PCB Piezotronics ICP M109D12 Installation And Operating Manual page 11

Model Number
109D12
Performance
Measurement Range(for ± 7V output)
Sensitivity(± 15 %)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Vibration
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Geometry
Sensing Element
Housing Material
Diaphragm
Sealing
Electrical Connector 10-32 Coaxial Jack
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR
EN GLISH SI
100,000 psi 690,000 kPa
0.07 mV/psi 0.010 mV/kPa
125,000 psi 862,000 kPa
2.0 psi 13.8 kPa
≥ 400 kHz ≥ 400 kHz
≤ 2.0 µ sec ≤ 2.0 µ sec
≤ 2.0 % FS ≤ 2.0 % FS
≤ 0.02 psi/g ≤ 0.015 kPa/(m/s²)
-100 to +275 °F -73 to +135 °C
≤ 0.07 %/°F ≤ 0.126 %/°C
3,000 °F 1,650 °C
2,000 g pk 19,620 m/s² pk
50,000 g pk 490,330 m/s² pk
Positive Positive
> 1,000 sec > 1,000 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
Compression Compression
Quartz Quartz
C-300 C-300
C-300 C-300
Epoxy Epoxy
10-32 Coaxial Jack
0.6 oz 17 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
- Hermetic Seal
H
Housing Material
[1]
Maximum Shock
Sealing
M - Metric Mount
[2]
- Negative Output Polarity
N
W - Water Resistant Cable
N OTES:
[1]Typical.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 065A06 Seal ring 0.318" OD x 0.250" ID x 0.010" thk 316L SS material (3)
Entered: ND Engineer: NJL
Date: 11/28/2022 Date: 11/28/2022 Date: 11/28/2022 Date: 11/28/2022 77296
3425 Walden Avenue, Depew, NY 14043
Revision: NR
ECN #: 53420
OPTION AL VERSION S
17-4 Stainless Steel 17-4 Stainless Steel
20,000 g pk 196,133
Welded Hermetic Welded Hermetic
Sales: RWM Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-M ail: info@ pcb.com
