DEHUMIDIFIER
DRY COMPACT 21
OPERATING INSTRUCTIONS
Read the instructions carefully before operating or servicing the dehumidifier.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage.
Keep these instructions in a safe place for future reference.
V 08/19
13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRY COMPACT 21 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo DRY COMPACT 21

Summary of Contents for Argo DRY COMPACT 21

  • Page 1 DEHUMIDIFIER DRY COMPACT 21 OPERATING INSTRUCTIONS Read the instructions carefully before operating or servicing the dehumidifier. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Keep these instructions in a safe place for future reference.
  • Page 2 Appliance filled with flammable gas R290. Before installing and using the appliance, read the owner’s manual. Before repairing the appliance, read the service manual. The Refrigerant R290  To realize the function of the air conditioner unit, a special refrigerant circulates in the system.
  • Page 3 GENERAL OPERATING AND SAFETY INSTRUCTIONS  This appliance is a highly efficient dehumidifier, designed for domestic use only!  Use this dehumidifier only as outlined in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or malfunctions. ...
  • Page 4  To disconnect the appliance, set the switch to OFF and remove the plug from the socket. Only pull on the plug. Do not pull the cord.  Do not bend, drag or twist the cord, or apply force to remove it. Do not operate the unit if its cable or plug are damaged;...

  • Page 5: Description Of Parts

     Do not spray insecticides, oils or paints near the appliance; doing so may damage its plastic parts or start a fire.  Keep flammable gases and oils away from the appliance! Do not move the appliance while it is operating; doing so can ...

  • Page 6: Appliance Start-Up

    PRE-OPERATING CHECKS AND OPERATIONS Before using the appliance, make sure the floater and the condensate collection tank are correctly positioned Remove the tank using both hands, following the direction of the arrow. Pull out the tank using both hands and verify the correct position of the floater. Floater Wrong Correct...

  • Page 7: Operating Precautions

    OPERATING PRECAUTIONS The appliance will only start operating if the humidity level in the room is above the set value. The dehumidifier will continue to operate until the set humidity level has been reached, with the exception of interruptions caused by a full tank. In this case, empty and reinstall the tank: the dehumidifier will now start running again.

  • Page 8: Control Panel

    CONTINUOUS CONDENSATE DRAINAGE The water can be continuously drained when using a PVC hose with an inner diameter of 14 mm (not supplied) Turn off the appliance and remove the plug before connecting the hose. Open the small side door, remove the cap and safely connect the hose to the continuous condensate discharge connection, as shown in the figures below.
  • Page 9 BUTTONS & LEDS ON/OFF BUTTON - Press this button to turn the dehumidifier on and off. FILTER BUTTON After 250 hours of operation, the FILTER RESET led turns on to indicate that it is time to clean the filter. Take the filter out and clean it. Then press the FILTER button. 1.

  • Page 10: Cleaning The Water Tank

    CLEANING AND MAINTENANCE MAINTENANCE OF THE HUMIDIFIER’S EXTERIOR SURFACE Warning Always pull the dehumidifier's plug out of the power socket before cleaning it, to prevent electric shock and malfunction. Warning Do not wet the appliance or immerse it in water, otherwise electric shocks may occur. Use a damp and soft cloth to clean the exterior surface of the dehumidifier.

  • Page 11: Troubleshooting

    TROUBLESHOOTING PROBLEM POTENTIAL CAUSE SOLUTION The dehumidifier is not working. The temperature is above 32 ° C or below 5 Empty the tank It is not possible to adjust the settings. °C. Position the tank correctly The internal tank is full. Correctly connect the plug The tank is not positioned correctly.
  • Page 12 REGULATION (EU) N. 517/2014 - F-GAS DRY COMPACT 21 The unit contains R290, a natural greenhouse gas with global warming potential (GWP) = 3 - Kg. 0.08 = 0.00024 Tons CO equiv. Do not release R290 into the atmosphere. INFORMATION FOR THE CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EUROPEAN DIRECTIVE 2012/19/EU This appliance may not be scrapped with domestic waste at the end of its life cycle.
