PCB Piezotronics ICP M109D12 Installation And Operating Manual page 23

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
2
MODEL 060A23
CAPTIVATED FLOATING
CLAMP NUT
1.68 [42.6]
.315 [8.00] HEX
MATERIAL: ST STL
.94 [23.9]
.035 - .040 [.89 - 1.02]
.41 [10.5]
.244 - .250 [6.20 - 6.35]
 
1 .245 - .246 [ 6.22 - 6.25]
1  .319 - .320 [  8.10 - 8.13]
8 CAUTION: DO NOT TOUCH SEAL SURFACE WITH TAP WHEN TAPPING HOLE
7 DIMENSIONS "A" & "B" TO SUIT USER REQUIREMENTS
A
6 KEEP DIMENSION "A" AS SHORT AS POSSIBLE, SEE OPERATING GUIDE FOR OPTIMUM PASSAGE LENGTH
5 THESE DIAMETERS TO BE CONCENTRIC TO WITHIN .001 [.03] TIR
4 SEAL SURFACE SHOULD BE FLAT & FREE OF TOOL MARKS WITH A MINIMUM FINISH OF 63 [1.6] FOR BEST RESULTS
3 DIMENSIONS SHOWN ARE FOR A .850 [21.59] THICK WALL. COUNTERBORE FOR THICKER WALLS
2 RECOMMENDED MOUNTING TORQUE ON .315 [8.00] HEX: 27-32 FT-LB [37-43 N-m]
1
MATERIAL: C-300 MARAGING STEEL
4
3
ELECTRICAL CONNECTOR
COAXIAL 10-32 UNF - 2A
RETAINING RING
M10x1 - 6g
MODEL 082A10 WASHER
.018 [.46] THICK
MATERIAL: C1095
MODEL 065A06 SEAL
 .315 [  8.00] O.D.
.010 [.25] THICK
MATERIAL: 316
 .248 - .249 [  6.30 - 6.32]
1
3
FLUSH INSTALLATION
.850 [21.59] 3
.260 [6.60]
MOUNTING HOLE DIMENSIONS
 
1 3 5 .252± .001 [ 6.40± .03] THRU
 .358 [  9.10] TO DEPTH SHOWN
4 5

8 M10x1.0 - 6H .510 [12.95]
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.01
XXX ±.005
ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH CABLE TOLERANCES IN METRIC
1"≤ LENGTH < 1' = +1"/ - 0
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
30.5cm ≤ LENGTH < 1.5m
5'≤ LENGTH < 100' = +6"/ - 0
1.5m
30.5m ≤ LENGTH
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII
.003 - .005
2
REV
NR
RECESSED INSTALLATION
MOUNTING HOLE DIMENSIONS
3 5  .252± .001 [
 
4 5 .358 [ 9.10] TO DEPTH SHOWN
8 M10x1.0 - 6H  .510 [12.95]
DRAWN CHECKED
DIMENSIONS IN MILLIMETERS
NJF 10/24/22 JDM 10/24/22 NJL
[ IN BRACKETS ]
DECIMALS X ± 0.3
XX ± 0.13
TITLE
ANGLES  2 DEGREES
INSTALLATION DRAWING
MODEL M109 SERIES
= +5.1cm/ - 0
≤ LENGTH < 30.5m = +15.2cm/ - 0
PRESSURE SENSOR
= +30.5cm/ - 0
FILLETS AND RADII
0.07 - 0.13
2
1
REVISIONS
DESCRIPTION DIN
RELEASED TO DRAFTING 53262
B
.850 [21.59] 3
.260 [6.60]
"A" 6 7
 "B" 7
 6.40± .03]  .850 [21.59]
A
ENGINEER
10/24/22
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
77174
IDENT. NO.
52681
SCALE: 3X SHEET 1 OF 1
1
