A148120 - A148121=
14652 - 14653
EN
TEXTILES SLINGS
Technical information
Product code
Description
Color
Safe Working Load
Effective length
Material
Width
Safety Factor
WORKING LOAD LIMIT - Safety Factor
Straigt
Webbing colour
(Tons)
Slinging method
1 - Purple
1.0
2 - Creen
2.0
3 - Yellow
3.0
4 - Grey
4.0
5 - Red
5.0
6 - Brown
6.0
8 - Blue
8.0
10 - Orange
10.0
12 - Orange
12.0
Identification - Label
Colour:
Material:
Blue
Polyester
Green
Polyamide
Brown
Polypropylene
It contains:
• the CMU
• The material used and the accessories class
(buckles...)
• The nominal length in metres
• The Manufacturer's name
• The traceability code
• The Standard number
• The EC marking
PROTECT THE SLING AGAINST SHARP EDGES
Flat sling
A148120
A148121
Flat sling 3000 kg
Flat sling 3000 kg
Yellow
Yellow
3000kg
3000kg
3m
PES
90mm(±3%)
90mm(±3%)
7
Choker
Basket
Basket
(Tons)
(Tons)
w/45°(Tons)
0.8
2.0
1.8
1.6
4.0
3.6
2.4
6.0
5.4
3.2
8.0
7.2
4.0
10.0
9.0
4.8
12.0
10.8
6.4
16.0
14.4
8.0
20.0
18.0
9.6
24.0
21.6
Identification of the textile sling
The colour of the textile sling or strap (colour
issuing from the harmonised standard), varies
according to the Maximum Working Load:
Colour
Corresponding capacity
Purple
Green
Yellow
Grey
Red
Brown
Blue
Orange
Orange
More than 10,000 kg.
EN
NL
DE
FR
PT
ES
IT
NO
SV
FI
HU
SK
PL
DA
CS
• For textile slings, a strap can be used with:
4m
PES
7
Basket
w/90°(Tons)
NB:
The lifting system is not guaranteed to work properly if these VERY IMPORTANT INSTRUCTIONS are not
followed. Serious accidents can lead to injuries, even fatalities.
General user instructions
• Lifting operations must be done by competent persons only.
• Use of the round slings and lifting straps for any purpose other than a lifting operation is forbidden.
1.4
• Use in chemical environments, like acid or alkaline solutions for example, must be avoided!
• Use of the round slings and lifting straps is only authorised within certain temperature ranges: PES/PA
2.8
from -30° C to +100° C, PP from -30° C to +80° C.
• Remove from service all round slings and lifting straps with illegible or missing labels. Lack of safety
4.2
instructions can lead to incorrect use.
5.6
• The round slings and lifting straps must not be stretched over sharp angles or sharp edges because
they could be cut.
7.0
• Opening the strap loop to an angle of over 20º is strictly forbidden.
8.4
Remove the sling from service in the event of:
11.2
• Localised deterioration of the strap, other than general wear
• Transversal or longitudinal cut, damage to edges by cutting or heating, cutting of seams or buckles
14.0
• Cutting of the sling sheath revealing the carrying threads
• Chemical attack causing the material to weaken or soften (indicated by a flaking of the surface of the
16.8
sheath, torn off or removed by rubbing)
• Damage due to heat or friction, indicated by the glossy appearance of the fibres
• Deformation of the end accessory
• Absence of identification plate or label
• Sun-sensitive textile slings can be damaged by ultra-violet rays and therefore be weakened without
altering their appearance; be careful with slings often exposed to sunlight.
HANDLING / LIFTING THE LOAD
• Before handling, identify the route and set-down point,; clear gangways;
• Make sure that no tool or object has been left on the load and that it will not "fly over" anyone when
1,000 kg
travelling!
• Check that the rise, fall and transfer of the load will be done freely and safely.
2,000 kg
• During the operation, the sling operator-driver must be positioned so as to accompany the load. He
3,000 kg
mustn't move backwards!
• If the device is driven by another operator, the sling operator informs the driver what movements he
4,000 kg
must execute: he must move within the driver's field of vision at all times; communication can be
done with a suitable sound system or by command gestures that both of them perfectly understand.
5,000 kg
• The load must be lifted vertically (pulling it at an oblique angle is dangerous!) , it must be moved at
a moderate pace and without stops and starts, staying close to the ground, high enough above it to
6,000 kg
avoid obstacles and avoiding swaying the load!
8,000 kg
• No worker must be under the load and the load must never be passed over the heads of staff.
• If you have to stop the operation, don't leave the load hanging: always set it down;
10,000 kg
• The load must be set down after stopping the horizontal movement and without it swaying; on suffi-
ciently solid ground (avoid covers, trap doors, gutters, fragile structures);
• Swaying the load to place it beyond the device's scope of action is forbidden;
• If necessary, set the load down on chocks in order to remove the slings or to support the load where
necessary.
User Guide
Gebruikersgids
Bedienungsanleitung
Guide utilisateur
Guia do utilizador
Guía de usuario
Manuale dell'utente
Brukerveiledning
Instruktioner
Käyttöopas
Felhasználói útmutató
Návod na použitie
Instrukcja użytkowania
Brugervejledning
Návod k použití
www.manutan.com
Sheaths for lifting straps and tubular slings
Polyurethane protective sheaths for flat slings
