Dimensions
Bolt/screw head hole diameter (maximum)
Bolt/screw head maximum height (maximum)
Bolt/screw hole diameter (maximum)
Bolt/screw shaft to surface (maximum)
Recommended bolt or screw
When mounting using a strap, the strap will hold the mounting bracket against a surface and is
sandwiched between the mounting bracket and the Monitor One enclosure.
Dimensions
Metric
Maximum strap width 15 mm 19/32"
Metric
SAE
12.46 mm 31/64"
4.0 mm
5/32"
4.33 mm 11/64"
3.65 mm
9/64"
M4
#8
SAE
