Summary of Contents for CDA FWC881 Series
- Page 1 FWC881* Wine Cooler Installation, use and maintenance...
-
Page 2: Table Of Contents
Contents Important information Disposal at the end of the appliance's life Before first use and controls Optimal temperature selection and settings mode 11 Dynamic, silent modes and humidity control Sabbath mode, door alarm, interior light Removing the shelves and temperature alarm Care and cleaning Troubleshooting... - Page 3 Important The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment.
-
Page 4: Important Information
Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Declarations of Conformity: This appliance has been manufactured to comply with all EU &... - Page 5 Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin.
-
Page 6: Before First Use
Before first use You must allow the appliance to settle for at least twenty four hours prior to switching the power on. It is recommended that you remove all internal and external packaging and clean the interior of the appliance prior to first use, using a solution of bicarbonate of soda and warm water and then thoroughly dry the interior. - Page 7 Only open the door when necessary. • • Do not cover the shelves with aluminium foil or anything else that will prevent air from circulating around the cabinet. To prevent damage to the door seal, ensure the door is fully open •...
-
Page 8: Use And Controls
Use and controls Key: – Upper zone "+" button 3 – Upper zone "-" button 4 – Lower zone "+" button 5 – Lower zone "-" button 6 – Light button To switch the power on/off Press and hold the power button for one second to switch the •... - Page 9 Optimal temperature selection Whilst wine is best stored at temperatures between 13ºC and 15ºC, your wine can also be stored at drinking temperature, for red wine this is between 15ºC and 17ºC, and for white wine between 12ºC and 13ºC. Wine Type Red Wine 15 - 18ºC (59ºF-64ºF)
- Page 10 2. Use the UP and DOWN keys to select the brightness of the display. The factory default setting is d1. d0: off d1: dimmest setting d2: medium setting d3: brightest setting 3. Touch the POWER key to confirm your selection. 4.
- Page 11 S2: sensor tone OFF, alarm tone OFF S3: sensor tone OFF, alarm tone ON 3. Touch the POWER key to confirm your selection. 4. Touch and hold the UP key for 5 seconds to leave settings mode. Otherwise the appliance exits settings mode automatically after approximately one minute.
- Page 12 Sabbath mode Sabbath mode is available for the observance of certain religious holidays. This will switch off the displays, interior light and audible alarms. The cooling process will continue. To switch the Sabbath mode on, touch and hold the power and light keys simultaneously for five seconds.
- Page 13 Removing the shelves To remove a shelf from the wine cooler, first remove all bottles from the shelf, then pull the shelf forwards until the groove on either side of the shelf is level Fig. 3 with the plastic peg on either side of the cabinet (as shown in fig.
-
Page 14: Care And Cleaning
Care and cleaning Always disconnect the appliance from the mains electrical supply before any cleaning or maintenance. • Do not use abrasive products or detergents. After washing, rinse and dry thoroughly. • The exterior of the appliance and the door seal should be cleaned using mild soapy water and dried thoroughly. -
Page 15: Troubleshooting
Troubleshooting If you have any problems with you rappliance you should check the trouble shooting guide prior to calling CDA Customer Care, to prevent unnecessary service calls and potential cost. If the appliance is not working, check • There is power to the appliance. - Page 16 The light button is not set to off. Please note: The LED lighting cannot be replaced without a service call. If the light fails, contact CDA Customer Care. If the door will not close properly, check • The appliance is level and stable.
-
Page 17: Installation And Ventilation
Installing the wine cooler This appliance is intended to be installed in a space between two Fig. 4 units. The minimum space required is: FWC881 – 595mm wide x 575mm deep x 1850mm high (630 depth with handle) Please note: When the product is installed, there should be a small ventilation gap between the top of the unit and the underside of any fitting above (6 mm or ¼”). - Page 18 To install the handle IMPORTANT: Do not overtighten the screws, and do not use power tools to install the handle. Carefully locate the handle in the required position (this would normally be the higher of the two positions as shown in Fig.
-
Page 19: Reversing The Door
Reversing the door It is possible to reverse the door on this appliance, if required. We recommend Door the help of at least one other individual throughout this process. Protect the area beneath the door with several clean towels or similar protective means. - Page 20 cabinet (Fig.10). Unscrew and transfer the hinge pin (8) and door support (7) to the opposite lower hinge (Fig.8). Unscrew and transfer the door adapter (9) to the designated top positions of the door (Fig.9). Rotate the door 180°° and relocate it to the designated position.
-
Page 21: Fitting The Plinth
Fitting the plinth We recommend the help of at least one other individual throughout this process. Protect the are abeneath the door and plinth with several clean towels or similar protective means. Do not tilt the appliance further than 90°° during this process. -
Page 22: Electrical Information
Electrical information Warning! This appliance must be earthed. The mains lead of this appliance has been fitted with a BS 1363A 13 Amp fused plug. change a fuse in this type of plug, follow the steps below: Remove the fuse cover fuse. - Page 23 As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: • The wire which is coloured GREEN and YELLOW must be connected to the terminal which is marked with the letter (E) or by the Earth symbol or coloured GREEN and YELLOW.
- Page 24 Bottle storage To achieve the most effective preservation of your wine for the longest time possible and avoiding any waste, position the products as shown in the diagrams in this section. In addition, this figure illustrates the layout of drawers, baskets and shelves, which allows the most efficient use of energy.
-
Page 25: Climate Range
Climate Range The information about the climate range of the appliance is provided on the rating plate. It indicates at which ambient temperature (that is room temperature in which the appliance is working) is optimal for the operation of the appliance. Climate class Allowable ambient temperature Extended Temperate... -
Page 26: Notes
Notes... - Page 27 Notes...
- Page 28 For more information please contact: The Sales Department on 01949 862 010 or email sales@cda.co.uk Customer Care Department. The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY 01949 862 012 01949 862 003 customer.care@cda.co.uk www.cda.co.uk...
