INSTALLATION AND
INSTRUCTION MANUAL
Gas and Electric 60cm Built in Ovens
Models:
Glem - GF64GEI, GF64EEI
Emilia - EMF61MVI, EF64EI
IMPORTANT
This oven is for domestic applications. It is NOT suitable for commercial applications
of any kind. Do not install the oven if there is any doubt. Contact Glem Gas Australasia
if you require clarification.
This oven must be installed by a qualified and licensed installer in accordance with
these instructions. If you do not retain proof of correct installation your warranty will be
voided.
If your oven is found to be incorrectly installed you will be liable for all service costs. If
a warranty call is made and the oven is found to be incorrectly installed you will be
charged for the cost of the service even if the oven is not repaired. We will not service
an incorrectly installed oven.
EDIT241121
Advertisement
Table of Contents
Related Manuals for Glem GF64GEI
Summary of Contents for Glem GF64GEI
- Page 1 IMPORTANT This oven is for domestic applications. It is NOT suitable for commercial applications of any kind. Do not install the oven if there is any doubt. Contact Glem Gas Australasia if you require clarification. This oven must be installed by a qualified and licensed installer in accordance with these instructions.
- Page 2 NOTE: Model number details are on the inside of the door. Record them here for your records. Model: Serial No.: Emilia and Glem ovens are manufactured in the Glem Gas factory in Modena, Italy. They have been designed and constructed to meet the following Australian Safety Standards: AS/NZ 5263.0: 2017 (Amendment 1) AS/NZ 5263.1.1: 2020...
- Page 3 SAFETY HINTS AND USAGE TIPS 1) OVEN DOOR Keep children away from the glass oven door while cooking is in progress: if touched, the glass could cause burns. Don’t let children sit on or play with the oven door. Do not use the drop-down door as a stool to reach above cabinets.
-
Page 4: General Warnings
Glem Gas Australasia Pty. Ltd. does not accept any responsibility for damage caused by inappropriate, incorrect, and irrational use. For detailed information, refer to the Warranty Card. Contact Glem Gas Australasia Pty. Ltd. on 1 300 307 917 for all service enquiries. On websites you will find details of www.glemgas.com.au... - Page 5 BEFORE USING FOR THE FIRST TIME Remove all packing material and literature from the oven before connecting the gas and electricity supplies. Make sure all plastic has been removed before use. Some models have trays with a protective coating; make sure the plastic coating has been removed.
-
Page 6: Description Of Controls
GAS OVEN DESCRIPTION OF CONTROLS Use the controls and knobs on the oven instrument panel to select the various functions. Minute counter – rotate the knob to the desired time up to 60 ‘TIMER’: minutes and a bell will ring at the end of the time period. For very short time periods turn the knob past the point you want and then back to it to load the timer mechanism. -
Page 7: Oven Operation
GAS OVEN OVEN OPERATION Lighting the Gas Oven The oven burner must be ignited with the DOOR OPEN. There is a safety device which prevents the oven lighting unless the door is in the open position 1. Open the oven door and remove the grill tray and leave it out. 2. -
Page 8: Electric Oven
ELECTRIC OVEN DESCRIPTION OF CONTROLS Electric ovens have the advantage of being able to offer different types of heat to suit many cooking applications. Models vary according to the functions available. Minute counter – rotate the knob to the desired time up to 60 TIMER: minutes and a bell will ring at the end of the time period. - Page 9 OVEN FUNCTIONS – Electric Oven (functions vary according to model) FAN FORCED: The heat is generated by a circular element and distributed by a fan. Fast and efficient and allows for baking on more than one shelf. Some foods may need to be rotated using this function.
-
Page 10: Cooking Table
COOKING TABLE Dish Shelf Position 1=top Temp Degrees C Cooking Time Cakes Static Fan Oven Static Fan Oven Minutes Chocolate cake 180-190 35-40 Creme Caramel 130-150 30-35 Cup Cakes 190-200 180-190 18-20 (35 cakes) Fruit Cake 175-190 165-180 35-35 Jam Tarts 185-200 185-200 40-50... - Page 11 Cooking Notes: • The information provided is purely a guideline. Modify to suit experience, eating habits and personal taste. • The times indicated in the table do not include preheating of the oven, which is always recommended. • The time and temperature indicated refer to average quantities of food: meats1/1.5kg, dough for confectionery, pizza, bread 0.5/0.8kg.
- Page 12 BAKING TROUBLE SHOOTING All ovens are different and it can take some time to learn the cooking characteristics of your new oven. Listed below are some common problems, causes and suggested solutions that may assist. Problem Cause Solution Cooking unevenly Wrong location in oven Use shelf to place food in centre of oven Wrong size tray...
-
Page 13: Grilling Tips
GRILLING TIPS: • Before introducing food inside the oven it is advisable to pre-heat the oven for at least 5 minutes. • Place the food to be grilled on the appropriate rack or tray, positioning it at the highest level depending on the volume of food and the amount of direct heat you want to apply. -
Page 14: Cleaning And Maintenance
CLEANING AND MAINTENANCE WARNING: the oven must be kept clean, as a build-up of fat constitutes a fire risk. 1. Cleaning of Stainless Steel: In order that your oven retains its new appearance, care should be taken to protect the stainless steel finish. Never use gritty or abrasive sponges. -
Page 15: Removing The Door
REPLACEMENT OF INTERNAL OVEN LIGHT WARNING: Ensure the oven is switched off before replacing the lamp to avoid the possibility of electric shock. Remove the glass protection cover unscrewing it in an anti-clockwise direction, replace the bulb with a similar bulb (15W) and reassemble. Only use oven bulbs (T300°C) 15w. -
Page 16: Troubleshooting
TROUBLE SHOOTING Faults If there is a problem with the oven or grill please check the points listed below before calling for service. You may be able to solve the problem yourself saving the inconvenience of a service call. Refer to page 12 for cooking problems. Service charges will apply to issues created by incorrect installation, installation by a non certified gas installer or incorrect use of the oven. - Page 17 OVEN INSTALLATION INSTRUCTIONS – Qualified and licenced technicians only. WHEN INSTALLING AN OVEN THERE MUST BE A CAVITY SPACE UNDER THE OVEN TO ALLOW AIR FLOW. MOUNT THE OVEN IN THE CAVITY ON 2 X 100mm WIDE SUPPORTS. THERE SHOULD BE 50mm AIR CLEARANCE UNDERNEATH.
- Page 18 If the appliance is to be installed adjacent to vinyl wrapped surfaces, use an installation kit available from the vinyl-wrap supplier. Glem Gas does not accept responsibility for damage caused by installation into low temperature After installation, test and ensure that the appliance tolerant cabinets.
-
Page 19: Location Of Installation
The place where the gas oven is installed must have a natural air flow necessary for gas combustion. The room air flow required for combustion on Emilia and Glem gas ovens is 5 cubic meters/hour. Discharge of combustion products The gas cooking ovens must discharge combustion products through extractor hoods connected directly to a flue or directly to the exterior as shown in the figure below. -
Page 20: Installation - Electrical Connection
INSTALLATION - ELECTRICAL CONNECTION This installation must be undertaken by a licensed and authorised technician. • The electrical supply for the oven must be a 240 Volt 50 Hz. • The fuse and electrical wiring of the dwelling must support the load of the oven. - Page 21 GAS OVEN INSTALLATION - Gas Connection WARNING! THIS OVEN MUST BE INSTALLED BY AN AUTHORISED PERSON – PROOF IS REQUIRED FOR WARRANTY SERVICE CLAIMS. The oven has been manufactured with a Natural Gas injector fitted. For use with LPG the oven must be converted by an authorised technician. The warranty will be voided if the LPG conversion is not undertaken by a qualified gas fitter.
-
Page 22: Final Check
If the oven fails to operate correctly, call Glem Gas Australasia Pty Ltd or their appointed agent for service. Do not attempt repairs yourself. -
Page 23: Important Notes
Gas checks and adjustments - pressure adjustment First shut off the gas to the oven. Remove the sealing screw from the regulator test point at the rear of the oven and attach the hose from the manometer to the point. Turn the gas back on and light the burner on the maximum temperature setting. - Page 24 This is a relatively simple task but must be undertaken by a licensed gas fitter. No responsibility will be accepted by Glem Gas if this requirement is not met and it will void the warranty To Convert to ULPG Operation –...
- Page 25 ADJUSTMENT OF THE THERMOSTAT MINIMUM SETTING The operation is performed with the oven installed in the fixture and after qualified personnel has completed the electrical and gas connections. This measure is necessary whenever the type of gas is changed natural gas to ULPG to guarantee a minimum temperature close to 150°C.
-
Page 26: Product Warranty
COMMERCIAL USE – 90 DAYS FROM DATE OF DELIVERY TO THE ORIGINAL PURCHASER. Glem Gas Australasia Pty Ltd, during the period of warranty, will at its option, and subject to the terms and conditions stated below, repair or replace free of charge this appliance or any component part, which upon... -
Page 27: Warranty Form
Purchased from Date of purchase WARRANTY FORM Please complete the section below and return to: Glem Gas Australasia Pty. Ltd, PO Box 63 Blaxcell PO South Granville or fax to 02 9721 2766 Appliance type Model No. Serial no. Purchased from... -
Page 28: Installers Check List
Date of Installation Name of Installer Licence number Installers Signature: Owner’s Signature confirming the above: GLEM GAS AUSTRALASIA PTY. LTD. P.O. Box 63 Blaxcell PO South Granville NSW 2142 Phone: 02 96433500 – Fax: 02 9643 3599 – www.glemgas.com.au Email us info@glemgas.com.au...
