Sound Level Check Point - Fujitsu ARXG30KMLA Design & Technical Manual

Hide thumbs Also See for ARXG30KMLA:
Table of Contents

Advertisement

6-2. Sound level check point

Microphone
Front view
6-2. Sound level check point
2 m
Air
Measuring duct
(Set the static pressure
as rating in this area.)
- 48 -
1 m
Product
Measuring duct
Microphone
Side view
6. Operation noise (sound pressure)
