Emergency Stop

The emergency stop may only be used in an emergency.
When the emergency stop is activated, all functions are stopped.
To reset the emergency stop, turn clockwise until the push button lifts and restores.
Down
Press and hold the button to lower the lift platform. The door must be completely closed
before.
Up
Hold the button down for the lift platform to go up. The door must be completely closed
before.
Overload
If the red light labeled (ALARM) is lit on the panel, the weight is on the lift exceeded, the lift
cannot be used until the load on the platform has been reduced.
Error indication
The lamp lights up in the event of a fault, contact your distributor.
1 blink = activation of synchronization
2 flashes = overcurrent
3 flashes = no pulses detected
4 flashes = motor position difference too large (synchronization error)
5 flashes = overvoltage
6 flashes = error in the cable security
Power failure
In the event of a power failure, a light on the front labeled (BATTERY) is activated
The automatic emergency lowering unit is activated in the event of a power failure, the lift
can still be used but only in the downward direction.
which shows that the lift now only has access to battery voltage.
Emergency signal
Tech Lift M4 is equipped with an emergency signal to call attention in the event of a
breakdown or other emergency.
