JVC LT-55C760 Unpacking Manual

Unpacking
Guide
LT-55C760(A)
TV
Instruction Book
& Quick Start Guide
Accessories TV Feet
Pack
Fitting the Feet
1. Ensure the TV is switched off and not connected to the mains power supply.
2. Keep the protective bag on your TV, it will help to protect the TV.
Lay the TV down on a flat surface ideally on the edge of a table so the base
of the TV slightly overhangs the edge of the table, with the back side facing
up. Please make sure a soft cushioned material (such as a dry bath towel or
thick piece of foam) is placed beneath the screen.
If you don't have a table big enough, you can use the TV box. Lie the box
flat, make sure you place the polystyrene back in the box first to give the
box some rigidity and strength.
3. Position each foot onto the back of the stand. They are marked Left and
Right on the back of each foot. Make sure you slide the lug under the recess.
4. Using 3 of the supplied screws, to screw each foot onto the TV.
• Keep the protective bag on your TV until you have attached the stand
and positioned the TV.
• The LCD display is very fragile, and must be protected at all times
when installing and removing the base stand. Be sure that no hard
or sharp object, or anything that could scratch or damage the LCD
display, comes into contact with it. DO NOT exert pressure on the front
of the TV at any time because the screen could crack.
JVC 55' LED Smart HD TV LT-55C760(A) Unpacking Guide.indd 1
✔
2 people are required
when unpacking your TV.
Right foot Left foot
(when looking from (when looking from
the back of the TV) the back of the TV)
✘
Remove the Protective Bag
Protective
Bag
Table
Cushioned
material
Don't lift the TV from the top
