- Page 1 Maintenance Manual coatmaster Flex V2 ® These operating instructions describe the individual steps of an annual coatmaster® Flex maintenance based on a photo documentation.
- Page 2 Subject to technical changes and printing errors. The data given are approximate values and are not to be understood as warranted characteristics in the legal sense. The values may vary due to component tolerances. Maintenance manual coatmaster Flex V2 EN Page 1 of 10 Thomas Baumgartner / 1.2023...
-
Page 3: Table Of Contents
Replacement of the outlet filter and clean the device inside ..........7 Install a new glass ........................9 Replacement of the inlet filter .....................9 Send the Service Report to coatmaster ................10 Table of figures Fig. 1 spare parts..........................4 Fig. 2 disconnect the battery .......................6 Fig. -
Page 4: Introduction
Any extensions or changes to the hardware or software are forbidden. If, after you have read this manual and have received personal training from an employee of coatmaster AG, you are unable to properly perform the work described, contact coatmaster AG. coatmaster AG... -
Page 5: Material
(for no spectral blue Flex) 6. Serial No of the Maintenance Kit Fig. 1 spare parts 2.2 Tools (not supplied by CM AG) 7. Torx screwdriver T10 Maintenance manual coatmaster Flex V2 EN Page 4 of 10 Thomas Baumgartner / 1.2023... -
Page 6: Maintenance Works
Level 2: must only be done by a coatmaster AG Technician or a coatmaster Distributor It’s prohibited to do a Level 2 Maintenance by user or any other technician besides coatmaster AG. If so, the warranty claim will be immediately terminated. -
Page 7: Safety Instructions
Fig. 2 disconnect the battery 3.3 Replacement of the front glass Front glass can only be replaced with spare parts supplied by coatmaster AG. Using other spare parts can lead to a damage to the device. 3.3.1 Remove the front metal ring Unscrew the front 4 x M3 screws with a torx T10 screwdriver. -
Page 8: Replacement Of The Outlet Filter And Clean The Device Inside
Fig. 5 cover screws position Fig. 6 housing opening Gently open partially the cover. Fig. 7 outlet filter Replace the black outlet filter. Maintenance manual coatmaster Flex V2 EN Page 7 of 10 Thomas Baumgartner / 1.2023... -
Page 9: Fig. 8 Clean Inside
3.4.2 Visual inspection Before the housing is screwed on again, make sure that there are no loose small parts or tools in the device, otherwise there is a possibility of damaging the coatmaster® Flex. 3.4.3 Assemble the coatmaster® Flex housing until «clack»... -
Page 10: Install A New Glass
3.6 Replacement of the inlet filter The inlet filter must be inspected, at least weekly, by the user of the coatmaster® Flex to avoid a malfunction of the device. If it is dirty, change the filter; otherwise, change the filter every month or after 80 hours of use, whichever is earlier. -
Page 11: Send The Service Report To Coatmaster
Send the completed “service report distributors” to coatmaster AG maintenance@coatmaster.com. Documents to send: completed report “service report distributors” completed CoC “Certificate of Calibrationen Flex” After receiving the documents, coatmaster will reset the maintenance-message on the Flex within the next two working days. coatmaster AG Flugplatzstrasse 5...
