JVC LT-55K890B Quick Start Manual

Quick Start Guide
55" LED Smart 4K HDR TV
LT-55K890(B)
JVC 55' LED Smart 4K HDR TV LT-55K890(B) Quick Start GB.indd 1-3
Thank you
GB for purchasing your new JVC TV.
Your new TV incorporates the latest technology to enhance your viewing
experience. We would suggest that you allow about 15 mins for initial setup.
Please follow this guide for a successful first time installation.
1
Setup in
What's in the Box?
15mins
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to any local regulations.
TV Remote Control/
AAA Batteries x2
TV Stand Neck
Screws (A) x 5
TV Stand Base
Screws (B) x 6
2
Operating Your Remote Control
1. Slide open the battery compartment on the back of the remote control.
2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of
the batteries with the (+) and ( - ) ends indicated in the battery compartment.
3. Slide the battery compartment cover back into place. Make sure it clicks into place.
For extra safety use the screw supplied to screw the battery compartment closed.
3
Installing the Base Stand
Fitting the Neck and Neck Cover
Together
1. Fit the neck cover over the neck.
2. Using 2 of the supplied screws (A), screw the
neck and neck cover together.
Fitting the Neck and Stand to the TV
3. Ensure the TV is switched off and not connected to
the mains power supply.
4. Lay the TV down on a flat surface ideally on the
edge of a table so the base of the TV slightly
overhangs the edge of the table, with the back side
facing up. Please make sure a soft cushioned
material (such as a dry bath towel or thick piece of
foam) is placed beneath the screen. You can leave
the protective bag on to protect the TV at this point.
5. Slide the Neck and Neck cover under the lip, the
neck will fit snugly over the screw holes. Then screw
the Neck to the TV using the 6 screws (B) supplied.
6. Once the Neck is secure screw the base to the neck
using the 3 screws (A) supplied. Be careful not the
drop the base, its heavy.
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or
anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of the TV at any time because the
screen could crack.
The latest eco-friendly power-saving technology will switch off the TV if
4
it is left on and idle for 4 hours. Please refer to "Auto Standby" under the
"Time Settings" section of the instruction manual for more detail.
Instruction Manual
Please inspect your TV for damage after unpacking. If
Quick Start Guide
you do notice any damage please consult your dealer.
Cushioned
material
A Protective
Table
Bag
A
B
A
Connecting the Aerial and Turning on the TV
1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the other end of the cable to the ANT socket on the back of your TV.
2. Plug the TV into a mains socket and switch on at the mains.
3. In standby mode, press the button on the remote control to turn the TV on. The LED indicator will flash for a few seconds then the TV will switch on.
LAN
LNB
13V dc/18V dc
SPDIF VGA
Optic.OUT
'F Type' connector
(not included)
LAN LNB
13V dc/18V dc
VGA
SPDIF
Optic.OUT
AV IN
RF coaxial cable
(not included)
Router
(not included)
Optional
If you want to connect to the internet via a wired connection
then connect your ethernet cable to the LAN socket.
• Do not connect the TV to the mains supply until you have completed all the connections.
• Always disconnect the TV from the mains socket when not in use for a long period of time.
• The button on the remote control is only used for switching the TV into standby, it does not disconnect the TV from the mains power.
To completely disconnect the mains power, please remove the mains plug from the mains socket.
