- Page 1 TE-CD 18/40 Li-i BL Original operating instructions Cordless Hammer Drill/Screwdriver Art.-Nr.: 45.137.33 I.-Nr.: 11018 Anl_TE_CD_18_40_Li_i_BL_SPK7.indb 1 Anl_TE_CD_18_40_Li_i_BL_SPK7.indb 1 31.10.2018 15:20:53 31.10.2018 15:20:53...
- Page 2 - 2 - Anl_TE_CD_18_40_Li_i_BL_SPK7.indb 2 Anl_TE_CD_18_40_Li_i_BL_SPK7.indb 2 31.10.2018 15:20:53 31.10.2018 15:20:53...
- Page 3 - 3 - Anl_TE_CD_18_40_Li_i_BL_SPK7.indb 3 Anl_TE_CD_18_40_Li_i_BL_SPK7.indb 3 31.10.2018 15:20:55 31.10.2018 15:20:55...
-
Page 4: Table Of Contents
Table of contents 1. Safety regulations 2. Layout and items supplied 3. Proper use 4. Technical data 5. Before starting the equipment 6. Operation 7. Cleaning, maintenance and ordering of spare parts 8. Disposal and recycling 9. Storage 10. Charger indicator - 4 - Anl_TE_CD_18_40_Li_i_BL_SPK7.indb 4 Anl_TE_CD_18_40_Li_i_BL_SPK7.indb 4... - Page 5 Danger! - Read the operating instructions to reduce the risk of inquiry Caution! Wear ear-muff s. The impact of noise can cause damage to hearing. Caution! Wear a breathing mask. Dust which is injurious to health can be generated when working on wood and other materials.
-
Page 6: Safety Regulations
• Danger! Open the packaging and take out the equip- When using the equipment, a few safety pre- ment with care. • cautions must be observed to avoid injuries and Remove the packaging material and any damage. Please read the complete operating packaging and/or transportation braces (if instructions and safety regulations with due care. -
Page 7: Technical Data
4. Technical data may change according to how the electric equip- ment is used and may exceed the specifi ed value in exceptional circumstances. Voltage supply ........18 V d.c. Idling speed: ......0-400/0-1500 rpm The specifi ed vibration value can be used to Torque settings: ........ -
Page 8: Operation
• bits which are suitable for the purpose and in on the type and length screws used • faultless condition. on the requirements needing to be met by the 3. Always check for concealed electric cables screwed joint. and gas and water pipes when drilling and screwing in walls. -
Page 9: Cleaning, Maintenance And Ordering Of Spare Parts
7. Cleaning, maintenance and 6.7 Battery capacity indicator (Fig. 6 – Item 2) Press the battery capacity indicator switch (a). ordering of spare parts The battery capacity indicator (2) shows the char- ge status of the battery using 3 LEDs. Danger! Always pull out the battery pack before starting All 3 LEDs are lit:... -
Page 10: Disposal And Recycling
8. Disposal and recycling The equipment is supplied in packaging to prevent it from being damaged in transit. The raw materials in this packaging can be reused or recycled. The equipment and its accessories are made of various types of material, such as metal and plastic. -
Page 11: Charger Indicator
10. Charger indicator Indicator status Explanations and actions Red LED Green LED Off Flashing Ready for use The charger is connected to the mains and is ready for use; there is no battery pack in the charger Off Charging The charger is charging the battery pack in quick charge mode. The char- ging times are shown directly on the charger. - Page 12 For EU countries only Never place any electric power tools in your household refuse. To comply with European Directive 2012/19/EU concerning old electric and electronic equipment and its implementation in national laws, old electric power tools have to be separated from other waste and disposed of in an environment-friendly fashion, e.g.
