Rocstor Y10A101-B2 User Manual

DisplayPort® 1.2 to HDMI 4Kx2K 60Hz Active
Adapter Converter M/F - Black
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
This Premium Rocstor DisplayPort 1.2 to HDMI allows you to transmit signal from your
DisplayPort host (PC, tablet) to an HDMI monitor. This adapter enables to output HDMI
video with max 4k/60Hz. Besides, this product supports HDR which enables to ensures
every moment of a video is displayed at its ideal values for depth, detail, brightness,
contrast and wider color gamuts—on a scene-by-scene or even a frame-by-frame
basis. With this product, you can watch videos or slideshows on big screen.
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
Operation
1- Connect DisplayPort of this product to a DisplayPort display
2- Connect HDMI port of this product to an HDMI monitor
System Requirement
Host computer with an available DisplayPort
Operating systems
- Windows 7 / 8 / 10 / 11
- Android OS
- Chrome OS
- Linux OS
- Mac OS v10.5 or above
User Manual
Y10A101-B2
®
Features
Upstream:
DisplayPort Male
(Connect to host computer)
• Supports DP1.2
Downstream:
HDMI
• Support HDMI resolution up to 4kx2k@60HZ
• 18Gbps HDMI bandwidth
• Supports 8/10/12 bit color depth output
• Support output pixel format RGB/YCbCr4:4:4/YCb
Cr4:2:2/YCbCr4:2:0
• Support HDCP 2.2&HDCP1.4
• Support HDR
Speci cation
Input / Output Connector
Input
Output
Warranty
Limited Warranty
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certi cations
Resolution
HDMI Resolutions
HDMI Bandwidth
Size (LxHxW)
Weight
Accessory
User Manual
Power
Power Source
Standby Power Consumption
Working Power Consumption
DisplayPort Male x1
HDMI Female x1
3 Year
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
FCC, CE
Up to 4KX2K@60HZ
18Gbps
6.6"x0.86"x0.47" - 168x22x12
0.7oz - 22gr
English Version
Bus Power
≤0.1W
≤0.72W
