- Page 1 User Manual Microwave Manuel D’utilisateur Micro-onde MODEL | MODÈLE: CHM16MB, CHM16MW, CHM16MS Page 1...
- Page 2 Page 2...
-
Page 3: Table Of Contents
CONTENTS SAFETY INFORMATION Precautions to Avoid Possible Exposure to Excessive Microwave Energy ..........4 A Special Note on Arcing ..............................4 Addendum ................................. 4 Important Safety Instructions ..........................5 Grounding Instructions ............................7 Utensil Guide for the Microwave ........................8-9 SET UP & USE Specifications ................................... -
Page 4: Safety Information
SAFETY INFORMATION DANGER WARNING CAUTION DANGER - Immediate hazards WARNING - Hazards or unsafe CAUTION - Hazards or unsafe which WILL result in severe practices which COULD result in practices which COULD result in personal injury or death severe personal injury or death minor personal injury PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO... -
Page 5: Important Safety Instructions
SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS WARNING When using electrical appliances, basic safety precautions should be followed, including the following WARNING: To reduce the risk of burns, electric shock, fire, and injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 2. - Page 6 SAFETY INFORMATION 12. The contents of feeding bottles and baby food jars should be stirred or shaken and the temperature should be checked before serving in order to avoid burns. 13. Cooking utensils may become hot because of heat transferred from the heated food.
-
Page 7: Grounding Instructions
NOTE: Neither Commercial Chef nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the electrical connection procedures. -
Page 8: Utensil Guide For The Microwave
SAFETY INFORMATION UTENSIL GUIDE FOR THE MICROWAVE This section lists which utensils can be used in the microwave, which have limited use, and which should not be used in the microwave at all. CAN USE CAN NOT USE LIMITED USE •... - Page 9 SAFETY INFORMATION CAN USE CAN NOT USE LIMITED USE • Wax paper: To prevent • Aluminum tray: May • Straw, wicker, and splattering. cause arcing. Avoid wood: For short- • Thermometers: aluminum foil this may term heating, such as Only those labeled cause arcing.
-
Page 10: Set Up & Use
SET UP & USE SPECIFICATIONS • Power Consumption: 120V~60Hz, 1550W • MWO Power: 1100W • Operation Frequency: 2450MHz • Outside Dimensions (H x W x D): 12.9” x 21.8” x 19.2” • Oven Cavity Dimensions (H x W x D): 10.2” x 17” x 15.5” •... -
Page 11: Parts & Features
SET UP & USE PARTS & FEATURES Glass Tray Wave Guide Control Panel Door Safety Turntable Roller Lock System NOTE: Do not remove the mica plate covering the wave guide in the oven cavity. A. Never place the glass tray upside down. The glass tray should never be restricted. -
Page 12: Operation
SET UP & USE OPERATION 1. Power Level Ten power levels are available. Number key Level Power 100% Display PL10 2. Clock Setting When the microwave oven is plugged into an outlet, the oven will display “ 0:00 ” 1) Press “ CLOCK ”, the screen will display 00:00. The hour figure will flash; “:” and other “0”... - Page 13 SET UP & USE Example: to cook the food with 50% microwave power for 15 minutes. A. Press “ COOK TIME ” once. “00:00” displays. B. Press “1”, “5”, “0”, “0” in order. C. Press “POWER LEVEL” once, then press “5” to select 50% microwave power. D.
- Page 14 SET UP & USE 2) During cooking process, following steps must be followed: a. Keep the door closed when surplus time is not displayed or the buzzer does not sound tiwice. b. When the buzzer sounds twice, the time will count down and display the surplus time, you can open the door to mix the food up, turn over or replace the food.
- Page 15 SET UP & USE Sensor Cook Chart Food Weight/ Menu button Food Code Portion Sensor Reheat Sensor Reheat SC-1 8.0~32.0 oz Frozen Pizza Frozen Pizza SC-2 6.0~12.0 oz Frozen Entrée Frozen Entrée SC-3 8.0~32.0 oz 1~4 potatoes Potato Potato SC-4 10.0 oz each 8.0 oz ~ Rice...
- Page 16 SET UP & USE 9. SOFTEN/MELT 1) Press “ SOFTEN/MELT ” repeatedly until the menu you require appears in the display. 2) After choosing the menu, press a number pad to select the weight or portion of the food. 3) Press “ START/+30SEC ”. to cook. Auto Menu Chart: Weight/ Food...
- Page 17 SET UP & USE EXAMPLE: Save one program as memory 2. To cook the food with 80% microwave power for 3 minutes and 20 seconds. Operate the following steps: a. In waiting state, press “MEMORY” twice, “2” displays. b. Press “ COOK TIME ”, then input number keys “3”, “2”, “0” to choose the cooking time.
- Page 18 SET UP & USE 13. CHILD LOCK FUNCTION Lock: In waiting state, press “ STOP/CANCEL ” for 3 seconds, there will be a long “beep” denoting entering into the children-lock state; If the clock has been set, current time will display. Lock quitting: In locked state, press “...
- Page 19 SET UP & USE COOKING TECHNIQUES Your microwave makes cooking easier than conventional cooking, provided you keep these considerations in mind: STIRRING Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the outside of the dish absorbs more energy and heats more quickly, so stir from the outside to the center.
-
Page 20: Cleaning & Care
CLEANING & CARE 1. When cleaning surfaces of door and front face of oven, use only mild, nonabrasive soaps, or detergents and apply with a sponge or soft cloth. 2. Turn off the oven and remove the power plug from the wall socket before cleaning. 3. -
Page 21: Troubleshooting & Warranty
TROUBLESHOOTING & WARRANTY BEFORE YOU CALL FOR SERVICE IF THE OVEN FAILS TO OPERATE: A) Check to make sure that the oven is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds and plug it in again securely. B) Check for a blown circuit fuse or a tripped main circuit breaker. -
Page 22: Troubleshooting
TROUBLESHOOTING & WARRANTY TROUBLESHOOTING Troubleshoot your problem by using the chart below. If the microwave oven still does not work properly, contact W Appliance Co. customer service center or the nearest authorized service center. Customers must never troubleshoot internal components. Microwaves hold dangerous voltage (5000V) even after power is removed. -
Page 23: Limited Warranty
TROUBLESHOOTING & WARRANTY LIMITED WARRANTY Commercial Chef brand is used under license. 16. To charges occurred for after hour service, weekend, holiday charges, tolls or mileage expense Any repair, replacement, or warranty service, for service calls to remote areas. and all questions about this product should be 17. - Page 24 © 2022 Commercial Chef is a W Appliance Company. All Rights Reserved. Page 24 April 2022...
