14. Accessories
14-1. Model: AOYG24KBTB
Part name
Installation manual
14-2. Models: AOYG30KBTB, AOYG36KBTB, and AOYG45KBTB
Part name
Installation manual
Drain pipe
14-1. Model: AOYG24KBTB
Exterior
Q'ty
1
Drain pipe
Exterior
Q'ty
1
Drain cap
1
One-touch bush
- 105 -
Part name
Part name
Exterior
Q'ty
1
Exterior
Q'ty
3
2
14. Accessories
