- Page 1 Manual EN COMTRAXX® COM463BC Gateway for data exchange between the interfaces BCOM and external BMS Software version V4.7.x COM463BC_D00427_02_M_XXEN/09.2023...
- Page 2 COM463BC_D00427_02_M_XXEN/09.2023...
-
Page 3: Table Of Contents
Signs and symbols............................5 Service and Support............................5 Training courses and seminars........................6 Delivery conditions............................6 Inspection, transport and storage......................6 Warranty and liability.............................6 Disposal of Bender devices..........................7 1.10 Safety..................................7 Product description.................... 9 Scope of delivery............................. 9 Device features..............................9 Applications............................... 9 Function................................9... - Page 4 Table of contents 4.4.1 Headline................................18 4.4.2 Path display (breadcrumb navigation)....................18 4.4.3 Navigation................................ 19 4.4.4 Subnavigation..............................19 4.4.5 Content area..............................20 4.4.6 Overview of pending alarms........................20 Virtual devices....................21 Application possibilities..........................21 Managing virtual devices........................... 21 5.2.1 Virtual devices: Overview list/Main page..................... 21 5.2.2 Editing a virtual device..........................
-
Page 5: General Information
Protect from dust Temperature range Recycling RoHS directives Service and Support Information and contact details about customer service, repair service or field service for Bender devices are available on the following website: Fast assistance | Bender GmbH & Co. KG. COM463BC_D00427_02_M_XXEN/09.2023... -
Page 6: Training Courses And Seminars
Regular face-to-face or online seminars for customers and other interested parties: www.bender.de > know-how > seminars. Delivery conditions The conditions of sale and delivery set out by Bender GmbH & Co. KG apply. These can be obtained in printed or electronic format. The following applies to software products: ‘Software clause in respect of the licensing of standard software as part of deliveries,... -
Page 7: Disposal Of Bender Devices
COMTRAXX® COM463BC Disposal of Bender devices Abide by the national regulations and laws governing the disposal of this device. For more information on the disposal of Bender devices, refer to www.bender.de > service & support. 1.10 Safety If the device is used outside the Federal Republic of Germany, the applicable local standards and regulations must be complied with. - Page 8 Intended use The COM463BC connects devices via the interfaces BCOM and external BMS. It is operated and configured using the web user interface integrated into the device. Address setting and termination For proper functioning of the COM463BC correct address assignment and termination is of utmost importance. CAUTION Malfunction due to duplicated addresses Assigning addresses that are already used by existing devices in the bus systems concerned may cause...
-
Page 9: Product Description
The COM463BC gateways are integrated into the existing EDP structure like PCs. After connecting to the network and compatible Bender products, all system devices can be accessed from any PC using a web browser. In this way, all important system information is directly available. -
Page 10: Functional Description
2.5.2 BMS interface External BMS bus (BMSe) Individual Bender devices, such as MK800, TM800 or Bender panels can communicate via the external BMS bus (BMSe). The COM463BC can communicate via the external BMS bus (BMSe). The COM463BC cannot parameterise other bus devices on the external bus. The parameters of the COM463BC itself can, however, be set via the LAN connected. -
Page 11: Mounting, Connection And Commissioning
For more detailed information on the topic of BMS, in particular about the wiring of bus devices, please refer to the separate document "BMS bus". You can obtain this document at https://www.bender.de/en/service-support/download-area/ Does the computer network have a DHCP server? If the connected computer network contains a DHCP server, activate the ‘DHCP’... -
Page 12: Mounting The Device
Mounting, connection and commissioning DANGER Mortal danger and risk of irreparable damage due to moisture! Install device such that it is protected against moisture. CAUTION Pay attention to installation location Operation of the device is only permitted in operating locations with restricted access! This can be installation in a switch cabinet, for example. -
Page 13: Connecting The Device
Explanation A1/+; A2/- Power supply Plug X1 BMS bus (Bender measuring device interface): Terminals ABMS and BBMS Plug X2 Ethernet connection (RJ45) for the connection to the PC network as well as to BCOM BMS bus terminating resistor switch Make the connection as follows: Remove terminal covers of the device. -
Page 14: Wiring Diagram
Mounting, connection and commissioning 3.2.3 Wiring diagram Wiring diagram COM463BC (example) COM463BC_D00427_02_M_XXEN/09.2023... -
Page 15: Display And Control Elements
Risk of duplicate addresses if BCOM system name is not changed. The factory setting for the system name on all Bender BCOM devices is "SYSTEM". If several systems are established in the same network, there is a risk that addresses will be assigned more than once. -
Page 16: Factory Settings For Addresses
Mounting, connection and commissioning – BCOM devices are detected automatically Check connection Connect the COM46… to the network again. Start the web user interface. All other settings (individual texts, e-mail notifications, …) can now be made. Factory settings for addresses The COM463BC is supplied with the following factory settings: Parameter Factory setting... -
Page 17: Web User Interface
Web user interface The web user interface of the device enables access via LAN, WLAN or the Internet. It provides a uniform display of all connected Bender devices. Functions of the web user interface • Bus overview of the associated devices •... -
Page 18: Home Page Comtraxx® User Interface
Web user interface Home page COMTRAXX® user interface Open an Internet browser. Enter the IP address of the gateway in the address line (example: http://172.16.60.72). Headline Path display Navigation Subnavigation Content area Alarm overview 4.4.1 Headline Clicking the logo: Return to home page Used device: Device type Used device: System name >... -
Page 19: Navigation
COMTRAXX® COM463BC 4.4.3 Navigation Menu Description Start Display of information about the device and the software. Please have this information to hand if you need to contact us for assistance by telephone. System overview The system overview shows all devices in the system either by subsystem or by interface. -
Page 20: Content Area
Web user interface 4.4.5 Content area Display of the system, alarms and entries for the tools Content area of the system display by Content area of the system display by subsystem interface 4.4.6 Overview of pending alarms Clicking the alarm overview: List of pending alarms Clicking on the list: Details about the alarms in the content area COM463BC_D00427_02_M_XXEN/09.2023... -
Page 21: Virtual Devices
‘virtual’ measuring point. Each of these measuring points uses one channel. A virtual device consists of a maximum of 16 channels. Virtual devices are treated like real devices and are fully integrated into the Bender system: All calculated values – can be stored in a data logger, –... -
Page 22: Editing A Virtual Device
Virtual devices Mirrored When enabled, the operating states of channels 1…12 of the virtual device are transmitted via BMS bus. 5.2.2 Editing a virtual device Device address, device name and BMS mirroring can be edited. 5.2.3 Editing channels In the channel overview, the 16 possible channels are displayed with the following information: •... - Page 23 COMTRAXX® COM463BC Mirroring to BMS If operating states are to be transmitted via BMS, this can bet set here. Virtual devices are treated like real devices. Therefore, addresses must not be assigned twice! COM463BC_D00427_02_M_XXEN/09.2023...
-
Page 24: Troubleshooting
Document the new settings as a PDF file. Use the backup function to save all settings of the device (see Chapter: “Device features”, Page 9). Frequently asked questions on the Internet FAQs on many Bender devices can be found at: Fast assistance | Bender GmbH & Co. KG Device operation, maintenance, cleaning Maintenance The device does not contain any parts that require maintenance. -
Page 25: Technical Data
COMTRAXX® COM463BC Technical data Tabular data ( )* = Factory setting Insulation coordination in acc. with IEC 60664-1/IEC 60664-3 Rated voltage AC 250 V Rated impulse withstand voltage/overvoltage category 4 kV / III Pollution degree Protective separation (reinforced insulation) between (A1/+, A2/-) - [(ABMS, BBMS), (X2)] Supply voltage Supply voltage U... - Page 26 Technical data Ethernet IP address nnn.nnn.nnn.nnn (192.168.0.254)* can always be reached via 169.254.0.1 Netmask nnn.nnn.nnn.nnn (255.255.0.0)* Protocols TCP/IP, DHCP, SMTP, NTP BMS-Bus (external) Interface/protocol RS-485/BMS external Operating mode master/slave (master)* Baud rate BMS external (19.2 / 38.4 / 57.6) kBit/s Cable length ≤...
- Page 27 COMTRAXX® COM463BC Classification of climatic conditions acc. to IEC 60721 Stationary use (IEC 60721-3-3) 3K22 Transport (IEC 60721-3-2) 2K11 Long-term storage (IEC 60721-3-1) 1K22 Mechanical conditions acc. to IEC 60721 Stationary use (IEC 60721-3-3) 3M11 Transport (IEC 60721-3-2) Long-term storage (IEC 60721-3-1) 1M12 Connection Connection type...
-
Page 28: Standards, Approvals And Certifications
Technical data Screw mounting 3 x M4 Type of enclosure J460 Enclosure material polycarbonate Flammability class UL94V-0 Dimensions (W x H x D) 107.5 x 93 x 62.9 mm Software D0472 Weight ≤ 240 g ( )* = Factory setting Standards, approvals and certifications Ordering information Device... - Page 29 COMTRAXX® COM463BC COM463BC_D00427_02_M_XXEN/09.2023...
- Page 30 COM463BC_D00427_02_M_XXEN/09.2023...
- Page 31 COMTRAXX® COM463BC COM463BC_D00427_02_M_XXEN/09.2023...
- Page 32 Alle Rechte vorbehalten. 35305 Grünberg Nachdruck und Vervielfältigung nur mit Germany Genehmigung des Herausgebers. © Bender GmbH & Co. KG, Germany Subject to change! The specified Tel.: +49 6401 807-0 All rights reserved. standards take into account the edition info@bender.de Reprinting and duplicating only with valid until 09.2023 unless otherwise...
