- Page 1 AWNINGS POWER AWNING 9200 9200 Series Power Awning Operating Instructions ....3 REVISION B Form No. 3316602.000 2023-07-25...
- Page 2 9200 Series Power Awning Copyright © 2023 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or be patent...
-
Page 3: Table Of Contents
For up-to- date product information, please visit www.dometic.com. 1 .1 Recognize safety information Contents This is the safety alert symbol . It is used to alert Explanation of symbols and safety you to potential physical injury hazards. -
Page 4: Supplemental Directives
2 Intended use product if adjustments or repairs are necessary. Critical parts may include awning fabric, cables, arm The 9200 Series Power Awning (hereinafter referred assemblies, etc. to as awning) is designed and intended for use on a Recreational Vehicle (RV) during or after the RV... -
Page 5: General Information
• Alterations to the product without express permission from the manufacturer • Use for purposes other than those described in this manual Dometic reserves the right to change product appearance and product specifications. 1 Awning switch 3 General information Extend... -
Page 6: Adjusting The Awning Pitch (Optional)
Operation 9200 Series Power Awning 4 .2 Adjusting the awning pitch 3. While holding the top arm assembly in place, tighten the knob. (optional) 4. Repeat these steps for the opposite side. WARNING: Impact and/or crush hazard . Always lower one side of hardware into water shed 4 .3 Preparing the awning to shed... -
Page 7: Closing The Awning
9200 Series Power Awning Operation 4 .5 Preparing the awning for travel The slope requirement is in addition to the slope from the RV’s awning rail. WARNING: Impact, crush, and/or projectile hazard . Failure to obey the following warnings 4 .4 Closing the awning could result in death or serious injury . -
Page 8: Closing The Awning Manually
Maintenance 9200 Series Power Awning 5 Maintenance 4 .6 Closing the awning manually WARNING: Electric shock hazard . Disconnect product from power supply (if applicable), and do not operate product when maintenance (such as window cleaning) is being carried out in the vicinity. Failure to obey this warning could result in death or serious injury. -
Page 9: Maintaining The Hardware
9200 Series Power Awning Maintenance 5 .1 Maintaining the hardware 13 Cleaning awning fabric 11 Lubricating fabric roller tube assembly To clean the fabric: 1. Open the awning. Silicone spray Fabric roller tube assembly 2. Mix 2 fl oz (59 ml) dish soap and 2 fl oz (59 ml) bleach 1. -
Page 10: Repairing The Fabric
3. Make sure the VLP is dry before closing the awning. VLP is available from Dometic Corporation. Disposal Place the packaging material in the appropriate recycling waste bins, whenever possible. - Page 11 9200 Series Power Awning...
