connect anything else to this connector. 2-26 L025317 Issue 1 March 2011...
  • Page 57: X59 Connector Schematic - Ethernet 2 - Remote Panel Interface

    INSTALLATION X59 Connector Schematic - Ethernet 2 - Remote Panel Interface L025317 Issue 1 March 2011 2-27...
  • Page 58 INSTALLATION The second Ethernet interface is used for a remote panel pre-configured to the IP address 192.168.57.2 / subnet mask 255.255.255.0. A Laser Start Input can be connected for laser start by means of a mechanical switch against floating GND (between pin 7 and pin 2) Connector Type: IEC 60130-9 Type 7 way female Mating Cable Connector (IP67 Types) : •...
  • Page 59: Use Of Interlock Loops

    INSTALLATION USE OF INTERLOCK LOOPS Functionality The D-Series Interlock circuit is controlled by a certificated E-Stop relay PNOZ S4 from PILZ. By means of 1 or 2 interlock circuits safety category 2,3 or 4 can be reached. With CAT4 a cross fault monitoring detects shorts between the interlock loops.
  • Page 60: X29 Connector

    INSTALLATION X29 Connector 2-30 L025317 Issue 1 March 2011...
  • Page 61 INSTALLATION PCB Connector Type: IEC 60130-9 Type 7 way male, Mating Cable Connector (IP67 Types) : • Lumberg : 0322 07 Pin description • Pin 1: L1_SOURCE - Positive Interlock Source / +24V floating This pin delivers a current limited 24V source and can only be used to drivePin 2, Pin 3 and Pin 7 of this connector.
  • Page 62: Safety Category 2

    INSTALLATION Safety Category 2 To reach the safety category 2, only one interlock circuit is used. Typically one guard door switch contact controls the interlock circuit. The control wheel needs to be turned to the upper left position as shown in the X29 diagram on page 2-30 (factory setting).
  • Page 63: Timing

    INSTALLATION Timing The next picture shows the general E-Stop Relay timing: L025317 Issue 1 March 2011 2-33...
  • Page 64: Typical Installation Faults

    INSTALLATION Typical installation faults Interlock 1 is connected with guard door 1 and interlock 2 with guard door 2. In this case the principle of redundancy would be violated. Furthermore the operator has to open both doors to make the next relay start possible. Active electronic parts such as transistors or light barriers feed an external voltage into the interlock circuit.
  • Page 65: Compressed Air Connection, Chilling

    INSTALLATION COMPRESSED AIR CONNECTION, CHILLING The Laser Head is equipped with a connection for compressed air with a typical flow rate of 280 litres per minute (10 cubic feet per minute (cfm)) - actual air flow is duty cycle and ambient dependent. This air cools the laser and keeps the objective lens free from dust.
  • Page 66: Connection Of Compressed Air To The Laser

    INSTALLATION Connection of Compressed Air to the Laser WARNING: Maximum operating air pressure is 3.5 bar! Connect the hose from the air installation kit to the laser compressed air inlet. A pressure control valve is at the air inlet. It limits the air flow into the laser cabinet to 450 liters per minute and opens at a supply pressure above 3 bar.
  • Page 67: Air Flow Settings

    INSTALLATION Note: Contact Domino. before disconnecting the silencer or connecting a hose to the air outlet 2 at the laser. If two hoses are used for the compressed air outlets these have always to be seperated from each other and to be placed in differnt ways for safety reasons.
  • Page 68 INSTALLATION D120I AIR FLOW SETTINGS ° D120i Ambient temperature (in C) vs. maximum mark duty cycle (in %) depending on airflow (in LPM) Without chiller 2-38 L025317 Issue 1 March 2011...
  • Page 69 INSTALLATION ° D120i Ambient temperature(in C) vs. maximum mark duty cycle (in %) depending on airflow (in LPM) With chiller L025317 Issue 1 March 2011 2-39...
  • Page 70: D320I Air Flow Settings

    INSTALLATION D320I AIR FLOW SETTINGS All curves are recorded with the original D-Series air kit. The maximum hose length when an air chiller is used is 4 meters form the chiller to the laser head. In this case the air kit is installed between air chiller and laser head. An air chiller type SMC (Modell: IDFA8E) has been used as reference.
  • Page 71: Fume Extraction System

    The DPX1000 is a general purpose fume extraction system that removes particulates. The DPX2000 fume extraction system has an additional filter and a chemical pad to remove odours and toxic gases. The DPX500, DPX1000, DPX1500 and DPX2000 will be equipped with a connector for the Domino D-Series Laser System. WARNING:...
  • Page 72: Guarding

    INSTALLATION GUARDING Guarding must be installed surrounding the laser head marking area in order to achieve a Class 1 installation of this Class 4 laser system (See “CLASS 1 GUARDING”). INITIAL OPERATION WARNINGS: Initial Operation laser marking system must only be performed by qualified personnel and in accordance with all valid regulations and safety instructions.
  • Page 73: Installation Wizard

    INSTALLATION INSTALLATION WIZARD This procedure is for trained personnel only. When logged with password "user4" this installation wizard will not be available to the operator. The Installation Wizard is the simple way to configure the printer. Note: System settings can only be changed after entering the Supervisor password, that is only known by employees authorized to carry out this level of change.
  • Page 74: Positioning Code On The Product

    INSTALLATION POSITIONING CODE ON THE PRODUCT The position of the code on the product depends on two factors: (1) The location of the product detector (print-go), relative to the mark window on the product; and (2) The ‘Encoder Delay’ setting in the software. The D-Series laser can start marking as soon as the print-go signal is received.
  • Page 75 INSTALLATION The encoder delay can be set on a message-by-message basis, which allows a single product detector location to be used for multiple sizes of product or to allow different code locations on products of the same size. To set the encoder delay login as administrator and navigate to: System Setup, Settings, Marking Engine, Marking Mode.
  • Page 76: Achieving Maximum Line Speed

    INSTALLATION Achieving Maximum Line Speed The D-Series includes a feature to extend the marking field when a moving product is marked as it moves past the print head. This feature is used to achieve maximum line speed. Marking mode has to be configured for "Marking on the Fly". Therefore adjust the marking mode via: System Setup, settings, Marking Engine, Marking Mode Screen setup for Marking on the Fly...
  • Page 77 INSTALLATION Example of a setup message to be marked. Marking starts when the marking field of the product is moved into the marking area of the laser. Product movement direction Product Marking field on product Marking area To achieve maximum line speed, the field can be extended behind the marking direction.
  • Page 78 INSTALLATION To extend the marking field in Dynamark 3, move the object in the opposite direction to the movement outside the marking field. Marking starts as the product marking field enters the marking area. Product movement direction Product Marking field on product Marking area Note: Moving the mark on the screen, whether in the real or extended fields, can...
  • Page 79: Making Marks Longer Than One Field Size

    INSTALLATION Making marks longer than one field size By using extended fields it is possible to mark an object that exceeds one field size. The procedure is the same as described previously on extending the marking field in Dynamark 3. Move the marking object out of the real field against the product movement direction and into an extended field.
  • Page 80 INSTALLATION THIS PAGE INTENTIONALLY LEFT BLANK 2-50 L025317 Issue 1 March 2011...
  • Page 81 PART 3 : OPERATION CONTENTS Page D-SERIES LASER MARKING SYSTEM ........WEB-BASED USER INTERFACE ..........D-Series System Schematic ............DYNAMARK SOFTWARE ............. MENU MAP OF DYNAMARK 3 SOFTWARE ......Topic Menu ................... Menu Map of System Setup/Service ..........Menu Map of System Setup/Settings ..........3-10 Menu Map of Global Print Settings ..........
  • Page 82 OPERATION Backup/Restore ................3-24 Create Backup ................3-24 Diagnostics ..................3-25 Printer Version ................3-25 Infoport Status ................3-25 Fonts ....................3-26 Parameter Sets ................3-26 GLOBAL PRINT SETTINGS ............3-27 Clocks .................... 3-27 Configure ..................3-27 Add ....................3-27 Delete ....................
  • Page 83 OPERATION Add ................... 3-38 Configure .................. 3-38 Coding ..................3-38 Upload Coding File ..............3-38 Delete Coding File ..............3-38 Parameter Set ................. 3-39 Standard Parameters ............... 3-40 D120i ..................3-40 D320i ..................3-41 Print Field Offset ................3-42 Setup Aiming ................. 3-43 MESSAGE EDITOR .................
  • Page 84 OPERATION Example 2 ..................3-61 Example 3 ..................3-65 MESSAGE STORE ................3-67 Preview ..................3-67 Load to Editor ................3-67 Send to Printer ................3-67 Message Store ................. 3-68 Change Store ................. 3-68 Delete Store ................... 3-68 Save Editor Message ............... 3-68 Select Message ................
  • Page 85: D-Series Laser Marking System

    OPERATION D-SERIES LASER MARKING SYSTEM D-Series Control unit (IP protected) On/Off Switch Optional (10W and 30W) Laser key switch Touchscreen Compressed Air Scanner Mains Laser Unit Laser Lens Connection Head connector Optional User Interface, Control Unit and Laser Unit with Scanner L025317 Issue 1 March 2011...
  • Page 86: Web-Based User Interface

    A web server installed on the controller allows remote access to the Dynamark 3 software on the controller’s Flash Memory. The Domino browser software installed on the optional Touchscreen can also be installed onto a PC/Laptop. This allows access to the controller via Ethernet connection using a Java-enabled web browser.
  • Page 87: D-Series System Schematic

    OPERATION D-Series System Schematic Laser Unit Laser Control Unit with Web-Server Substrate Human Interface/ Scanner Web Browser Lens & Laser Beam D-Series Schematic diagram DYNAMARK SOFTWARE D-Series Web-based User Interface. The Dynamark 3 control software is password protected. This manual is aimed at password (User4) User level 4.
  • Page 88: Menu Map Of Dynamark 3 Software

    OPERATION MENU MAP OF DYNAMARK 3 SOFTWARE The menu map of Dynamark 3 software is displayed on the next few pages. Use this as a reference to navigate to the various menus and screens Topic Menu Home System Setup Global Print Settings Message Editor Message Store Active Alerts/Logs...
  • Page 89: Menu Map Of System Setup/Service

    OPERATION Menu Map of System Setup/Service System Setup Service Settings Initial Setup Wizard Backup Restore Create Backup Restore From Backup System Update Diagnostics Printer Version Infoport Status Debug Log File Fonts Upload Font Delete Font Parameter Sets Upload Parameter Set Delete Parameter Set Note: Backup/Restore, Diagnostics, Fonts and...
  • Page 90: Menu Map Of System Setup/Settings

    OPERATION Menu Map of System Setup/Settings Settings System Setup Communications Marking Engine Marking Mode Dynamark 3 Interface Encoder Source General PN Transformation TCP/IP RS232 Compiler Options Network Setup Vector Sorting Controller Setup Print Field Panel Setup * Coordinates Orientation Connection Method * Install Options Tube Distortion Optical Correction...
  • Page 91: Menu Map Of Global Print Settings

    OPERATION Menu Map of Global Print Settings Use this map as a reference when setting up or editing Clocks, Counters, Inserts, Variables and Print Field Offsets Global Print Settings Clocks Variables Configure OEM Message Select Delete Parameter Set Control Setting Modify Control Encodings Duplicate...
  • Page 92: Menu Map Of Message Editor

    OPERATION Menu Map of Message Editor Use this map when adding new or editing existing messages. Message Editor Message Settings Insert Field Text Mark on the fly Vector Sorting Shape Maximum Mark Field Usable Mark Field Rectangle Optical Correction Graphic Tube Distortion Upload PN Transformations...
  • Page 93: Menu Map Of Message Editor / Text

    OPERATION Menu Map of Message Editor / Text Use this map when adding or editing text messages. Message Editor Insert Text Modify Insert Text Field Insert Clock Insert Counter Insert Text Insert Insert Variable Insert Coding Insert Text Link Insert Special Character Menu map of the Message Editor Text screens and functions L025317 Issue 1 March 2011...
  • Page 94: Menu Map Of Message Store

    OPERATION Menu Map of Message store Use this map when you need to preview, load, send to printer or manage the messages stored. Message Store Preview Load to Editor Send to Printer Store Manager Change Store Delete Store Create Store Rename Store Save Editor Change Store...
  • Page 95: Menu Map Of Active Alerts/Logs

    OPERATION Menu Map of Active Alerts/Logs Use this map for viewing the Alerts and Logs on the system. Active Alerts/Logs Reset or Mark Enable Logs Status All Details Acknowledge Acknowledge All Most recent/All Status not acknowledged Details Acknowledge Acknowledge All Most recent/All Action Log Menu map of the Active Alerts and Logs...
  • Page 96: Controls And Indicators

    OPERATION CONTROLS AND INDICATORS The User Interface, Indicator Lamps and Software icon functions are described in the following paragraphs: Touchscreen and Interface The software is operated via a PC keyboard, Touchscreen or Web Browser. An entry is confirmed with the left mouse button if PC or Web browser are used.
  • Page 97: Indicator Lamps

    OPERATION Indicator lamps Interlock 1 Interlock 2 Server Running Printer Ready Printer Busy • Interlock 1 - Illuminates when the interlock 1 is closed. • Interlock 2 - Illuminates when all the interlocks are closed. • Server Running - Illuminates when the internal PC is ready. •...
  • Page 98 OPERATION The status LED is a multi-colour LED which indicates: • Green System ready, no errors, no laser operation. • Red Laser operation. Laser operation is indicated elongated to show also short laser operation periods. • Yellow Error or warning. Additonal information may be shown by a flashing yellow LED for service technicians.
  • Page 99: User Levels And Passwords

    The default passwords are "user1", "user2", "user3", and "user4", for user levels 1 to 4. Extended system parameter settings can only be changed after entering the Supervisor password. This password is only known by employees authorised by Domino. Note: If unauthorised changes are performed, the warranty will be invalidated.
  • Page 100: User Interface

    OPERATION USER INTERFACE The user interface is the work area for setting up a message. The User level is displayed in the title bar when logged on. Help Help files are available for all aspects of the Dynamark software and can be accessed by clicking on the icon.
  • Page 101: Topic Menu And User Interface

    OPERATION Topic Menu and User Interface Home System Setup Global Print Settings Message Editor Message Store Active Alerts Close Topic menu Topic Menu USB Icons Screen Number Blue - Touchscreen Red - Control Unit Title Bar Topic Menu Buttons Close Topic Menu Printer...
  • Page 102 OPERATION Connection Status icon Help Button Close Close Topic On-screen Keyboard Keyboard Open Topic Send To Printer Menu Back Button Navigate to Next Screen Marking Mode Enabled Printer Status Tool Bar Icons (ready to print) Typical user interface showing on-screen keyboard, Editor interface, tools and icons Note: The printer is normally connected via a Personal Computer (PC),...
  • Page 103: Switching On And Off

    OPERATION SWITCHING ON AND OFF WARNINGS: The laser marking system must only be used for its intended purpose. The laser marking system may only be operated by trained personel. Operation is only allowed with all required cables connected and all parts mounted. Do not disconnect any cables during operation.
  • Page 104: Start And Stop Marking

    OPERATION START AND STOP MARKING Start Marking Mode Note: If the laser unit is switched off, it must be switched on (see page 3-23). Click on the enable marking mode button at the lower right of the screen. HELP_TAG_SetupBackupUpdate2,1 Stop Marking Mode Clicking on this button will disable the marking mode.
  • Page 105: Diagnostics

    OPERATION Diagnostics The diagnostic screens display the printer version and infoport status for detailed diagnostics and fault finding. HELP_TAG_SetupDiagnostics,1 HELP_TAG_DiagnosticsMain,1 HELP_TAG_InfoportStatus,1 Printer Version Displays the marking controller’s, software version, hardware, I/O hardware, driver module and the software versions of the system on screen. Infoport Status Displays the status of various I/O’s on the printer.
  • Page 106: Fonts

    OPERATION Fonts Displays the fonts loaded on the system. There are options available to upload or delete dst-fonts to the system. HELP_TAG_SetupFonts,1 HELP_TAG_SetupFontsDelete,1 HELP_TAG_SetupParametersDelete,1 Parameter Sets Parameter sets available on the system are displayed on the screen; see below. New Dynamark 3 Parameter Sets can be uploaded or existing ones deleted. HELP_TAG_SetupParameters,1 3-26 L025317 Issue 1 March 2011...
  • Page 107: Global Print Settings

    OPERATION GLOBAL PRINT SETTINGS Note: Global Print Settings are made for all messages. Local settings only apply to current messages in the Editor. Note: All global variables are lost when powering down the controller. Clocks The Clock function is used to enter time and date codes, including expiry dates, into a message.
  • Page 108: Control Settings

    OPERATION Control Settings Julian Leap Day February 29th is marked as either 060 or 366 depending on the toggle setting for the Julian Leap Day. HELP_TAG_SetupClockControls,1 HELP_TAG_SetupClockEncodings,1 Expiry Update Selects between midnight, after last shift and until first shift. After last shift updates the clocks at the end of the last shift even if that shift spans across midnight and into the next day.
  • Page 109: Alpha Day (31) Encoding

    OPERATION Alpha Day (31) encoding Sets the Alpha Day encoding string used by the Alpha Day (31) time component. Defaults to 1234567890ABCDEFGHJKLNPQRSTVXYZ. First component corresponds to the “WEEK BEGIN DAY”. Alpha Month (1) encoding Defines the Alpha Month #1 encoding string used by the Month Letter (M1) time stamp component.
  • Page 110: Shift

    OPERATION Shift The Setup Shifts screen allows the start time of each shift and a shift code to be set. Each shift continues until the start time of the next shift. The OK button includes the shift into the schedule. Configure - The configure button incorporates the entered information into the selected shift.
  • Page 111: Counter

    OPERATION Counter The Add button is used to add a new counter. (1) Click on Add and enter the counter name and click next. (2) Enter the Format String "n" for numerical and "A"for alpha characters, then click Next. (3) Select a Leading Character Mode from the drop down options. None, Blank or Custom.
  • Page 112: Alpha Field String

    OPERATION Alpha Field String Allows editing of the string to be used for the alpha designators in the counters. All alphanumeric characters are available for use in this string. The maximum string length is 26 characters. The default string is A to Z (including all characters).
  • Page 113: Inserts

    OPERATION Inserts The Inserts function sets up and places a text insert into the message. Edit Edit or modify the selected text insert. To add a new insert into a text field, enter a name for the new insert and click next.
  • Page 114: Mode Type

    OPERATION Mode Type Allows selection of the following: Disabled - Disables "Insert" functions. OEM Select - Causes the marking of a text insert based on a binary representation placed on the OEM Select port. Timer - Causes the change of marking a text insert after a fixed elapsed time in seconds.
  • Page 115: Creating A Text Insert

    OPERATION Creating a text insert To create a text insert log in as "User4" from the home screen and select Global Print Settings from the Topic Menu. (1) Select Inserts from the options available. (2) Click Add, to add a new Insert and name the Insert "Insert1" and click Next.
  • Page 116 OPERATION (5) Enter a text length of 4 in the Text Length dialogue box and click Next. (6) Select Insert and then select the option, Insert Before. (7) Enter "Txt1" in the text dialogue box and click OK. 3-36 L025317 Issue 1 March 2011...
  • Page 117: Oem Message Select

    OPERATION (8) Click on the Back button, select Next and OK to complete this example as shown below. OEM Message Select Messages may be activated for printing by a combination of input signals and a strobe signal via the user port. The input signals have to be set before sending the strobe signal (user input H) to the controller.
  • Page 118: Variables

    OPERATION Variables Note: Variables, neither global or local persist after a power cycle. The Setup Variables screen allows variables to be set and named for inclusion in a message. HELP_TAG_EditorInsertVariables,1 HELP_TAG_EditorInsertExternalCoding,1 HELP_TAG_SetupVariables,1 HELP_TAG_SetupVariableAdd,1 HELP_TAG_SetupVariableConf01,1 HELP_TAG_SetupVariableDelete,1 Adds a new variable to the system. HELP_TAG_SetupExternalCodingDelete,1 HELP_TAG_SetupExternalCoding,1 (1) Enter the new variable name.
  • Page 119: Parameter Set

    OPERATION Parameter Set Note: This screen is not available to "User4" password level and is shown here for reference only. Laser Power - Sets the percentage for the optical output of the CO2 laser. Mark Speed - Sets the speed to be used during marking. If the mark appears to be faint, reduce this value (note that this will increase the marking time).
  • Page 120: Standard Parameters

    OPERATION Standard Parameters D120i Default parameters Parameter Laser System D120 i-Tech 8mm Scan head StepPeriod [ μ μ JumpDelay [ μ MarkDelay [ μ PolygonDelay [ μ LaserOffDelay [ μ LaserOnDelay [ MaxVectorLength [mm] 0.25 LaserPower [%] JumpSpeed [bit/ms] 7000 MarkSpeed [bit/ms] 6000 Parameter ranges...
  • Page 121: D320I

    OPERATION D320i Default parameters Parameter Laser System D320 i-Tech 8mm Scan head μ StepPeriod [ JumpDelay [ μ MarkDelay [ μ PolygonDelay [ μ LaserOffDelay [ μ LaserOnDelay [ μ MaxVectorLength [mm] 0.25 LaserPower [%] JumpSpeed [bit/ms] 7000 MarkSpeed [bit/ms] 6000 Parameter ranges Parameter...
  • Page 122: Print Field Offset

    OPERATION Print Field Offset Offset for the print field in x and y direction in mm. HELP_TAG_SetupPrintOffset,1 Note: The message must fit in the usable field, otherwise "Transformation failed" error will occur. 3-42 L025317 Issue 1 March 2011...
  • Page 123: Setup Aiming

    OPERATION Setup Aiming Setup of the aiming beam. The aiming beam may be used for installation to see where the objects of the message are located on the product to print on. Three options are impemented: • Aiming beam disabled •...
  • Page 124: Message Editor

    OPERATION MESSAGE EDITOR The Message Editor is used to build or modify the message content. The Message Editor and Print Parameters are saved with the individual messages. Only one message at a time can be edited and sent to the Printer. After sending the message to the printer (via the web server) a new message may be edited ready to send.
  • Page 125: Objects

    OPERATION Objects Select single Object or Groups of objects Select all Select all objects or individual Objects Button objects for moving or resizing. Property values Select individual properties in the dialogue box to modify their state or value (s) Message Editor Screens Property Values Button showing the Toolbar functions and object property values...
  • Page 126: Delete, Duplicate And Undo Function

    OPERATION Delete, Duplicate and Undo function Undo Button Duplicate button Delete selected object (s) Delete, Duplicate and Undo Button Message Editor Screen showing the Toolbar highlighted for the Delete, Undo and Duplicate function for the selected objects 3-46 L025317 Issue 1 March 2011...
  • Page 127: Alignment Tools

    OPERATION Alignment Tools Distributes selected objects Tool Bar horizontally at a pre-defined distance Centres selected objects horizontally Aligns selected objects to the left edge of the reference object Aligns selected objects to the top edge of the reference object Aligns selected objects to the right edge of the reference object...
  • Page 128: Message Editor Icons

    OPERATION Message Editor Icons Alignment tool button opens the alignment tool bar. Distributes the selected objects horizontally at a pre-defined distance. Centres the selected objects vertically. Aligns the selected objects to the left edge of the reference object. Aligns the selected objects to the top edge of the reference object. Aligns the selected objects to the right edge of the reference object.
  • Page 129: General Property Values

    OPERATION General property values Object Name - Defines the name of the text object, which clearly identifies it for selection in the Object Selection window. Defines marking Parameter parameters for the object. Each object must have a parameter set assigned to it. x-position - Defines the horizontal coordinate of the object in mm.
  • Page 130: Conditional Printing

    OPERATION Conditional Printing For conditional printing the digital inputs needs to be conftgured. While the condition mask only specifies which inputs to look at the condition value needs to be set according to the exact state the inputs shall have in order to mark the object.
  • Page 131: Text Object Properties

    OPERATION Text object properties Key functions for selecting and editing are the same as for the General object properties above. Text - This is the input field for the text. From the Object menu, select Insert New Object - Text Object to open the Text Assistant.
  • Page 132: Object Properties

    OPERATION Object properties Rotation [º] - Rotates the object around the offset cross in clockwise or counter clockwise direction, negative values give counter clockwise rotation. y Angle - Tilts the object into perspective. Positive and negative values in degrees are possible.
  • Page 133: Insert

    OPERATION Insert The Insert function offers the option of entering Text, Machine Readable Code (MRC), Shape (and Arc or Rectangle) or a Graphic into a message on using the Message Editor. Each insertion is descried below. HELP_TAG_EditorTextWizard01,1 HELP_TAG_EditorTextWizard02,1 HELP_TAG_EditorTextWizard03,1 HELP_TAG_EditorTextWizard04,1 HELP_TAG_EditorTextWizard05,1 HELP_TAG_EditorTextWizard06,1 Text Inserts a text string into the message.
  • Page 134: Mrc (Barcodes)

    OPERATION MRC (Barcodes) Inserts machine readable code (MRC) and QR-codes into the message. The property values are the same as the general property values and text property values. MRC Type - Sets the code type, selected from the drop down menu. Resolution (dpi) - Specifies the resolution of the code in dots per inch.
  • Page 135: Shape

    OPERATION Horizontal Alignment - Centres the object horizontally. Vertical Alignment - Centres the object vertically. Mirror x - Mirrors the object horizontally. Mirror y - Mirrors the object vertically. Mark - Prevents/allows the marking of the object. Useful for objects that are only used as a positional aid when creating an object.
  • Page 136: Rectangle

    OPERATION Screen displays the result of entering a property value of 360º, 24 line segements and 1 border line for Arc Rectangle The property values are the same as the general property values and text property values. HELP_TAG_EditorRectangle,1 Border Lines - Sets the number of rectangles. Object Name - Enter a unique name for the object.
  • Page 137: Graphic

    OPERATION Graphic The property values are the same as the general property values and text property values. Note: Monochromous Bitmap (*.bmp), DXF (*.dxf) (up to Version 12, information about 3-dimensional objects is discarded, fonts and labels are not supported) and Hewlett Packard Graphics Language HPGL (*.plt) black white graphic file formats are supported.
  • Page 138: Delete

    OPERATION Delete Deletes the selected object. A prompt is displayed asking if you want to delete the following object. Duplicate Creates a copy of the selected message settings. Message Settings Message settings determine Fields, Mark on the Fly, Vector Sorting and activate useable fields.
  • Page 139: Examples

    OPERATION EXAMPLES These are examples on entering text messages using the Message Editor. Example 1 is for a simple test message "Test1" and example 2 is for a text message "Text2" with more options and various property values assigned to the text message.
  • Page 140 OPERATION (3) Using the delete key remove the default text in the dialogue box and enter "Text1" without the quotes then click OK. Resize the text entered or move the text on the screen to position it where you want by dragging the selection box around the selected text as shown below.
  • Page 141: Example 2

    OPERATION Example 2 To insert a text message "Text2" follow the steps shown for example 1 from step 1 and 2 to log on as "user4" and open the Message Editor for text entry. (1) Using the back key or delete key remove the default text in the dialogue box and enter "Text2"...
  • Page 142 OPERATION (3) Name the object so that properties can be assigned to it as "Text2" and then select the "Parameter Set" to use from the option panel below the object Name dialogue box. The parameter set selected can be modified by clicking on the modify button.
  • Page 143 OPERATION Send to printer Property value Open/Close Property Scroll down dialogue value dialogue (6) With the text selected, open the property value dialogue to set properties of object Text2. Parameter Set is Default, all the other values as follows: • x Position = -12.35, •...
  • Page 144 OPERATION • x Rotation = 20, • y Rotation = 0.00, • Horizontal Alignment = None, • Vertical Alignment = None, • Horizontal Mirror = No, • Vertical Mirror = Yes and • Mark enabled set to Yes and close the property value dialogue. (7) Click on the send to printer button, a send to printer dialogue will appear on screen: "In order to apply your changes, marking will be restarted.
  • Page 145: Example 3

    OPERATION Example 3 To Print a "Best Before" date 31 days from today’s date: (1) From the Topic Menu tab click Message Editor to open the Message Editor screen. (2) Click Next 3 times, then click on Dynamic Text Setup. (3) The screen will display a choice of Clocks, Counter, Inserts and Next, click on Clocks and then click the Add function.
  • Page 146 OPERATION (8) Click on Insert Text Field and then click Insert Clock again for the next entry and select the clock that was created (Best) and click Next. Choose Year(YYYY) CLK_YY from the Clock Component dropdown list and finally OK . The Screen now displays the Text "Best Before:"...
  • Page 147: Message Store

    OPERATION MESSAGE STORE All messages are saved in a Message Store at the controller, from where they can be accessed and opened in the Message Editor. By default, there is one Message Store; further Message Stores can be created and named, subsequently renamed, and deleted through the Store Manager. The software allows only one message to be active in the controller at a time so attempts to open a message when a message is already active requires the operator to respond to a prompt to save the current message.
  • Page 148: Message Store

    OPERATION Message Store The Message Store, Store Manager allows the message store to be changed, deleted, created and renamed. Change Store Allows the user to select and change to another store. Delete Store Allows the user to delete the store. HELP_TAG_MsgStoreSaveMsg,1 HELP_TAG_MsgStoreDeleteStore,1 HELP_TAG_MsgStoreSelectStore,1...
  • Page 149: Select Message

    OPERATION Select Message Allows the user to select a message from the list of messages displayed. Delete Message The selected message can be deleted. A prompt is displayed "Do you really want to delete the message?" requesting confirmation before the message is deleted.
  • Page 150: Active Alerts

    OPERATION ACTIVE ALERTS Logs The software maintains two separate chronological records of the D-Series user activity, the Status log and the Action log. From the Topic Menu on the home screen, press Active Alerts and then Logs. Status panel Severity status icon Status Log The Status messages panel on this screen displays the most recent fault or status condition change.
  • Page 151 OPERATION Press Status - All to display the complete status log: Press Status - Not Acknowledged to display status messages that have yet to be acknowledged: Details - Displays more information of the selected alert status. Acknowledge - Acknowledges a selected or selection of alerts. Acknowledge all - Acknowledges all alerts.
  • Page 152: The Action Log

    OPERATION The Action Log The Action Log stores an action history of each laser status event by time, date, and user status. For example, users logging in and out, marking started and stopped, etc. HELP_TAG_SetupActionLog,1 From the Topic Menu on the Home screen, press Active Alerts, Logs and then Action Log: Export Action Log - Exports the action log history to a USB device.
  • Page 153 PART 4 : TECHNICAL REFERENCE CONTENTS Page CONTROL UNIT WITH TOUCH SCREEN ........ NON IP PROTECTED AND IP PROTECTED CONTROLLER LASER UNIT WITH SCANNER HEAD ........OPTIONS FOR USE ............... D-Series Laser Marking System ............PERFORMANCE DATA ..............CONTROLLER TYPES ..............SPECIFICATION ................
  • Page 154 TECHNICAL REFERENCE THIS PAGE INTENTIONALLY LEFT BLANK L025317 Issue 1March 2011...
  • Page 155: Control Unit With Touch Screen

    TECHNICAL REFERENCE CONTROL UNIT WITH TOUCH SCREEN NON IP PROTECTED AND IP PROTECTED CONTROLLER Non IP protected IP protected controller controller version version L025317 Issue 1 March 2011...
  • Page 156: Laser Unit With Scanner Head

    TECHNICAL REFERENCE LASER UNIT WITH SCANNER HEAD Non IP protected IP protected laser laser version version Scanner Head Lens Assembly D-Series laser head L025317 Issue 1March 2011...
  • Page 157: Options For Use

    TECHNICAL REFERENCE OPTIONS FOR USE The D-Series Laser Marking Systems are suited for directly marking objects by material removal, or by changing the colour of the material. All painted, printed or anodised materials can be marked by material removal, giving the marking contrast. We highly recommended that the technical aspects of individual applications are discussed with the manufacturer or the distributor.
  • Page 158: Controller Types

    TECHNICAL REFERENCE CONTROLLER TYPES D120i D320i Controller Type Electrical Requirements: Mains Power: Voltage 100-240VAC 100-240VAC Frequency 50/60Hz 50/60Hz max. Power Consumption 1050VA 1050VA Laser Power: Voltage 30V DC 30V DC max. Current IP 43 Enclosure: Dimensions 371x430x154 371x430x154 (L x W x H) [mm] Cooling fan cooled fan cooled...
  • Page 159: Specification

    TECHNICAL REFERENCE SPECIFICATION D-Series Laser Marking System (10 Watt Versions) D-Series Models D120i 8mm Scan Head 10W (approx. 8W for Blue tube option @ wavelength of Laser Power 9.3μm) Sealed-Off CO Laser, 30,000 hours MTBF Laser Type Wavelength 10.6μm typical (9.3μm as Blue tube option available) Duty Cycle* 100% Maximum Laser On...
  • Page 160: D-Series Laser Marking System (30 Watt Versions)

    TECHNICAL REFERENCE D-Series Laser Marking System (30 Watt Versions) D-Series Models D320i 8mm Scan Head 30W (approx. 20W for Blue tube option @ wavelength of Laser Power 9.3μm) Sealed-Off CO Laser, 30,000 hours MTBF Laser Type Wavelength 10.6μm typical (9.3μm as Blue tube option available) Duty Cyle* 100% Maximum Laser On...
  • Page 161: Installation Dimensions

    TECHNICAL REFERENCE INSTALLATION DIMENSIONS D-Series Control Unit (10W to 30W systems) with elbows fitted for 19" rack mounting (optional) L025317 Issue 1 March 2011...
  • Page 162 TECHNICAL REFERENCE D-Series Control Unit (10W to 30W systems) IP55 version 4-10 L025317 Issue 1March 2011...
  • Page 163 TECHNICAL REFERENCE D-Series 10, 30 Watt Laser Head with i-Tech 8mm scanner, fan cooled Dimensions L025317 Issue 1 March 2011 4-11...
  • Page 164 TECHNICAL REFERENCE D-Series 10 Watt Laser Head with i-Tech 8mm scanner (down), compressed air cooled Dimensions 4-12 L025317 Issue 1March 2011...
  • Page 165 TECHNICAL REFERENCE D-Series 30 Watt Laser Head with i-Tech 8mm scanner (down), compressed air cooled Dimensions L025317 Issue 1 March 2011 4-13...
  • Page 166 TECHNICAL REFERENCE D-Series Standard Scanner orientations 4-14 L025317 Issue 1March 2011...
  • Page 167 TECHNICAL REFERENCE D-Series OEM Scanner orientations L025317 Issue 1 March 2011 4-15...
  • Page 168: Touchscreen

    TECHNICAL REFERENCE TOUCHSCREEN Note: The Touchscreen can be supplied as an optional user interface. Technical Specifications Display 10.4 inch SVGA full colour touch screen Operating System Windows CE Toushscreen Dimensions (mm) 310(W) x 235(H) x 80(D) Touchscreen IP Rating Designed to IP65 Mounting Accessories Full range of brackets Temperature...
  • Page 169: Touchscreen Dimensions

    TECHNICAL REFERENCE TOUCHSCREEN DIMENSIONS 75mm 79mm M5 (X4) (2.95in) (3.11in) 305mm (12.0in) L025317 Issue 1 March 2011 4-17...
  • Page 170 TECHNICAL REFERENCE 4-18 L025317 Issue 1March 2011...
  • Page 171 PART 5 : MAINTENANCE AND FAULT FINDING CONTENTS Page CHECKING FANS AND AIR VENTS ..........Control Unit and Laser Head Fans ..........Laser Head Air Vents ..............CLEANING THE LENS ..............GENERAL CLEANING ..............FAULT FINDING ................STATUS MESSAGES AND SUGGESTED ACTIONS ....System Status Messages ..............
  • Page 172 MAINTENANCE AND FAULT FINDING THIS PAGE INTENTIONALLY LEFT BLANK L025317 Issue 1 March 2011...
  • Page 173: Checking Fans And Air Vents

    MAINTENANCE AND FAULT FINDING CHECKING FANS AND AIR VENTS WARNING: Before undertaking any work on the laser marking system, remove the mains power plug. The fans are located at the sides of the control unit and on the laser head. A fan defect immediately poses a danger of overheating that may result in damage to the control unit and laser head, therefore the fans must be checked once a month.
  • Page 174: General Cleaning

    It can be assumed that the D-Series laser systems should require no service when properly operated. However, should there ever be a fault, service employees of Domino are at your service. For service assistance please visit the following website http://www.domino-printing.com and use the Global Map to search for local technical support.
  • Page 175: Status Messages And Suggested Actions

    DSP boards are all connected, request. restore backup, restart the controller. Laser watchdog The laser has been Contact Domino. fault firing for longer than expected. Print go while A print go trigger has Check that the print go signal printing.
  • Page 176 List buffer repeat Internal Fault. Restart the system, re-store count fail. backup. Contact Domino. Maximum print The maximum Check the sensor is set up to print distance distance between correctly, disable this function exceeded.
  • Page 177 MAINTENANCE AND FAULT FINDING Status Message Cause Suggested Action Scanhead The scanhead is cold. Wait for the heaters in the temperature out scanner motors to warm the of valid range. scanners, the printer can be used but you may experience very minor position errors .
  • Page 178 561 Laser power not The mains to the Contact Domino. disabled safety relay could not be switched off . 562 Laser DC power Laser DC supply Check the output from the...
  • Page 179 MAINTENANCE AND FAULT FINDING Status Message Cause Suggested Action 564 TRIAC shorted The safety circuit Contact Domino. triac or the by-pass relay is short circuit 565 TRIAC not The safety circuit Contact Domino. working triac is open circuit so The unit is working in a mains power cannot failsafe mode now.
  • Page 180 (CAT3/4) interlocks where not closed. 600 Irregular Laser The laser did not stop Contact Domino Off Procedure when the DSP expected it to. 601 Laser Off Delay Laser parameter Contact Domino...
  • Page 181 MAINTENANCE AND FAULT FINDING Status Message Cause Suggested Action 602 Laser Off Delay Laser parameter Contact Domino Retriggered misconfiguration in message. 603 Laser On Delay Laser parameter Contact Domino Retriggered misconfiguration in message. 604 I2C Sensor Bus Hardware Contact Domino...
  • Page 182 Please check if all message error (software- verification has failed. parameters are correctly set - if bug) yes please contact Domino . 3166 Cannot mark The system is Use a message with data in it. empty message configured not to...
  • Page 183 Suggested Action 3167 Compile-error Internal software Please check if all message verification has failed. parameters are correctly set - if yes please contact Domino . 3168 Transformation Objects or parts of Position objects correctly. failed/object out objects are located of bounds.
  • Page 184 "Disable Marking" configured if they reach their end value. 3180 Print failed. General fault. Contact Domino. 3181 DSP failure. The DSP hardware Ensure that the boards are cannot be contacted fitted correctly.
  • Page 185 MAINTENANCE AND FAULT FINDING Status Message Cause Suggested Action 3188 Barcode Error General software Contact Domino. Error in fault. embedded code. 3189 Barcode Error General software Contact Domino. Generated line fault. with less than 1 unit. 3190 Barcode Error General software Contact Domino.
  • Page 186 MAINTENANCE AND FAULT FINDING Status Message Cause Suggested Action 3203 Barcode Error! The MRC Check the text is valid for this Code-Creation generation cannot MRC type. failed create a pattern for this text. 3204 Barcode Error! The MRC Check the text is valid for this Pattern-Creation generation cannot MRC type.
  • Page 187 MAINTENANCE AND FAULT FINDING Status Message Cause Suggested Action 3216 Unknown HPGL The HPGL code of Make sure that a supported code the vector graphics version of the HPGL file file (PLT file) is format is used. unknown. 3217 No Message The requested action Select a message and send it to cannot be performed...
  • Page 188 MAINTENANCE AND FAULT FINDING Status Message Cause Suggested Action 3224 Invalid Setup The system setup is Check message setup, create a inconsistent (some new message. settings don't fit to others). 3225 Batch finished A batch (e.g. coding Load another coding file or set from a file) has been the line number within the finished printing.
  • Page 189 Domino to fitted to the laser deactivate it. controller - only a service user can now log into the system.
  • Page 190 MAINTENANCE AND FAULT FINDING Status Message Cause Suggested Action 4006 Dongle expired The service dongle Contact Domino. has expired (some dongles have a limited life time in order to prohibit illegal usage). 4007 Dongle is about The service dongle is Contact Domino.
  • Page 191: Replacing The Lens

    MAINTENANCE AND FAULT FINDING REPLACING THE LENS WARNINGS: Before undertaking any work on the laser marking system, remove the mains power plug. This procedure is to be performed by fully trained engineers only. The lens must not come in contact with unprotected skin (health hazard).
  • Page 192: Changing The Fuses

    MAINTENANCE AND FAULT FINDING CHANGING THE FUSES WARNINGS: Before undertaking any work on the laser marking system, remove the mains power plug. This procedure is to be performed by fully trained engineers only. Two pole fuses are used. Main Power Fuses F1 and F2 If fuse is blown, replace with the same type: •...
  • Page 193: Changing The Pc-Cmos Setup Battery

    MAINTENANCE AND FAULT FINDING CHANGING THE PC-CMOS SETUP BATTERY WARNINGS: Before undertaking any work on the laser marking system, remove the mains power plug. This procedure is to be performed by fully trained engineers only. There is danger of the battery exploding if replaced incorrectly, so follow this procedure.
  • Page 194: Status Leds

    MAINTENANCE AND FAULT FINDING STATUS LEDS Inside the controller, some LEDs display the status of the electronics. On the DIB board directly on the front: Name Colour Location Function green DIB-PCB Product Detect green Mark suppress Control green Encoder Channel A green Laser Fan Frequency yellow...
  • Page 195: Fume Extraction System

    MAINTENANCE AND FAULT FINDING FUME EXTRACTION SYSTEM WARNINGS: Only use genuine Domino replacement parts. Any other parts may not meet the design or working requirements and put personnel at risk. Opening the cabinet door while the extraction system is in operation will stop the extraction process (see procedure below).
  • Page 196: Changing Filter Bags

    MAINTENANCE AND FAULT FINDING Changing Filter Bags WARNINGS: (1) Full protective clothing must be worn and correct disposal methods used immediately. Filters must be changed in accordance with the instruction sheet provided with the filter kit. Note: Filter alerts may be caused by debris build up in the extraction nozzle, hose, air inlet or sense line in the air inlet.
  • Page 197: Changing The Chemical Filter (Dpx2000)

    MAINTENANCE AND FAULT FINDING (6) Insert the new main filter into the machine ensuring that the filter label is in front and the airflow arrow is pointing up. (7) Turn the filter locking handle 180° clockwise, so that it is horizontal and in the filter locked position.
  • Page 198 MAINTENANCE AND FAULT FINDING 5-28 L025317 Issue 1 March 2011...
  • Page 199 APPENDIX A: MARKING FONTS CONTENTS Page 1LS-Arabic ..................1LS-Arabic (Cont) ................. 1LS-Arial NC ................1LS-Arial NC (Cont) ..............1LS-Arial ..................1LS-Arial-(Cont) ................1LS-Arial (Cont) ................1LS-Arial (Cont) ................A-10 1LS-Arial (Cont) ................A-11 1LS-Arial (Cont) ................A-12 1LS-Arial (Cont) ................A-13 1LS-Arial (Cont) ................
  • Page 200 APPENDIX - FONTS 2LS-Arial (Cont) ................A-34 2LS-Arial (Cont) ................A-35 2LS-Arial (Cont) ................A-36 2LS-Arial (Cont) ................A-37 2LS-Arial (Cont) ................A-38 2LS-Arial (Cont) ................A-39 2LS-Folio ..................A-40 2LS-Folio (Cont) ................A-41 2LS-Folio (Cont) ................A-42 2RLS Japanese ................A-43 2RLS Korean .................
  • Page 201: 1Ls-Arabic

    APPENDIX - FONTS 1LS-Arabic " & < > • • • • • • • • • • • • • • • • • • • L025317 Issue 1 March 2011...
  • Page 202: 1Ls-Arabic (Cont

    APPENDIX - FONTS 1LS-Arabic (Cont) • • • • • • • • • • ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ® ¯ ° ± ² ³ ´ µ ¶ · ¸ º » ¼...
  • Page 203: 1Ls-Arial Nc

    APPENDIX - FONTS 1LS-Arial NC " & < > • • • • • • • • • • • • • • • • • • • L025317 Issue 1 March 2011...
  • Page 204: 1Ls-Arial Nc (Cont

    APPENDIX - FONTS 1LS-Arial NC (Cont) • • • • • • • • • • ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ® ¯ ° ± ² ³ ´ µ ¶ · ¸ ¹ º...
  • Page 205: 1Ls-Arial

    APPENDIX - FONTS 1LS-Arial " & < > ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ® ¯ ° ± ² ³ L025317 Issue 1 March 2011...
  • Page 206: 1Ls-Arial-(Cont

    APPENDIX - FONTS 1LS-Arial-(Cont) ´ µ ¶ · ¸ ¹ º » ¼ ½ ¾ ¿ À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í Î Ï Ð Ñ Ò Ó Ô Õ Ö × Ø...
  • Page 207: 1Ls-Arial (Cont

    APPENDIX - FONTS 1LS-Arial (Cont) • • • • • • • • • • • ı • • • • • • • • • • • • • • • Ł ł • • • • • • •...
  • Page 208: 1Ls-Arial (Cont

    APPENDIX - FONTS 1LS-Arial (Cont) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 209: 1Ls-Arial (Cont

    APPENDIX - FONTS 1LS-Arial (Cont) 1075 1076 1077 1078 1079 1080 • • • • • • 1081 1082 1083 1084 1085 1086 • • • • • • 1087 1088 1089 1090 1091 1092 • • • • • •...
  • Page 210: 1Ls-Arial (Cont

    APPENDIX - FONTS 1LS-Arial (Cont) 1583 1584 1585 1586 1587 1588 • • • • • • 1589 1590 1591 1592 1593 1594 • • • • • • 1600 1601 1602 1603 1604 1605 • • • • • •...
  • Page 211: 1Ls-Arial (Cont

    APPENDIX - FONTS 1LS-Arial (Cont) 1713 1714 1715 1716 1717 1718 • • • • • • 1719 1720 1721 1722 1723 1724 • • • • • • 1725 1726 1727 1728 1729 1730 • • • • • •...
  • Page 212: 1Ls-Arial (Cont

    APPENDIX - FONTS 1LS-Arial (Cont) 3626 3627 3628 3629 3630 3631 • • • • • • 3632 3633 3634 3635 3636 3637 • • • • • • 3638 3639 3640 3641 3642 3647 • • • • • •...
  • Page 213: 1Ls-Arial - Fast

    APPENDIX - FONTS 1LS-Arial - fast " & < > • • • • • • • • • • • • • • • • • • • L025317 Issue 1 March 2011 A-15...
  • Page 214: 1Ls-Arial - Fast (Cont

    APPENDIX - FONTS 1LS-Arial - fast (Cont) ¢ ¦ § ¨ ª « ¬ ® ¯ ± µ ¶ ¸ ¹ º » À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í Î Ï Ð Ñ...
  • Page 215: 1Ls-Chinese-1

    APPENDIX - FONTS 1LS-Chinese-1 A full Unicode 1LS-Chinese-1 Generic font set (approximately 10,000 characters) is also available. L025317 Issue 1 March 2011 A-17...
  • Page 216: 1Ls-Chinese-2

    APPENDIX - FONTS 1LS-Chinese-2 A full Unicode 1LS-Chinese-2 Generic font set (approximately 10,000 characters) is also available. A-18 L025317 Issue 1 March 2011...
  • Page 217: 1Ls-Dot Matrix

    APPENDIX - FONTS 1LS-Dot Matrix < > 8364 L025317 Issue 1 March 2011 A-19...
  • Page 218: 1Ls-Ocr-A

    APPENDIX - FONTS 1LS-OCR-A • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • " & < > A-20 L025317 Issue 1 March 2011...
  • Page 219: 1Ls-Ocr-A (Cont

    APPENDIX - FONTS 1LS-OCR-A (Cont) • • • • • • • • • • • • ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ® ¯ ° ± ² ³ ´ µ ¶ · ¸ ¹...
  • Page 220 APPENDIX - FONTS 1LS-OCR-A (Cont) ú û ü ý þ ÿ 8364 A-22 L025317 Issue 1 March 2011...
  • Page 221: 1Ls-Ocr-B-10 Bt

    APPENDIX - FONTS 1LS-OCR-B-10 BT " & < > • • • • • • Ä Ð Ö Ü ß ä ï 8364 ö ü L025317 Issue 1 March 2011 A-23...
  • Page 222: 1Ls-Pet Nc

    APPENDIX - FONTS 1LS-PET NC " & < > • • • • • • • • • • • • • • • • • • • A-24 L025317 Issue 1 March 2011...
  • Page 223: 1Ls-Pet Nc (Cont

    APPENDIX - FONTS 1LS-PET NC (Cont) • • • • • • • • • • ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ® ¯ ° ± ² ³ ´ µ ¶ ¸ ¹ º »...
  • Page 224: 2Lcs-Helvetica

    APPENDIX - FONTS 2LCS-Helvetica • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • " & < > A-26 L025317 Issue 1 March 2011...
  • Page 225: 2Lcs-Helvetica (Cont

    APPENDIX - FONTS 2LCS-Helvetica (Cont) • • • • • • • • • • • • • • • • • • • • • • ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ® ¯...
  • Page 226 APPENDIX - FONTS 2LCS-Helvetica (Cont) ð ñ ò ó ô õ ö ÷ ø ù ú û 8364 ü ý þ ÿ A-28 L025317 Issue 1 March 2011...
  • Page 227: 2Ls-Arial Nc

    APPENDIX - FONTS 2LS-Arial NC • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • " & < > L025317 Issue 1 March 2011 A-29...
  • Page 228: 2Ls-Arial Nc (Cont

    APPENDIX - FONTS 2LS-Arial NC (Cont) • • • • • • • • • • • • • • • • • • • • • • • • • ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª...
  • Page 229 APPENDIX - FONTS 2LS-Arial NC (Cont) í î ï ð ñ ò ó ô õ ö ÷ ø ù ú û ü ý þ 8364 ÿ L025317 Issue 1 March 2011 A-31...
  • Page 230: 2Ls-Arial

    APPENDIX - FONTS 2LS-Arial " & < > ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ® ¯ ° ± ² ³ A-32 L025317 Issue 1 March 2011...
  • Page 231: 2Ls-Arial (Cont

    APPENDIX - FONTS 2LS-Arial (Cont) ´ µ ¶ · ¸ ¹ º » ¼ ½ ¾ ¿ À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í Î Ï Ð Ñ Ò Ó Ô Õ Ö ×...
  • Page 232: 2Ls-Arial (Cont

    APPENDIX - FONTS 2LS-Arial (Cont) • • • • • • • • • • • ı • • • • • • • • • • • • • • • Ł ł • • • • • • •...
  • Page 233 APPENDIX - FONTS 2LS-Arial (Cont) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 234: 2Ls-Arial (Cont

    APPENDIX - FONTS 2LS-Arial (Cont) 1083 1084 1085 1086 1087 1088 • • • • • • 1089 1090 1091 1092 1093 1094 • • • • • • 1095 1096 1097 1098 1099 1100 • • • • • •...
  • Page 235: 2Ls-Arial (Cont

    APPENDIX - FONTS 2LS-Arial (Cont) 1594 1600 1601 1602 1603 1604 • • • • • • 1605 1606 1607 1608 1609 1610 • • • • • • 1611 1612 1613 1614 1615 1616 • • • • • •...
  • Page 236: 2Ls-Arial (Cont

    APPENDIX - FONTS 2LS-Arial (Cont) 1723 1724 1725 1726 1727 1728 • • • • • • 1729 1730 1731 1732 1733 1734 • • • • • • 1735 1736 1737 1738 1739 1740 • • • • • •...
  • Page 237: 2Ls-Arial (Cont

    APPENDIX - FONTS 2LS-Arial (Cont) 3636 3637 3638 3639 3640 3641 • • • • • • 3642 3647 3648 3649 3650 3651 • • • • • • 3652 3653 3654 3655 3656 3657 • • • • • •...
  • Page 238: 2Ls-Folio

    APPENDIX - FONTS 2LS-Folio • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • " & < > A-40 L025317 Issue 1 March 2011...
  • Page 239: 2Ls-Folio (Cont

    APPENDIX - FONTS 2LS-Folio (Cont) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • ¡ ¢ £ ¤...
  • Page 240 APPENDIX - FONTS 2LS-Folio (Cont) å æ ç è é ê ë ì í î ï ð ñ ò ó ô õ ö ÷ ø ù ú û ü 8364 ý þ ÿ A-42 L025317 Issue 1 March 2011...
  • Page 241: 2Rls Japanese

    APPENDIX - FONTS 2RLS Japanese L025317 Issue 1 March 2011 A-43...
  • Page 242: 2Rls Korean

    APPENDIX - FONTS 2RLS Korean A-44 L025317 Issue 1 March 2011...
  • Page 243: 2Ls-Romi

    APPENDIX - FONTS 2LS-Romi • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • " & < > L025317 Issue 1 March 2011 A-45...
  • Page 244: 2Ls-Romi (Cont

    APPENDIX - FONTS 2LS-Romi (Cont) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • ¡ ¢ £ ¤...
  • Page 245 APPENDIX - FONTS 2LS-Romi (Cont) å æ ç è é ê ë ì í î ï ð ñ ò ó ô õ ö ÷ ø ù ú û ü 8364 ý þ ÿ L025317 Issue 1 March 2011 A-47...
  • Page 246: 2Rls Simplified Chinese

    APPENDIX - FONTS 2RLS Simplified Chinese A-48 L025317 Issue 1 March 2011...
  • Page 247: 2Rls Traditional Chinese

    APPENDIX - FONTS 2RLS Traditional Chinese L025317 Issue 1 March 2011 A-49...
  • Page 248: 3Ls-Rom

    APPENDIX - FONTS 3LS-Rom • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • " & < > A-50 L025317 Issue 1 March 2011...
  • Page 249: 3Ls-Rom (Cont

    APPENDIX - FONTS 3LS-Rom (Cont) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • ¡ ¢ £ ¤...
  • Page 250 APPENDIX - FONTS 3LS-Rom (Cont) å æ ç è é ê ë ì í î ï ð ñ ò ó ô õ ö ÷ ø ù ú û ü 8364 ý þ ÿ A-52 L025317 Issue 1 March 2011...
  • Page 251: 3Ls-Romi

    APPENDIX - FONTS 3LS-Romi • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • " & < > L025317 Issue 1 March 2011 A-53...
  • Page 252: 3Ls-Romi (Cont

    APPENDIX - FONTS 3LS-Romi (Cont) • • • • • • • • ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ® ¯ ° ± ² ³ ´ µ ¶ · ¸ ¹ º » ¼ ½...
  • Page 253 APPENDIX - FONTS 3LS-Romi (Cont) 8364 þ ÿ L025317 Issue 1 March 2011 A-55...
  • Page 254: 5Ls-Arial

    APPENDIX - FONTS 5LS-Arial • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • " & < > A-56 L025317 Issue 1 March 2011...
  • Page 255: 5Ls-Arial (Cont

    APPENDIX - FONTS 5LS-Arial (Cont) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • ¡ ¢ £ ¤...
  • Page 256 APPENDIX - FONTS 5LS-Arial (Cont) 8364 û ü ý ÿ A-58 L025317 Issue 1 March 2011...
  • Page 257 APPENDIX B: BARCODES CONTENTS Page BARCODE TYPES SUPPORTED ..........1-D Barcodes ................2-D Barcodes ................. L025317 Issue 1 March 2011...
  • Page 258 APPENDIX BARCODES THIS PAGE INTENTIONALLY LEFT BLANK L025317 Issue 1 March 2011...
  • Page 259 APPENDIX BARCODES BARCODE TYPES SUPPORTED 1-D Barcodes In the table below, the types of 1-D barcodes supported by Dynamark 3 are summarised, with the type and number of characters specified for that barcode type. The term "any" means capital letter and number characters; in some cases additional characters are defined, but lower case letters are not permitted.
  • Page 260 APPENDIX BARCODES Code Type No. of Characters Check Digit EAN13 13 numbers 1 of the 13 EAN13+2 15 numbers 1 of the 15 EAN13+5 18 numbers 1 of the 18 EAN14 automatic EAN128 automatic ITF-6 6 numbers 1 (EAN optional) ITF-14 14 numbers 1 (EAN optional)
  • Page 261 APPENDIX BARCODES 2-D Barcodes The following types of 2-D codes are supported within Dynamark 3 software: Barcode Type Details Codablock F Stacked 2-44 rows of 1-61 characters per row PDF417 Stacked Up to 1848 different patterns PDF417 Truncated Stacked QR Code 4296 Alphanumeric Matrix 2/5 Matrix...
  • Page 262 APPENDIX BARCODES L025317 Issue 1 March 2011...
  • Page 263 INDEX general 5-4 Numerics 1-D Barcodes B-3 lens 5-3 2-D Barcodes B-5 Clocks setting 3-27 Accessible laser radiation 1-7 Coding 3-38 Aiming Compressed Air Connection 2-34 setup 3-43 Conditional Printing 3-50 Air Vent 5-3 Connecting Flange Sockets 2-11 Algorithm 3-57 Control keys 3-16 Alignment 3-47, 3-51 Control Unit 2-5...
  • Page 264 INDEX Icons 3-48 Indicators 3-17 Message Store 3-67 Initial Operation 2-42 Installation dimensions 4-9 Name 3-49 Installation Wizard 2-43 Number of lines 4-5 Inv. line flow 3-51 Object Inverse 3-54, 3-57 properties 3-52 IP Rating 2-3 OEM 3-37 Italics 3-51 Offset 3-42 Julian Day 3-28 Offset Adjustment 2-44...
  • Page 265 INDEX Shift Code 3-30 Text Object Signs properties 3-51 controller Touchscreen 4-3 locations 1-16 Transport locking device 2-4 laser UI 3-16 locations 1-17 USB Port 2-11 Size and spacing 4-5 User Requirements 1-3 Special object properties 3-52 Specific Dangers 1-7 Variables 3-38 Speed of object 4-5 Ventilation fans 2-42...
  • Page 266 INDEX Index-4 L027970 Issue 2 March 2011...

This manual is also suitable for:

D120iD320i

Table of Contents

Save PDF
