We recommend that you keep pin 8 (VIN) and pin 7 (GND) is the same positions.
Other pins can be used as desired.
The pins on the board layout are numbered 8 - 1 left to right, opposite of how the pins on the
cable are numbered.
SCREW TERMINALS
The order of these pins isn't significant, but this is how the I/O Card is wired, so it probably best
to be consistent.
SCHEMATICS - PROTOTYPING CARD
Screw Terminal Color M12 Pin
A
Red
B
Black
C
Green
D
Blue
1
3
2
4
