Reference
3233
Description.
Description
This relay allows the most basic and common functions to be carried out: opening a door, activating a light, etc.
For more advanced functions not available in this relay, FERMAX has the DUOX PLUS relay ref. 3267.
Programming is very simple, even if the factory default parameters are already the ones desired by the installer, you will not even
have to program anything. Just connect and that's it.
Using jumper JP1, the relay can be programmed as:
Block Relay (Default value: block = 00): Only the devices in that BLOCK can activate the relay (outdoor panels, guard unit or
monitors / telephones)
General Entrance Relay: All users of the installation can activate the relay.
The relay can be programmed to activate with the following actions :
Door opening.
F1 (default activation parameter).
F2
Call from the panel or concierge.
The relay activation time can also be programmed: [1 s, 99 s]. The factory default is 4 s.
Fermax / Products
EAN
8424299032337
Product Code
F03233
DUOX PLUS BASIC RELAY
1/3
Updated on
2023-08-12 04:42
thanks to

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F03233 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fermax F03233

Summary of Contents for Fermax F03233

  • Page 1 This relay allows the most basic and common functions to be carried out: opening a door, activating a light, etc. For more advanced functions not available in this relay, FERMAX has the DUOX PLUS relay ref. 3267. Programming is very simple, even if the factory default parameters are already the ones desired by the installer, you will not even have to program anything.
  • Page 2 QR TO THE USER GUIDE : when scanning this QR with the mobile, it takes the installer to the technical manual of the product. TECHNICAL CHARACTERISTICS Power supply: 18-24 Vdc Consumption: Standby: 1.2 W Relay ON: 7.2 W Fermax / Products thanks to...
  • Page 3 0.1586 width x depth) mm (height x width x depth) cm Technologie 86 x 106 x 31 6,5x11,3x9,6 DUOX Manuals 970204 Rele Basico DUOX Plus V11_20.pdf Declaration of conformity DOCF03233EN.pdf Accessories F03267 DUOX PLUS RELAY Fermax / Products thanks to...
