Page 1 UPER ® 6014V-M4 UPER ERVER USER’S MANUAL Revision 1.0a...
Page 2 Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
Page 3: About This Manual
About This Manual This manual is written for professional system integrators and PC technicians. It pro- vides information for the installation and use of the SuperServer 6014V-M4. Instal- lation and maintainance should be performed by experienced technicians only. The SuperServer 6014V-M4 is a high-end single processor rackmount server based on the SC813MS-420C 1U rackmount server chassis and the Super X6DVA-4G serverboard.
Page 4 UPER ERVER 6014V-M4 User's Manual Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6014V-M4. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X6DVA-4G serverboard, including the locations and functions of connectors, headers and jumpers.
Page 5 Preface Notes...
Page 6: Table Of Contents
UPER ERVER 6014V-M4 User's Manual Table of Contents Preface About This Manual ... iii Manual Organization ... iii Chapter 1: Introduction Overview ... 1-1 Serverboard Features ... 1-2 Server Chassis Features ... 1-5 Contacting Supermicro ... 1-7 Chapter 2: Server Installation Overview ...
Page 7 Power ... 3-3 SCSI Drive Carrier LEDs ... 3-3 Chapter 4: System Safety Electrical Safety Precautions ... 4-1 General Safety Precautions ... 4-2 ESD Precautions ... 4-3 Operating Precautions ... 4-4 Chapter 5: Advanced Serverboard Setup Handling the Serverboard ... 5-1 Processor and Heatsink Installation ...
Page 8 UPER ERVER 6014V-M4 User's Manual JLAN1/2 (Ethernet Ports) ... 5-14 Extra Universal Serial Bus Headers ... 5-15 Power LED/Speaker ... 5-15 ATX PS/2 Keyboard and PS/2 Mouse Ports ... 5-15 Wake-On-LAN ... 5-16 Wake-On-Ring ... 5-16 SMB Power (I C) ... 5-16 Jumper Settings ...
Page 9 Power Supply Failure ... 6-7 Replacing the Power Supply ... 6-7 Chapter 7: BIOS Introduction ... 7-1 Main Setup ... 7-2 Advanced Settings ... 7-3 Boot Settings ... 7-16 Security Settings ... 7-19 Exit Options ... 7-20 Appendices: Appendix A: BIOS Error Beep Codes ... A-1 Appendix B: BIOS POST Checkpoint Codes ...
Page 10 UPER ERVER 6014V-M4 User's Manual Notes...
Page 11: Chapter 1: Introduction
Overview The Supermicro SuperServer 6014V-M4 is a high-end single processor, 1U rack- mount server featuring state-of-the-art technology. The 6014V-M4 is comprised of two main subsystems: the SC813MS-420C 1U rackmount chassis and the X6DVA- 4G serverboard. Please refer to our web site for information on operating systems that have been certiﬁ...
Page 12: Serverboard Features
The X6DVA-4G has one 32-bit, 33 MHz (5V) PCI slot, one 64-bit, 100 MHz (3.3V) PCI-X slot, one 64-bit, 133 MHz (3.3V) PCI-X slot and one x4 PCI-Express slot. When conﬁ gured as the 6014V-M4, one 133 MHz PCI-X slot is available with the use of a riser card (included with the system).
Page 13: Onboard Controllers/Ports
Onboard Controllers/Ports An onboard IDE controller supports up to four Ultra ATA 100 hard drives or ATAPI devices. Onboard I/O backpanel ports include one COM port, a VGA port, two USB ports, PS/2 mouse and keyboard ports and two GLAN (NIC) ports. Other Features Other onboard features that promote system health include voltage monitors, a chassis intrusion header, auto-switching voltage regulators, chassis and CPU...
Page 14 UPER ERVER 6014V-M4 User's Manual 82541 82541 Video SRAM Figure 1-1 . Intel E7320 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. 6300ESB- SATA SATA IDE IDE COM1 Flpy/Prntr Keyboard Mouse...
Page 15: Server Chassis Features
The following is a general outline of the main features of the SC813MS-420C chassis. System Power When conﬁ gured as a SuperServer 6014V-M4, the SC813MS-420C chassis in- cludes a single 420W power supply. SCSI Subsystem The SC813MS-420C chassis was designed to support four SCSI hard drives. These drives are hot-swappable units.
Page 16: Cooling System
UPER ERVER 6014V-M4 User's Manual Figure 1-2. Rear I/O Panel Cooling System The SC813MS-420C chassis has an innovative cooling design that features four 4-cm high-performance system cooling fans. Each of these fans plug into a chassis fan header on the serverboard.
Page 17: Contacting Supermicro
Contacting Supermicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
Page 18 UPER ERVER 6014V-M4 User's Manual Notes...
Page 19: Chapter 2: Server Installation
This quick setup assumes that your 6014V-M4 system has come to you with the processor and memory prein- stalled. If your system is not already fully integrated with a serverboard, processor, system memory etc., please turn to the chapter or section noted in each step for...
Page 20: Choosing A Setup Location
UPER ERVER 6014V-M4 User's Manual Choosing a Setup Location - Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). - Leave approximately 30 inches of clearance in the back of the rack to allow for sufﬁ...
Page 21: Rack Mounting Considerations
Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).
Page 22: Installing The System Into A Rack
Identifying the Sections of the Rack Rails You may have received rack rail hardware with the SuperServer 6014V-M4. (Two front inner rails should already be attached to the chassis.) This hardware consists of two rear inner rails that secure to the chassis, one on each side just behind the preinstalled front inner rails.
Page 23: Installing The Rack Rails
Figure 2-1. Installing Rear Inner Chassis Rails Installing the Rack Rails Determine where you want to place the SuperServer 6014V-M4 in the rack (see Rack and Server Precautions in Section 2-3). Position the chassis rail guides at the desired location in the rack, keeping the sliding rail guide facing the inside of the rack.
Page 24: Installing The Server Into The Rack
UPER ERVER 6014V-M4 User's Manual Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. Do this by lining up the rear of the chassis rails with the front of the rack rails.
Page 25: Installing The Server Into A Telco Rack
Chapter 2: Server Installation Installing the Server into a Telco Rack If you are installing the SuperServer 6014V-M4 into a Telco type rack, follow the di- rections given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack.
Page 26: Checking The Serverboard Setup
ERVER 6014V-M4 User's Manual Checking the Serverboard Setup After you install the 6014V-M4 in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. 1. Accessing the inside of the system (Figure 2-4) First, release the retention screws that secure the unit to the rack.
Page 27 Chapter 2: Server Installation Figure 2-4. Accessing the Inside of the SuperServer 6014V-M4...
Page 28: Checking The Drive Bay Setup
UPER ERVER 6014V-M4 User's Manual Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the SCSI drives and SCSI backplane have been properly installed and all essential connections have been made. 1. Accessing the drive bays All drives can be accessed from the front of the server.
Page 29: Chapter 3: System Interface
System Interface Overview There are several LEDs on the control panel as well as others on the SCSI drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of speciﬁ c components. There are also two buttons on the chassis control panel and an on/off switch on the power supply.
Page 30: Control Panel Leds
5). This LED will remain ﬂ ashing or on as long as the indicated condition exists. NIC2: Indicates network activity on GLAN2 when ﬂ ashing . NIC1: Indicates network activity on GLAN1 when ﬂ ashing. HDD: Channel activity for all HDDs. This light indicates CD-ROM and SCSI drive activity on the 6014V-M4 when ﬂ ashing.
Page 31: Power
Power: Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. SCSI Drive Carrier LEDs Each SCSI drive carrier has two LEDs. Green: When illuminated, the green LED on the front of the SCSI drive car- rier indicates drive activity.
Page 32 UPER ERVER 6014V-M4 User's Manual Notes...
Page 33: Chapter 4: System Safety
Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6014V-M4 from damage: Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.
Page 34: General Safety Precautions
General Safety Precautions Follow these rules to ensure general safety: Keep the area around the SuperServer 6014V-M4 clean and free of clutter. The SuperServer 6014V-M4 weighs approximately 38 lbs (~17.3 kg) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.
Page 35: Esd Precautions
ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other. An electrical discharge is created to neutralize this difference, which can damage electronic com ponents and printed circuit boards. The following measures are generally sufﬁ cient to neutralize this difference before contact is made to protect your equipment from ESD: Use a grounded wrist strap designed to prevent static discharge.
Page 36: Operating Precautions
Operating Precautions Care must be taken to assure that the chassis cover is in place when the 6014V-M4 is operating to assure proper cooling. Out of warranty damage to the 6014V-M4 system can occur if this practice is not strictly followed.
Page 37: Chapter 5: Advanced Serverboard Setup
Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X6DVA-4G serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter. Remember to close the chas- sis completely when you have ﬁ...
Page 38: Processor And Heatsink Installation
UPERSERVER 6014V-M4 User’s Manual Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Also, do not place the serverboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up.
Page 39 5. Screw in two diagonal screws until just snug (do not fully tighten), then do the same with the remaining two diagonal screws. Finish by fully tightening all four screws (see Figure 5-2). 6. If installing two processors, repeat these steps to install the second processor in the CPU #2 slot.
Page 40: Connecting Cables
UPERSERVER 6014V-M4 User’s Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The ribbon cables used to transfer data from the peripheral devices have been carefully routed in preconﬁ...
Page 41: Connecting The Control Panel
Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-3 for the pin locations of the various front control panel buttons and LED indi- cators. Please note that even and odd numbered pins are on opposite sides of each header.
Page 42: I/O Ports
Figure 5-4 below for the colors and locations of the various I/O ports. Figure 5-4. Rear Panel I/O Ports Installing Memory Note: Check the Supermicro web site for recommended memory modules. Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Also note that the memory is inter- leaved to improve performance (see step 1).
Page 43 Memory Support The X6DVA-4G supports up to 24 GB of registered ECC DDR266 or up to 12 GB of registered ECC DDR333 SDRAM. You should not mix DIMMs of differ- ent sizes and speeds. See Figures 5-5a and 5-5b for installing and removing memory modules.
Page 44: Adding Pci Cards
UPERSERVER 6014V-M4 User’s Manual Adding PCI Cards 1. PCI slots The X6DVA-4G has one x4 PCI-Express slot, one 64-bit 133 MHz PCI-X slot and one 64-bit 100 MHz PCI-X slot. A riser card is included with the server. The CSE-RR1U-X riser ﬁ ts into the 133 MHz PCI-X slot to support a full-height, half- length PCI-X add-on card at any speed.
Page 45: Super X6Dva-4G Layout
Serverboard Details Figure 5-6. SUPER X6DVA-4G Layout Kybrd/Mouse ATX POWER JPR1 USB0/1 DIMM #1B DIMM #1A DIMM #2B DIMM #2A DIMM #3B DIMM #3A BATTERY JLAN1 JLAN2 North Bridge JPL1 133 MHz PCI-X PCI-X #6 100 MHz PCI-X PCI-X #5 JPL2 PCIE #4 x4 PCI Express...
Page 46: X6Dva-4G Quick Reference
UPERSERVER 6014V-M4 User’s Manual X6DVA-4G Quick Reference Jumper Description J13/J15 PCI Slots to SMB SCSI Term. En/Disable JBT1 CMOS Clear JPA1 SCSI Controller Enable/Disable Power Force On JPG1 VGA Enable/Disable JPL1/2 JLAN1/2 Enable/Disable JPR1 Power Fail Alarm Reset Watch Dog Enable/Disable...
Page 47: Connector Deﬁ Nitions
Connector Deﬁ nitions ATX Power Connector The primary power supply connector meets the SSI (Superset ATX) 24-pin specification. Make sure that the orientation of the connector is cor- rect. See the table on the right for pin deﬁ nitions. Secondary Power Connector In addition to the Primary ATX power connector (above), the Secondary...
Page 48: Hdd Led
UPERSERVER 6014V-M4 User’s Manual HDD LED The HDD (IDE Hard Disk Drive) LED connection is located on pins 13 and 14 of JF1. Attach the IDE hard drive LED cable to display disk activity. Refer to the table on the right for pin deﬁ...
Page 49: Reset Button
Reset Button The Reset Button connection is lo- cated on pins 3 and 4 of JF1. Attach it to the hardware reset switch on the computer case. Refer to the table on the right for pin deﬁ nitions. Power Button The Power Button connection is located on pins 1 and 2 of JF1.
Page 50: Serial Ports
UPERSERVER 6014V-M4 User’s Manual Serial Ports The COM1 serial port is located be- side the mouse port. COM2 is a head- er on the serverboard located near the printer connector (see serverboard layout for location). See the table on the right for pin deﬁ nitions.
Page 51: Extra Universal Serial Bus Headers
Extra Universal Serial Bus Headers Two additional USB headers (USB2/3) are located on the serverboard. These are included for connection to the ports on the front of the chassis. A USB cable (not included) is needed for the connection. See the table on the right for pin deﬁ...
Page 52: Wake-On-Lan
UPERSERVER 6014V-M4 User’s Manual Wake-On-LAN The Wake-On-LAN header is desig- nated JWOL. See the table on the right for pin deﬁ nitions. You must enable the LAN Wake-Up setting in BIOS to use this feature. You must also have a LAN card with a Wake- on-LAN connector and cable.
Page 53: Jumper Settings
Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identiﬁ ed with a square solder pad on the printed circuit board.
Page 54: Jlan1/2 Enable/Disable
UPERSERVER 6014V-M4 User’s Manual JLAN1/2 Enable/Disable Change the setting of jumper JPL1 and JPL2 to enable or disable the JLAN1 and JLAN2 Gb Ethernet ports, respectively. See the table on the right for jumper settings. The default setting is enabled.
Page 55: Scsi Termination Enable/Disable
Alarm Reset The system can notify you in the event of a power supply failure. This feature assumes that Supermicro redundant power supply units are installed in the chassis. If you only have a single pow- er supply installed, you should close this jumper (JPR1) to prevent false alarms.
Page 56: Watch Dog Enable/Disable
UPERSERVER 6014V-M4 User’s Manual Watch Dog Enable/Disable JWD controls the Watch Dog func- tion. Watch Dog is a system monitor that can reboot the system when a software application is “hung up”. Pins 1-2 will cause WD to reset the system if an application is hung up.
Page 57: Sata Led Header
SATA LED Header The Serial ATA LED header is desig- nated JSLED. Connect an LED cable here to display SATA drive activity. See the table on the right for pin deﬁ nitions. Onboard LED Indicators There are several LED indicators on the X6DVA-4G serverboard desig- nated DS1-DS5 and DS7-DS8.
Page 58: 5-11 Scsi And Ide Hard Drive Connections
UPERSERVER 6014V-M4 User’s Manual 5-11 SCSI and IDE Hard Drive Connections Note the following when connecting the hard disk drive cables: • A red mark on a wire typically designates the location of pin 1. IDE Connectors There are no jumpers to conﬁ g- ure the onboard IDE#1 and #2 connectors.
Page 59: Scsi Connectors
SCSI Connector Refer to the table at right for pin deﬁ nitions for the Ultra320 SCSI connector located at J28. Chapter 5: Advanced Serverboard Setup Ultra320 SCSI Drive Connector Pin Deﬁ nitions (J28) Pin# Deﬁ nition Pin # Deﬁ nition +DB (12) -DB (12) +DB (13)
Page 60 UPERSERVER 6014V-M4 User’s Manual Notes 5-24...
Page 61: Chapter 6: Advanced Chassis Setup
Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC813MS-420C chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows. Tools Required The only tool you will need to install components and perform maintainance is a Philips screwdriver.
Page 62: Control Panel
UPER ERVER 6014V-M4 User's Manual Figure 6-1. Chassis Front View Figure 6-2. Chassis Rear View Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system control buttons and status indicators.
Page 63: System Fans
BIOS (see page 7-16). System Fan Failure If a fan fails, you will need to have it replaced with the same type. Contact your vendor or Supermicro for information on replacement fans. Drive Bay Installation/Removal Removing the Front Bezel If your system has a front bezel (optional) attached to the chassis, you must ﬁ...
Page 64: Accessing The Drive Bays
CD-ROM Drive: For installing/removing a CD-ROM drive, you will need to gain access to the inside of the 6014V-M4 by removing the top cover of the chassis. Proceed to the "CD-ROM Drive Installation" section later in this chapter for instruc- tions.
Page 65: Sca Backplane
2. Installing/removing hot-swap SCSI drives Four SCSI drive bays are located in the front of the chassis, making them easily accessible for installation and removal. These SCSI drives are hot-swap units, meaning they can be installed and removed without powering down the system. To remove, ﬁ...
Page 66: Cd-Rom Drive Installation
The top cover of the chassis must be opened to gain full access to the CD-ROM drive bay. The 6014V-M4 accomodates only slim CD-ROM drives. Side mounting brackets are needed to mount a slim CD-ROM drive in the 6014V-M4 server. You must power down the system before installing or removing a CD-ROM drive.
Page 67: Power Supply
Chapter 6: Advanced Chassis Setup Power Supply The SuperServer 6014V-M4 has a single 420 watt power supply. This power supply has the capability of operating at 100 - 240 input volts. Depress the main power button on the front of the chassis and then unplug the AC power cord to completely remove power from the system before removing the power supply.
Page 68 UPER ERVER 6014V-M4 User's Manual Notes...
Page 69: Chapter 7: Bios
When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. (Note that BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text mes- sages.) Options printed in Bold are the default settings.
Page 70: 7-2 Main Setup
UPER ERVER 6014V-M4 User's Manual 7-2 Main Setup When you ﬁ rst enter AMI BIOS Setup Utility, you will see the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen.
Page 71: Advanced Settings
Advanced Settings The Advanced Settings screen and sub menus are listed below: Main Main Advanced Advanced Boot Boot Advanced Settings Warning: Setting wrong values in below sections may cause system to malfunction. CPU Configuration IDE Configuration Floppy Configuration PCI PnP Configuration Super IO Configuration Advanced Chipset Configuration ACPI Configuration...
Page 72 UPER ERVER 6014V-M4 User's Manual Hardware Prefetcher This feature allows the user to enable the Hardware Prefetcher function. If Disabled, the CPU will prefetch data at 64-bits per cache line. If Enabled, it will fetch data at 128-bits per cache line.
Page 73: Ide Configuration Submenu
Chapter 7: BIOS IDE Conﬁ guration Sub-Menu When you select this Sub-Menu, AMI BIOS automatically displays the status of the following items: IDE Conﬁ guration This allows the user to conﬁ gure the IDE mode. The options are Disabled, P-ATA (Parallel ATA) only, S-ATA (Serial ATA) only and P-ATA &...
Page 74 UPER ERVER 6014V-M4 User's Manual Block (Multi-Sector Transfer) Block mode boosts IDE drive performance by increasing the amount of data transferred. Only 512 bytes of data can be transferred per interrupt if block mode is not used. Block mode allows transfers of up to 64 KB per interrupt. Select "Disabled"...
Page 75: Floppy Configuration
Chapter 7: BIOS IDE Detect Time Out This feature allows the user to set the time-out value for detecting ATA, ATA PI devices installed in the system. The options are 0 (sec), 5, Mode 1.0, 15, 20, 25, 30, and 35. ATA(PI) 80Pin Cable Detection This feature allows AMI BIOS to auto-detect 80Pin ATA(PI) Cable.
Page 76 UPER ERVER 6014V-M4 User's Manual Allocate IRQ to PCI VGA Set this value to allow or restrict the system from giving the VGA adapter card an interrupt address. The options are Yes and No. Palette Snooping Select Enabled to inform the PCI devices that an ISA graphics device is installed in the system in order for the graphics card to function properly.
Page 77: Super Io Confi Guration Sub-Menu
Super IO Conﬁ guration Sub-Menu Serial Port1 Address This option speciﬁ es the base I/O port address and Interrupt Request address of serial port 1. Select "Disabled" to prevent the serial port from accessing any system resources. When this option is set to Disabled, the serial port physically becomes unavailable.
Page 78: Advanced Chipset Settings
UPER ERVER 6014V-M4 User's Manual Advanced Chipset Settings This item allows the user to conﬁ gure the Advanced Chipset settings for the sys- tem. NorthBridge Conﬁ guration This feature allows the user to conﬁ gure the settings for the NorthBridge portion of the Intel Lindenhurst chipset.
Page 79 Intel PCI-X Hub Conﬁ guration This feature allows the user to conﬁ gure the settings for Intel PCI-X Hub chipset. PXH Channel A/Channel B Bus Frequency This feature allows the user to set the maximum PCI bus speed to be programmed. The options are Auto, 33MHz PCI, 66MHz PCI, 66MHz PCI-X M1, 100MHz PCI-X M1 and 133MHz PCI-X M1.
Page 80: Power Configuration
UPER ERVER 6014V-M4 User's Manual ACPI APIC Support Select Enabled to allow the ACPI APIC Table Pointer to be included in the RSDP pointer list. The options are Enabled and Disabled. AMI OEMB Table Select Enabled to allow the OEMB Table Pointer to be included in the R(x)SDT pointer lists.
Page 81 Chapter 7: BIOS ECC Event Logging This setting allows you to enable or disable ECC Event logging. The options are Enabled and Disabled. Hub Interface Event Logging This setting allows you to enable or disable Hub Interface Event logging. The options are Enabled and Disabled.
Page 82 UPER ERVER 6014V-M4 User's Manual PCI Express Conﬁ guration This section allows the user to conﬁ gure the PCI Express slots. Active State Power Management Select Enabled to activate the function of power management for signal transactions between PCI Express L0 and L1 Link. The options are Enabled and Disabled.
Page 83: System Health Monitor
USB Conﬁ guration This feature allows the user to conﬁ gure the USB settings. USB Function This feature allows you to enable 2 USB Ports or 4 USB Ports. The options are Disabled, 2 USB Ports and 4 USB Ports. Legacy USB Support Select "Enabled"...
Page 84: Boot Settings
UPER ERVER 6014V-M4 User's Manual CPU1 Temperature, CPU2 Temperature, System Temperature AMI BIOS will automatically display the following information: CPU1 VCORE/CPU2 VCORE (for 2U systems), 3.3V Vcc(V), +5 Vin, 12V Vcc(V), -12V Vcc (V), DRAM VTT, 1.2V Vcc, 2.5V for DIMM, 1.5V Standby Power, 5V Standby, 3.3V Standby, Fan1 Speed to Fan6 Speed.
Page 85 Chapter 7: BIOS BIOS Settings Conﬁ guration Quick Boot If Enabled, this option will skip certain tests during POST to reduce the time needed for the system to boot up. The options are Enabled and Disabled. Quiet Boot Set this value to allow the boot up screen options to be modiﬁ ed between POST messages or OEM logo.
Page 86: Boot Device Priority
UPER ERVER 6014V-M4 User's Manual Boot Device Priority This feature allows the user to specify the sequence of priority for the Boot Device. The settings are 1st Floppy Drive, CDROM, ATAPI CDROM and Disabled. The default settings are: · 1st boot device – Floppy Drive ·...
Page 87: Security Settings
Security Settings AMI BIOS provides a Supervisor and a User password. If you use both passwords, the Supervisor password must be set ﬁ rst. Main Main Advanced Advanced Boot Boot Security Settings Supervisor Password: User Password: Change Supervisor Password Change User Password Boot Sector Virus Protection [Disabled] VOZ-53 (C)Copyright 1985-2002, American Megatrends, Inc.
Page 88: Exit Options
UPER ERVER 6014V-M4 User's Manual Exit Options Select the Exit tab from AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Main Main Advanced Advanced Boot Boot Exit Options Save Changes and Exit Discard Changes and Exit...
Page 89: Load Optimal Defaults
Chapter 7: BIOS Load Optimal Defaults To set this feature, select Load Optimal Defaults from the Exit menu and press <Enter>. Then Select "OK" to allow BIOS to automatically load the Optimal Defaults as the BIOS Settings. The Optimal settings are designed for maximum system performance, but may not work best for all computer applications.
Page 90 UPER ERVER 6014V-M4 User's Manual Notes 7-22...
Page 91: Appendix A: Bios Error Beep Codes
Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process. The error messages normally appear on the screen. Fatal errors are those which will not allow the system to continue the boot-up pro- cedure.
Page 92 UPER ERVER 6014V-M4 User's Manual DS7/DS8 LED Post Codes LED Indicators Description/Message PWR On SPD Read OK Memory Size-OK Starting Bus Initialization...
Page 93: Appendix B: Bios Post Checkpoint Codes
BIOS POST Checkpoint Codes When AMIBIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, diagnostic equipment can be attached to the computer to read I/O port 0080h. Uncompressed Initialization Codes The uncompressed initialization checkpoint codes are listed in order of execution: Checkpoint...
Page 94: Bootblock Recovery Codes
UPER ERVER 6014V-M4 User's Manual Bootblock Recovery Codes The bootblock recovery checkpoint codes are listed in order of execution: Checkpoint Code Description The onboard ﬂ oppy controller if available is initialized. Next, beginning the base 512 KB memory test. Initializing the interrupt vector table next.
Page 95 Uncompressed Initialization Codes The following runtime checkpoint codes are listed in order of execution. These codes are uncompressed in F0000h shadow RAM. Checkpoint Code Description The NMI is disabled. Next, checking for a soft reset or a power on condition. The BIOS stack has been built.
Page 96 UPER ERVER 6014V-M4 User's Manual Checkpoint Code Description Interrupt vector initialization is done. Clearing the password if the POST DIAG switch is on. Any initialization before setting video mode will be done next. Initialization before setting the video mode is complete. Conﬁ guring the mono- chrome mode and color mode settings next.
Page 97 Checkpoint Code Description The memory below 1 MB has been cleared via a soft reset. Clearing the memory above 1 MB next. The memory above 1 MB has been cleared via a soft reset. Saving the memory size next. Going to checkpoint 52h next. The memory test started, but not as the result of a soft reset.
Page 98 UPER ERVER 6014V-M4 User's Manual Checkpoint Code Description The password was checked. Performing any required programming before WIN- BIOS Setup next. The programming before WINBIOS Setup has completed. Uncompressing the WINBIOS Setup code and executing the AMIBIOS Setup or WINBIOS Setup utility next.
Page 99 Checkpoint Code Description Returned from adaptor ROM at E000h control. Performing any initialization required after the E000 option ROM had control next. Initialization after E000 option ROM control has completed. Displaying the system conﬁ guration next. Uncompressing the DMI data and executing DMI POST initialization next. The system conﬁ...
Page 100 UPER ERVER 6014V-M4 User's Manual Notes...
Page 101: Appendix C: Software Installation
After all the hardware has been installed, you must ﬁ rst conﬁ gure the Adaptec Embedded Serial ATA RAID Driver before you install the Windows operating system. The necessary drivers are all included on the Supermicro bootable CDs that came packaged with your server. (For Adaptec's SCSI Host RAID Utility, please refer to the CDs that came with your serverboard.)
Page 102: Using The Adaptec Raid Confi Guration Utility (Arc)
I/O throughput and providing data acces- sibility regardless of a single disk failure. By incorporating Adaptec Embedded Serial ATA into the serverboard design, Supermicro offers the user the beneﬁ ts of SATA RAID without the high costs associated with RAID hardware.
Page 103: Using The Array Confi Guration Utility (Acu)
Appendix C: Software Installation *Array Conﬁ guration Utility: Use this utility when you want to create, conﬁ gure and manage arrays. *Disk Utilities: Use this option to format or verify disks. To run the Adaptec RAID Conﬁ guration Utility, you will need to enable the RAID function in the system BIOS (refer to Chapter 7 for System BIOS Conﬁ...
Page 104: Managing Arrays
UPER ERVER 6014V-M4 User's Manual Managing Arrays Select this option to view array properties and delete arrays. The following sec- tions describe the operations Of "Managing Arrays". To select this option, use the arrow keys and the Enter key to select Managing...
Page 105 Appendix C: Software Installation Viewing Array Properties To view the properties of an existing array: 1. At the BIOS prompt, press Ctrl+A. 2. From the ARC menu, select Array Conﬁ guration Utility (ACU). 3. From the ACU menu, select Manage Arrays (as shown on the previous screen.) 4.
Page 106: Creating Arrays
UPER ERVER 6014V-M4 User's Manual Creating Arrays Before creating arrays, make sure the disks for the array are connected and installed in your system. Note that disks with no usable space, or disks that are un-initialized are shown in gray and cannot be used. See Initializing Disk Drives.
Page 107 Appendix C: Software Installation Assigning Array Properties Once you've create a new array, you are ready to assign properties to the ar- ray. Caution: Once the array is created and its properties are assigned, you cannot change the array properties using the ACU. You will need to use the Adaptec Storage Manager - Browser Edition.
Page 108 UPER ERVER 6014V-M4 User's Manual 4. The item "Create RAID via" allows you to select between the different meth- ods of creating RAID 0 and RAID 1. The following table gives examples of when each is appropriate. Raid Level Create Via...
Page 109 Appendix C: Software Installation Notes 1. Before adding a new drive to an array, back up any data contained on the new drive. Otherwise, all data will be lost. 2. If you stop the build or clear process on a RAID 1 from ACU, you can restart it by pressing Ctrl+R.
Page 110 UPER ERVER 6014V-M4 User's Manual Adding a Bootable Array 1. From the Main menu, select Manage Arrays. 2. From the list of arrays, select the array you want to make bootable and press Ctrl+B. 3. Enter Y to create a bootable array when the following message is displayed: "This will make all other existing bootable array non-bootable.
Page 111 Appendix C: Software Installation Adding/Deleting Hotspares Note: In order to rebuild a RAID (RAID 0 or RAID 1), you need to add a new HDD as a hotspare. 1. Turn on your computer and press Ctrl+A as prompted to access the ARC Utility.
Page 112: Initializing Disk Drives
UPER ERVER 6014V-M4 User's Manual Initializing Disk Drives If an installed disk does not appear in the disk selection list for creating a new array or if it appears grayed out, you may have to initialize it before you can use it as part of an array.
Page 113 Appendix C: Software Installation 5. Repeat Step 4 so that both drives to be initialized are selected (as shown on the following screen). C-13...
Page 114: Rebuilding Arrays
UPER ERVER 6014V-M4 User's Manual 6. Press Enter. 7. Read the warning message as shown on the screen below. 8. Make sure that you have selected the correct disk drives to initialize. If cor- rect, type Y to continue. Rebuilding Arrays Note 1: Rebuilding applies to Fault Tolerant arrays (RAID 1) only.
Page 115: Using The Disk Utilities
Appendix C: Software Installation Using the Disk Utilities The Disk Utilities enable you to format or verify the media of your Serial ATA hard disks. To access the disk utilities: 1. Turn on your computer and press Ctrl+A when prompted to access the ARC utility.
Page 116 UPER ERVER 6014V-M4 User's Manual To Exit Adaptec RAID Conﬁ guration Utility 1. Once you have completed RAID array conﬁ gurations, press ESC to exit. The following screen will appear. 2. Press Yes to exit the Utility. For more information regarding the Adaptec RAID Utility, please refer to Adaptec's User's Guide in the CD included in your shipping package.
Page 117 Appendix C: Software Installation C-2 Installing Intel's 6300ESB Driver by Adaptec and Windows OS 1. Insert Supermicro's bootable CD that came with the package into the CD drive during the system reboot. The "Super Micro Driver Diskette Maker" screen will appear.
Page 118: Installing Other Drivers
UPER ERVER 6014V-M4 User's Manual C-3 Installing Other Software Programs and Drivers Installing Other Drivers After you've installed the Windows Operating System, a screen (as shown in Figure B-1) will appear. You are now ready to install additional software programs and drivers.
Page 119: Supero Doctor
Appendix C: Software Installation Supero Doctor III The Supero Doctor III program is a web-based management tool that offers both remote and local management tools. The local management application is called SD III Client. The Supero Doctor III program included on the CD-ROM that came with your system allows you to monitor the environment and opera- tions of your system.
Page 120 Figure B-3. Supero Doctor III: Remote Control Display Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download the SDIII User's Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/ UserGuide.pdf. For Linux, we recommend using Supero Doctor II.
Page 121: Appendix D: System Speciﬁ Cations
Appendix D: System Speciﬁ cations Appendix D System Speciﬁ cations Processors Single or dual Intel® Xeon processors up to 3.60 GHz at an 800 MHz front side bus speed Chipset Intel E7320 BIOS 8 Mb ﬂ ash EEPROM with AMI BIOS Memory Capacity Six (6) 184-pin DIMM sockets to support a maximum of 12 GB registered ECC DDR333 or 24 GB registered ECC DDR266 SDRAM...
Page 122 UPER ERVER 6014V-M4 User's Manual Weight Gross Weight: 38 lbs. (17.3 kg.) System Cooling Four (4) 4-cm high performance fans (FAN-0061) System Input Requirements AC Input Voltage: 100-240 VAC Rated Input Current: 5A max. (100-240V) Rated Input Frequency: 50 to 60 Hz...
