  • Page 1 UPER 6014V-T2 UPER ERVER USER’S MANUAL Revision 1.0a...
  • Page 2 Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

  • Page 3: Preface

    About This Manual This manual is written for professional system integrators and PC technicians. It pro- vides information for the installation and use of the SuperServer 6014V-T2. Instal- lation and maintainance should be performed by experienced technicians only. The SuperServer 6014V-T2 is a high-end dual processor 1U rackmount server based on the SC811T-420 server chassis and the Super X6DVL-EG2 serverboard.
  • Page 4 UPER ERVER 6014V-T2 User's Manual Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6014V-T2. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X6DVL-EG2 serverboard, including the locations and functions of connectors, headers and jumpers.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 6014V-T2 User's Manual Table of Contents Preface About This Manual ... iii Manual Organization ... iii Chapter 1: Introduction Overview ... 1-1 Serverboard Features ... 1-2 Server Chassis Features ... 1-5 Contacting Supermicro ... 1-7 Chapter 2: Server Installation Overview ...
  • Page 7 ESD Precautions ... 4-3 Operating Precautions ... 4-4 Chapter 5: Advanced Serverboard Setup Handling the Serverboard ... 5-1 Processor and Heatsink Installation ... 5-2 Connecting Cables ... 5-4 Connecting Data Cables ... 5-4 Connecting Power Cables ... 5-3 Connecting the Control Panel ... 5-5 I/O Ports ...
  • Page 8 UPER ERVER 6014V-T2 User's Manual Jumper Settings ... 5-16 Explanation of Jumpers ... 5-16 CMOS Clear ... 5-16 JLAN1/2 Enable/Disable ... 5-17 VGA Enable/Disable ... 5-17 PCI Slots to SMB ... 5-17 Alarm Reset ... 5-17 Watch Dog Enable/Disable ... 5-18 5-10 Onboard Indicators ...
  • Page 9 Table of Contents Appendices: Appendix A: BIOS Error Beep Codes ... A-1 Appendix B: BIOS POST Checkpoint Codes ... B-1 Appendix C: Software Installation ... C-1 Appendix D: System Specifi cations ... D-1...
  • Page 10 Table of Contents Notes...

  • Page 11: Chapter 1: Introduction

    Overview The Supermicro SuperServer 6014V-T2 is a high-end dual processor, 1U rackmount server designed with cutting-edge technology. The 6014V-T2 is comprised of two main subsystems: the SC811T-420 1U chassis and the X6DVL-EG2 serverboard. Please refer to our web site for information on operating systems that have been certifi...

  • Page 12: Serverboard Features

    UPER ERVER 6014V-T2 User's Manual Serverboard Features At the heart of the SuperServer 6014V-T2 lies the X6DVL-EG2, a dual processor serverboard based upon Intel's E7320 chipset. Below are the main features of the X6DVL-EG2. Processor The X6DVL-EG2 has two 604-pin FC-mPGA4 sockets to support dual Intel 64-bit Xeon processors.
  • Page 13 Ethernet Ports Two Intel 82541G1 Ethernet controllers are integrated into the X6DVL-EG2 to sup- port two Gigabit LAN (Ethernet) ports. Onboard Controllers/Ports An onboard IDE controller supports one fl oppy drive and up to four Ultra ATA 100 hard drives or ATAPI devices. Onboard I/O backpanel ports include one COM port, two USB ports, PS/2 mouse and keyboard ports, a graphics (monitor) port and two Gigabit LAN (NIC) ports.

  • Page 14: System Block Diagram

    UPER ERVER 6014V-T2 User's Manual Figure 1-1 . Intel E7320 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. PCI-EXPRESS EXPRESS X4 PCI 64-BIT 66MHZ 82541 82541 RJ45 RJ45 XEON E64MT XEON E64MT...

  • Page 15: Server Chassis Features

    When confi gured as the SuperServer 6014V-T2, the SC811T-420 chassis includes a single 420W power supply. Serial ATA Subsystem For the 6014V-T2, the SC811T-420 chassis was designed to support two Serial ATA hard drives. The Serial ATA drives are hot-swappable units. ATA/100 IDE drives can be alternately supported.
  • Page 16 UPER ERVER 6014V-T2 User's Manual Figure 1-2. Rear I/O Panel...

  • Page 17: Contacting Supermicro

    Contacting Supermicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 18 UPER ERVER 6014V-T2 User's Manual Notes...

  • Page 19: Chapter 2: Server Installation

    Unpacking the System You should inspect the box the SuperServer 6014V-T2 was shipped in and note if it was damaged in any way. If the server itself shows damage, you should fi le a damage claim with the carrier who delivered it.

  • Page 20: Choosing A Setup Location

    UPER ERVER 6014V-T2 User's Manual Choosing a Setup Location - Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). - Leave approximately 30 inches of clearance in the back of the rack to allow for suffi...

  • Page 21: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 22: Installing The System Into A Rack

    ERVER 6014V-T2 User's Manual Installing the System into a Rack This section provides information on installing the SuperServer 6014V-T2 into a rack unit. If the system has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.
  • Page 23 Figure 2-2. Installing Chassis Rails Installing the Rack Rails Determine where you want to place the SuperServer 6014V-T2 in the rack (see Rack and Server Precautions in Section 2-3). Position the fi xed rack rail/sliding rail guide assemblies at the desired location in the rack, keeping the sliding rail guide facing the inside of the rack.
  • Page 24 UPER ERVER 6014V-T2 User's Manual Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. Do this by lining up the rear of the chas- sis rails with the front of the rack rails.
  • Page 25 Chapter 2: Server Installation Installing the Server into a Telco Rack If you are installing the SuperServer 6014V-T2 into a Telco type rack, follow the di- rections given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack.

  • Page 26: Checking The Serverboard Setup

    ERVER 6014V-T2 User's Manual Checking the Serverboard Setup After you install the 6014V-T2 in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. 1. Accessing the inside of the system (Figure 2-5) First, release the retention screws that secure the unit to the rack.
  • Page 27 Chapter 2: Server Installation Figure 2-5. Accessing the Inside of the System...

  • Page 28: Checking The Drive Bay Setup

    UPER ERVER 6014V-T2 User's Manual Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the Serial ATA drives and Serial ATA backplane have been properly installed and all essential connec- tions have been made.

  • Page 29: Chapter 3: System Interface

    System Interface Overview There are several LEDs on the control panel as well as others on the Serial ATA drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi c components. There are also two but- tons on the chassis control panel.

  • Page 30: Control Panel Leds

    UPER ERVER 6014V-T2 User's Manual Control Panel LEDs The control panel located on the front of the chassis has fi ve LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective ac- tion you may need to take.

  • Page 31: Power

    Power: Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Serial ATA Drive Carrier LED Each Serial ATA drive carrier has a green LED. When illuminated, this green LED (on the front of the Serial ATA drive carrier) indicates drive activity.
  • Page 32 UPER ERVER 6014V-T2 User's Manual Notes...

  • Page 33: Chapter 4: System Safety

    Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6014V-T2 from damage: Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 34: General Safety Precautions

    General Safety Precautions Follow these rules to ensure general safety: Keep the area around the SuperServer 6014V-T2 clean and free of clutter. The SuperServer 6014V-T2 weighs approximately 38 lbs (~17.3 kg) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.

  • Page 35: Esd Precautions

    ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other. An electrical discharge is created to neutralize this difference, which can damage electronic com ponents and printed circuit boards. The following measures are generally suffi cient to neutralize this difference before contact is made to protect your equipment from ESD: Use a grounded wrist strap designed to prevent static discharge.

  • Page 36: Operating Precautions

    Operating Precautions Care must be taken to assure that the chassis cover is in place when the 6014V-T2 is operating to assure proper cooling. Out of warranty damage to the 6014V-T2 system can occur if this practice is not strictly followed.

  • Page 37: Chapter 5: Advanced Serverboard Setup

    Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X6DVL-EG2 serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter. Remember to close the chas- sis completely when you have fi...

  • Page 38: Processor And Heatsink Installation

    UPERSERVER 6014V-T2 User’s Manual Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Also, do not place the serverboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up.
  • Page 39 5. Screw in two diagonal screws until just snug (do not fully tighten), then do the same with the remaining two diagonal screws. Finish by fully tightening all four screws (see Figure 5-2). 6. If installing two processors, repeat these steps to install the second processor in the CPU #2 slot.

  • Page 40: Connecting Cables

    UPERSERVER 6014V-T2 User’s Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The ribbon cables used to transfer data from the peripheral devices have been carefully routed in preconfi...

  • Page 41: Connecting The Control Panel

    Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-3 for the pin locations of the various front control panel buttons and LED indi- cators. Please note that even and odd numbered pins are on opposite sides of each header.

  • Page 42: I/O Ports

    Figure 5-4 below for the colors and locations of the various I/O ports. Figure 5-4. Rear Panel I/O Ports Installing Memory Note: Check the Supermicro web site for recommended memory modules. Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Also note that the memory is inter- leaved to improve performance (see step 1).

  • Page 43: Adding Pci Cards

    Figure 5-5b. Top View of DDR2 Slot Adding PCI Cards 1. PCI slots The 6014V-T2 system includes a CSE-RR1U-X riser card. This riser fi ts into a 66 MHz PCI slot to support a full-height, half-length PCI add-on card. 2. PCI card installation Before installing a PCI add-on card, see step 1, above.

  • Page 44: Serverboard Details

    UPERSERVER 6014V-T2 User’s Manual Serverboard Details Figure 5-6. SUPER X6DVL-EG2 Layout ATX POWER Kybrd/Mouse USB0/1 DIMM #1B DIMM #1A DIMM #2B DIMM #2A JLAN1 JLAN2 North Bridge JPL1 JPL2 PCI #6: 66 MHz PCI PCI #5: PCI-E x4 PCI #4: PCI-E x4...

  • Page 45: X6Dvl-Eg2 Quick Reference

    X6DVL-EG2 Quick Reference Jumper Description J13/J15 PCI Slots to SMB En/Disable JBT1 CMOS Clear JPG1 VGA Enable/Disable JPL1/2 JLAN1/2 Enable/Disable Power Fail Alarm Reset Watch Dog Connector Description DS1-DS2, DS4-DS5 Onboard LED Indicators (see Section 5-10) DS7-DS8 POST Code LEDs (see Appendix A) System LED (see Section 5-10) FAN 1-6 System Fan Headers...

  • Page 46: Connector Defi Nitions

    UPERSERVER 6014V-T2 User’s Manual Connector Defi nitions ATX Power Connector The primary power supply connector meets the SSI (Superset ATX) 24-pin specification. Make sure that the orientation of the connector is cor- rect. See the table on the right for pin defi...

  • Page 47: Hdd Led

    HDD LED The HDD (IDE Hard Disk Drive) LED connection is located on pins 13 and 14 of JF1. Attach the IDE hard drive LED cable to display disk activity. Refer to the table on the right for pin defi nitions. NIC1 LED The NIC1 (Network Interface Control- ler) LED connection is located on pins...

  • Page 48: Reset Button

    UPERSERVER 6014V-T2 User’s Manual Reset Button The Reset Button connection is lo- cated on pins 3 and 4 of JF1. Attach it to the hardware reset switch on the computer case. Refer to the table on the right for pin defi nitions.

  • Page 49: Serial Ports

    Defi nition P/S 1 Fail Signal P/S 2 Fail Signal P/S 3 Fail Signal Reset (from MB) Note: This feature is only available when using redundant Supermicro power supplies. Fan Header Pin Defi nitions (FAN1-6) Pin# Defi nition Ground (Black)

  • Page 50: Power Led/Speaker

    UPERSERVER 6014V-T2 User’s Manual Extra Universal Serial Bus Headers Two additional USB headers (USB2/3) are located near the fl oppy connector. These may be connected for front side USB access. A USB cable (not included) is needed for the connec- tion.

  • Page 51: Wake-On-Lan

    Wake-On-LAN The Wake-On-LAN header is desig- nated WOL. See the table on the right for pin defi nitions. You must enable the LAN Wake-Up setting in BIOS to use this feature. You must also have a LAN card with a Wake-on-LAN con- nector and cable.

  • Page 52: Jumper Settings

    UPERSERVER 6014V-T2 User’s Manual Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identifi ed with a square solder pad on the printed circuit board.

  • Page 53: Jlan1/2 Enable/Disable

    Alarm Reset The system can notify you in the event of a power supply failure. This feature assumes that Supermicro redundant power supply units are installed in the chassis. If you only have a single power supply installed, you should dis- able this header (the default setting) to prevent false alarms.

  • Page 54: Watch Dog Enable/Disable

    UPERSERVER 6014V-T2 User’s Manual Watch Dog Enable/Disable JWD controls the Watch Dog func- tion. Watch Dog is a system monitor that can reboot the system when a software application is “hung up”. Pins 1-2 will cause WD to reset the system if an application is hung up.

  • Page 55: Sata Led Header

    SATA LED Header The Serial ATA LED header is desig- nated JSLED. Connect an LED cable here to display SATA drive activity. See the table on the right for pin defi nitions. Onboard LED Indicators There are several LED indicators on the X6DVL-EG2 serverboard desig- nated DS1-DS2, DS4-DS5 and DS7- DS8.

  • Page 56: 5-11 Floppy, Ide And Sata Drive Connections

    UPERSERVER 6014V-T2 User’s Manual 5-11 Floppy, IDE and SATA Drive Connections Note the following when connecting the fl oppy and hard disk drive cables: • The fl oppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1.

  • Page 57: Ide Connectors

    IDE Connectors There are no jumpers to confi g- ure the onboard IDE#1 and #2 connectors. See the table on the right for pin defi nitions. SATA Connectors There are no jumpers to con- figure the SATA connectors. See the table on the right for pin defi...
  • Page 58 UPERSERVER 6014V-T2 User’s Manual Notes 5-22...

  • Page 59: Chapter 6: Advanced Chassis Setup

    Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC811T-420 chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If a step is unnecessary, skip ahead to the step that follows.

  • Page 60: Control Panel

    UPER ERVER 6014V-T2 User's Manual Figure 6-1. Chassis Front View Figure 6-2. Chassis Rear View Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system control buttons and status indicators.

  • Page 61: System Fans

    Chapter 6: Advanced Chassis Setup System Fans Two 10-cm blower fans provide the cooling for the SuperServer 6014V-T2. The chassis includes air seals under the blower fans and at the chassis cross section, which separates the drive bay area from the serverboard area of the chassis to promote better airfl...

  • Page 62: Drive Bay Installation/Removal

    CD-ROM/Floppy Disk Drives: For installing/removing a CD-ROM or fl oppy disk drive, you will need to gain access to the inside of the 6014V-T2 by removing the top cover of the chassis. Proceed to the "CD-ROM and Floppy Drive Installation"...
  • Page 63 2. Installing/removing hot-swap Serial ATA drives Two Serial ATA drive bays are located in the front of the chassis, making them easily accessible for installation and removal. These drives are hot-swappable, meaning they can be installed and removed without powering down the system. To remove, fi...

  • Page 64: Cd-Rom And Floppy Drive Installation

    UPER ERVER 6014V-T2 User's Manual Serial ATA Power Cables Serial ATA power cables should be routed so that they do not block the airfl ow through the chassis. See the serverboard layout diagram for the location of the cable connections.

  • Page 65: Power Supply

    Chapter 6: Advanced Chassis Setup Power Supply The SuperServer 6014V-T2 has a single 420 watt power supply. This power supply has the capability of operating at 100 or 240 input volts. Depress the main power button on the front of the chassis and then unplug the AC power cord to completely remove power from the system before removing the power supply.
  • Page 66 UPER ERVER 6014V-T2 User's Manual Notes...

  • Page 67: Chapter 7: Bios

    When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. (Note that BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text mes- sages.) Options printed in Bold are the default settings.

  • Page 68: 7-2 Main Setup

    UPER ERVER 6014V-T2 User's Manual 7-2 Main Setup When you fi rst enter the AMI BIOS Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen.

  • Page 69: Advanced Settings

    Advanced Settings Warning When you fi rst enter the Advanced Setup screen, the Setup Warning will be displayed. Please follow the instruction and set the correct value for each item to prevent the system from malfunctioning. CPU Confi guration Sub Menu Confi...
  • Page 70 UPER ERVER 6014V-T2 User's Manual Max CPUID Value Limit This feature allows the user to set the maximum CPU ID value. Enable this function to boot legacy OS that cannot support processors with extended CPUID functions. The options are Enabled and Disabled.
  • Page 71 IDE Confi guration Sub Menu When you select this Sub Menu, the AMI BIOS automatically displays the status of the following items: IDE Confi guration This feature allows the user to set the IDE mode. The options are Disabled, P- ATA (Parallel ATA) Only, S-ATA (Serial ATA) Only and P-ATA &...
  • Page 72 UPER ERVER 6014V-T2 User's Manual P-ATA Channel Selection This feature allows the user to select which channel to set the Parallel ATA Mode. The options are Primary, Secondary and Both. S-ATA Ports Defi nition This feature allows the user to confi gure Serial ATA Ports. The options are P0- 3rd/P1-4th and P0-4th/P1-3rd.
  • Page 73 Chapter 7: BIOS is not used. Block mode allows transfers of up to 64 KB per interrupt. Select Disabled to allow the data to be transferred from and to the device one sector at a time. Select Auto to allows the data transfer from and to the device occur multiple sectors at a time if the device supports it.
  • Page 74 UPER ERVER 6014V-T2 User's Manual S.M.A.R.T. For Hard disk drives Self-Monitoring Analysis and Reporting Technology (SMART) can help predict impending drive failures. Select Auto to allow the BIOS to auto detect hard disk drive support. Select Disabled to prevent the AMI BIOS from using the S.M.A.R.T.
  • Page 75 Chapter 7: BIOS PCI/PnP Confi guration This feature allows the user to set PCI/PnP confi gurations for the following items: Plug & Play OS Select Yes to allow the OS to confi gure Plug & Play devices. (This is not required for system boot if your OS supports Plug &...
  • Page 76 UPER ERVER 6014V-T2 User's Manual IRQ3/IRQ4/IRQ5/IRQ7/IRQ9/IRQ10/IRQ11/IRQ14/IRQ15 This feature specifi es the availability of an IRQ to be used by a PCI, PnP device. Select Reserved for the IRQ to be used by a Legacy ISA device. The options are Available, Reserved.
  • Page 77 Parallel Port Address This option specifi es the I/O address used by the parallel port. Select Disabled to prevent the parallel port from accessing any system resources. When the value of this option is set to Disabled, the printer port becomes unavailable. Select 378 to allow the parallel port to use 378 as its I/O port address.
  • Page 78 UPER ERVER 6014V-T2 User's Manual SouthBridge Confi guration This feature allows the user to confi gure the settings for the Intel ICH SouthBridge chipset. CPU B.I.S.T. Enable Select Enabled to enable the function of CPU Built In Self Test. The options are Enabled and Disabled.
  • Page 79 Power Confi guration This feature allows the user to confi gure PnP settings. Power Button Mode This setting allows you to decide if the system will instantly power off or will wait for 4 seconds before power-off when the power button is pressed. The options are Instant off and 4 Seconds.
  • Page 80 UPER ERVER 6014V-T2 User's Manual System Bus Event Logging This setting allows you to enable or disable System Bus Event logging. The options are Enabled and Disabled. Memory Buffer Event Logging This setting allows you to enable or disable Memory Buffer Event logging. The options are Enabled and Disabled.
  • Page 81 Remote Access Confi guration You can use this screen to select options for the Remote Access Confi guration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. Remote Access This feature allows the user to disable Remote Access function.

  • Page 82: System Health Monitor

    UPER ERVER 6014V-T2 User's Manual System Health Monitor This feature allows the AMI BIOS to automatically display the status of the follow- ing items: CPU Overheat Temperature The feature allows the user to set the CPU temperature threshold. The options...

  • Page 83: Boot Settings

    Chapter 7: BIOS Fan Speed Control Modes This feature allows the user to decide how the system controls the speeds of the onboard fans. If the option is set to "3-pin fan", the fan speed is controlled based upon the CPU die temperature. When the CPU die temperature is higher, the fan speed will be higher as well.
  • Page 84 UPER ERVER 6014V-T2 User's Manual Boot up Num-Lock Set this value to allow the Number Lock setting to be modifi ed during boot up. The default setting is On. The options are On and Off. PS/2 Mouse Support Set this value to allow the PS/2 mouse support to be modifi ed. The options are Auto, Enabled and Disabled.

  • Page 85: Boot Device Priority

    Boot Device Priority This feature allows the user to specify the sequence of priority for the Boot De- vice. The settings are 1st Floppy Drive, CD-ROM, HDD and Disabled. The default set- tings are: · 1st boot device –1st Floppy Drive ·...

  • Page 86: Security Settings

    UPER ERVER 6014V-T2 User's Manual Security Settings AMI BIOS provides a Supervisor and a User password. If you use both passwords, the Supervisor password must be set fi rst. Change Supervisor Password Select this item and press <Enter> to access the sub menu and then type in the password.

  • Page 87: Exit Options

    Chapter 7: BIOS Exit Options Select the Exit tab from the AMI BIOS Setup Utility screen to enter the Exit the BIOS Setup screen. Saving Changes and Exit When you have completed the system confi guration changes, select this option to leave the BIOS Setup and reboot the computer, so the new system confi...
  • Page 88 UPER ERVER 6014V-T2 User's Manual Load Fail-Safe Defaults To set the Fail-Safe BIOS settings, select Load Fail-Safe Defaults and press <En- ter>. The Fail-Safe settings are designed for maximum system stability, but not maximum performance. 7-22...

  • Page 89: Appendix A: Bios Error Beep Codes

    Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process. Their error messages normally appear on the screen. Fatal errors are those which will not allow the system to continue the boot-up pro- cedure.
  • Page 90 UPER ERVER 6014V-T2 User's Manual DS7/DS8 LED Post Codes DS7 LED DS8 LED Description/Message Power On SPD Read Ok Memory Size OK Starting Bus Initialization...

  • Page 91: Appendix B: Bios Post Checkpoint Codes

    BIOS POST Checkpoint Codes When AMIBIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, diagnostic equipment can be attached to the computer to read I/O port 0080h. Uncompressed Initialization Codes The uncompressed initialization checkpoint codes are listed in order of execution: Checkpoint...
  • Page 92 UPER ERVER 6014V-T2 User's Manual Bootblock Recovery Codes The bootblock recovery checkpoint codes are listed in order of execution: Checkpoint Code Description The onboard fl oppy controller if available is initialized. Next, beginning the base 512 KB memory test. Initializing the interrupt vector table next.
  • Page 93 Uncompressed Initialization Codes The following runtime checkpoint codes are listed in order of execution. These codes are uncompressed in F0000h shadow RAM. Checkpoint Code Description The NMI is disabled. Next, checking for a soft reset or a power on condition. The BIOS stack has been built.
  • Page 94 UPER ERVER 6014V-T2 User's Manual Checkpoint Code Description Interrupt vector initialization is done. Clearing the password if the POST DIAG switch is on. Any initialization before setting video mode will be done next. Initialization before setting the video mode is complete. Confi guring the mono- chrome mode and color mode settings next.
  • Page 95 Checkpoint Code Description The memory below 1 MB has been cleared via a soft reset. Clearing the memory above 1 MB next. The memory above 1 MB has been cleared via a soft reset. Saving the memory size next. Going to checkpoint 52h next. The memory test started, but not as the result of a soft reset.
  • Page 96 UPER ERVER 6014V-T2 User's Manual Checkpoint Code Description The password was checked. Performing any required programming before WIN- BIOS Setup next. The programming before WINBIOS Setup has completed. Uncompressing the WINBIOS Setup code and executing the AMIBIOS Setup or WINBIOS Setup utility next.
  • Page 97 Checkpoint Code Description Returned from adaptor ROM at E000h control. Performing any initialization required after the E000 option ROM had control next. Initialization after E000 option ROM control has completed. Displaying the system confi guration next. Uncompressing the DMI data and executing DMI POST initialization next. The system confi...
  • Page 98 UPER ERVER 6014V-T2 User's Manual Notes...

  • Page 99: Appendix C: Software Installation

    After all the hardware has been installed, you must fi rst confi gure the Adaptec Embedded Serial ATA RAID Driver before you install the Windows operating system. The necessary drivers are all included on the Supermicro bootable CDs that came packaged with your serverboard. (For Adaptec's SCSI Host RAID Utility, please refer to the CDs that came with your serverboard.)
  • Page 100 I/O throughput and providing data acces- sibility regardless of a single disk failure. By incorporating Adaptec Embedded Serial ATA into the motherboard design, Supermicro offers the user the benefi ts of SATA RAID without the high costs associated with RAID hardware.
  • Page 101 Appendix C: Software Installation *Array Confi guration Utility: Use this utility when you want to create, confi gure and manage arrays. *Disk Utilities: Use this option to format or verify disks. To run the Adaptec RAID Confi guration Utility, you will need to enable the RAID function in the system BIOS (refer to Chapter 7 for System BIOS Confi...
  • Page 102 UPER ERVER 6014V-T2 User's Manual Managing Arrays Select this option to view array properties and delete arrays. To select this op- tion, use the arrow keys and the Enter key to select Managing Arrays from the main menu (as shown below).
  • Page 103 Viewing Array Properties To view the properties of an existing array: 1. At the BIOS prompt, press Ctrl+A. 2. From the ARC menu, select Array Confi guration Utility (ACU). 3. From the ACU menu, select Manage Arrays (as shown on the previous screen.) 4.
  • Page 104 UPER ERVER 6014V-T2 User's Manual Creating Arrays Before creating arrays, make sure the disks for the array are connected and installed in your system. Note that disks with no usable space, or disks that are un-initialized are shown in gray and cannot be used. See Initializing Disk Drives.
  • Page 105 Appendix C: Software Installation Assigning Array Properties Once you've create a new array, you are ready to assign properties to the ar- ray. Caution: Once the array is created and its properties are assigned, you cannot change the array properties using the ACU. You will need to use the Adaptec Storage Manager - Browser Edition.
  • Page 106 UPER ERVER 6014V-T2 User's Manual 4. The item "Create RAID via" allows you to select between the different meth- ods of creating RAID 0 and RAID 1. The following table gives examples of when each is appropriate. Raid Level Create Via...
  • Page 107 Appendix C: Software Installation Notes 1. Before adding a new drive to an array, back up any data contained on the new drive. Otherwise, all data will be lost. 2. If you stop the build or clear process on a RAID 1 from ACU, you can restart it by pressing Ctrl+R.
  • Page 108 UPER ERVER 6014V-T2 User's Manual Adding a Bootable Array 1. From the Main menu, select Manage Arrays. 2. From the list of arrays, select the array you want to make bootable and press Ctrl+B. 3. Enter Y to create a bootable array when the following message is displayed: "This will make all other existing bootable array non-bootable.
  • Page 109 Appendix C: Software Installation Adding/Deleting Hotspares Note: In order to rebuild a RAID (RAID 0 or RAID 1), you need to add a new HDD as a hotspare. 1. Turn on your computer and press Ctrl+A as prompted to access the ARC Utility.
  • Page 110 UPER ERVER 6014V-T2 User's Manual Initializing Disk Drives If an installed disk does not appear in the disk selection list for creating a new array or if it appears grayed out, you may have to initialize it before you can use it as part of an array.
  • Page 111 Appendix C: Software Installation 5. Repeat Step 4 so that both drives to be initialized are selected (as shown on the following screen). C-13...
  • Page 112 UPER ERVER 6014V-T2 User's Manual 6. Press Enter. 7. Read the warning message as shown on the screen below. 8. Make sure that you have selected the correct disk drives to initialize. If cor- rect, type Y to continue. Rebuilding Arrays Note 1: Rebuilding applies to Fault Tolerant arrays (RAID 1) only.

  • Page 113: Using The Disk Utilities

    Appendix C: Software Installation Using the Disk Utilities The Disk Utilities enable you to format or verify the media of your Serial ATA hard disks. To access the disk utilities: 1. Turn on your computer and press Ctrl+A when prompted to access the ARC utility.
  • Page 114 UPER ERVER 6014V-T2 User's Manual To Exit Adaptec RAID Confi guration Utility 1. Once you have completed RAID array confi gurations, press ESC to exit. The following screen will appear. 2. Press Yes to exit the Utility. For more information regarding the Adaptec RAID Utility, please refer to Adaptec's User's Guide in the CD included in your shipping package.
  • Page 115 Appendix C: Software Installation C-2 Installing Intel's 6300ESB Driver by Adaptec and Windows OS 1. Insert Supermicro's bootable CD that came with the package into the CD drive during the system reboot. The "Super Micro Driver Diskette Maker" screen will appear.
  • Page 116 UPER ERVER 6014V-T2 User's Manual C-3 Installing Other Software Programs and Drivers Installing Other Drivers After you've installed the Windows Operating System, a screen (as shown in Figure C-1) will appear. You are now ready to install additional software programs and drivers.
  • Page 117 Appendix C: Software Installation Supero Doctor III The Supero Doctor III program is a web-based management tool that offers both remote and local management tools. The local management application is called SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 118 Figure C-3. Supero Doctor III: Remote Control Display Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download the SDIII User's Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/ UserGuide.pdf. For Linux, we recommend using Supero Doctor II.

  • Page 119: Appendix D: System Specifi Cations

    Appendix D: System Specifi cations Appendix D System Specifi cations Processors Single or dual Intel® Xeon processors up to 3.60 GHz at an 800 MHz front side bus speed Chipset Intel E7320 BIOS 8 Mb fl ash EEPROM with AMI BIOS Memory Capacity Four (4) 240-pin DIMM sockets to support a maximum of 8 GB registered ECC DDR2-400 SDRAM...
  • Page 120 UPER ERVER 6014V-T2 User's Manual Weight Gross Weight: 38 lbs. (17.3 kg.) System Cooling Two (2) 10-cm blower fans (FAN-0059) System Input Requirements AC Input Voltage: 100-240 VAC Rated Input Current: 5A max. (100-240V) Rated Input Frequency: 50 to 60 Hz...
