Chapter 3

Adjusting the Picture

The menus for adjusting the picture are used to obtain
the best picture settings according to your preference,
the type of program you are watching and the ambient
lighting.
Display the main menu by pressing Menu and select
Picture, then press the OK button to confirm. The
Picture options are as below:
Note: some options may be not available for certain
signal sources.
Picture preset
Brightness
Contrast
Saturation
Sharpness
Back Light
Color Temperature
Select
Screen Mode
Back
Menu
Auto Format
Exit
Exit
ECO Settings
Picture preset: use the left or right direction button to
scroll through the picture preset settings: Standard,
Dynamic, Studio, Personal, Movie.
Brightness: adjusts the brightness of the picture.
Contrast: adjusts the difference between light and dark
areas of the picture.
Saturation: adjusts the richness of colour.
Sharpness: adjusts the crispness of the edges in the
picture.
Note: this function is not available in VGA mode.
Back Light: adjusts the backlight level of the screen.
Note: this function is not available in Standard/Personal
mode.
Color temperature: adjusts the color temperature of the
picture. Use the left or right direction button to scroll
through the color settings: Cool for a more blue palette
of picture colors; Normal;Customer, and Warm for a
more red palette of picture colors.
Screen mode: use the left or right direction button to
select the picture size. (Note: You are recommended to
use the full screen mode. Do not use the display mode
with black bars on both sides of the picture (such as 4:3)
for long time, otherwise the TV screen may be damaged
permanently.)
Auto format: use the left or right direction button to
select On and Off, when On selected, the picture will
display the picture according to HD Signal's format.
Note: Auto format is available only in TV and AV mode.
Eco Settings: press the OK or right direction button to
select energy saving mode: press the left or right
direction button to select desired power saving mode to
achieve desired power saving effect. At this time the
Picture preset option under Picture will be set to
Personal synchronically.
Advanced Settings: press the OK or right direction
button to display its submenu.
ECO
60
50
50
8
50
Cinerama
Cool
On
Auto
.
Advanced Functions
Noise reduction: this setting reduces picture
any type of interference. This feature is
especially useful for providing a clearer picture in
weak analog signal conditions. Press the left or right
direction button to choose between these options:
Low/High/Auto /Off/Middle.
MPEG NR (Noise Reduction): this feature allows you to
reduce visible interference caused by MPEG compression.
Dynamic Contrast: turns on this option to adjust the
contrast automatically.
Film Mode: optimizes the picture for watching film. Select
On or Off.
White Balance: adjusts the color temperature manually
when the Color Temperature mode is Customer.
Gamma: adjusts the middle level of luminance.
Reset: this function allows you to reset all the picture
settings to the factory default settings.
Note: some options may appear in the next page of
Picture menu, you can press the up or down direction
button to switch.

Adjusting the Sound

Display the main menu by press the Menu button and select
Sound, then press the OK button to confirm. The Sound
menu appears with the following options:
CEC
Version Info
Enter
OK
Select
Back
Menu
Exit
Exit
Sound preset: press the OK or right direction button to
display its submenus:
- Sound preset: use the left or right direction button to
select a sound type from the list: Off, Rock, Pop, Live,
Dance, Techno, Classic, Soft and Personal.
- Frequency range: use the up or down direction button
to select the desired frequency range (100Hz, 300Hz,
1KHz, 3KHz, 10KHz), use the left or right direction
button to adjust the level.
Balance: use the left or right direction button to balance the
sound between the left and right speakers.
Audio delay: if the sound output does not match the
picture,use the left or right buttonto adjust the delay time to
synchronize the sound with the picture
Wide stereo: use the left or right direction button to switch
On or Off.
Sound type use the left or right direction button to select a
sound type from the list
10
Sound
. . . . . .
Sound preset
Balance
0
Audio delay 0
Wide stereo
On
Sound type
Stereo
Auto volume control
Off
static or
