4. OUTDOOR FAN CONTROL

1. Outdoor Fan Motor
Following table shows the fan speed of the outdoor unit.
( Table 3 : Fan speed of the outdoor unit )
AO*18LMAK2
AO*24LMAM2
AO*30LMAW4
For AO*18LMAK2/ 24LMAM2
*
When the outdoor heat exchanger tenperature is lower than 2°C,
the fan speed switches to 780rpm on heating mode.
For AO*30LMAW4
*
It runs at 500rpm for 20 seconds after starting up the outdoor fan.
When the outdoor heat exchanger tenperature is lower than 2°C,
the fan speed switches to 780rpm on heating mode.
Cooling
780/ 420 rpm
820/ 780/ 400/ 300/ 200 rpm
01-11
Heating
780/ 420 rpm
850/ 780/ 400/ 300/ 200 rpm
