- Page 1 Register your product and get support at www.philips.com/welcome PPX 4010 EN User Manual EN User Manual...
-
Page 2: Table Of Contents
Connecting to Devices with HDMI Output ....7 Connecting to a Computer (VGA) ........7 Connecting to an iPhone/iPad ...........8 Service ............9 Cleaning ..................9 Device Overheated .............9 FW update ................9 Troubleshooting ..............10 Appendix ..........11 Technical Data ..............11 Accessories ................11 Philips · PPX 4010... -
Page 3: Dear Customer
Dear Customer What's in the Box 1 – PicoPix Projector Thank you for purchasing our Pocket Projector. 2 – Quick Start Guide We hope you enjoy your device and its many functions! 3 – Dual USB to Micro USB cable About this User Manual 4 –... -
Page 4: General Safety Information
1 Seal this device in a plastic bag before moving it to another room, in order for it to adapt to room con- ditions. 2 Wait one to two hours before you take the device out of the plastic bag. Philips · PPX 4010... -
Page 5: Overview
2 Overview Top/rear of the Device Side View 1 – HDMI – HDMI port for a playback device (with 1 – Brightness button: allows to adjust 3 levels of brightness. adapter cable) 2 – DC IN – USB port for power supply Maximum possible brightness depends on the available ... -
Page 6: Initial Operation
0.5 meter and a max- imum of 5 meters. Make sure the projector is in a secure position. 3 Use the focus wheel on the top to adjust the image sharpness. Philips · PPX 4010... -
Page 7: Connect To The Playback Device
4 Connect to the playback device Only use the supplied cable or cables that are available Use the VGA-Audio cable (available as an accessory) to as accessories to connect the projector. connect the projector to a computer, laptop, etc.. The projector supports the following resolutions: VGA/ Supplied cables SVGA/XGA/WXGA. -
Page 8: Connecting To An Iphone/Ipad
2 Connect the Micro USB cable to the projector. 3 Connect the Dual USB cable to a suitable power source (e;g; PPA 6200). 4 Connect the Apple cable to the Iphone or Ipad. 5 Connect the HDMI cable to the Apple Digital AV Adapter. Philips · PPX 4010... -
Page 9: Service
5 Service Cleaning FW update 1 Prepare a USB key (not provided) and a Dual Female DANGER! USB adaptor (not provided, see picture). Instructions for Cleaning! 2 Before, copy the file «MSTFLASH.bin» to the root Use a soft, lint-free cloth. Never use liquid or directory of USB key. -
Page 10: Troubleshooting
• Disconnect and reconnect the USB cable to restart the projector. • Use the supplied HDMI cable (PPA1290). Third- Bad image or color quality when connecting with HDMI. party cables may cause signal distortions. Philips · PPX 4010... -
Page 11: Appendix
6 Appendix Technical Data Accessories Dimensions (L¦×¦H¦×¦W)......68 x 22 x 66 ¦mm Following accessories are available for your device: Weight ................87 g Cables available as accessories Recommended Ambient........5¦–¦35¦ºC MHL cable........(PPA1240 / 253520048) Relative Humidity ....15¦–¦85¦% (non-condensing) VGA cable........(PPA1250 / 253447070) Video connection ...... - Page 12 Other product names used herein are for complies with Industry Canada CAN ICES-3 (B)/NMB- identification purposes only and may be trademarks of 3(B) their respective owners. X-GEM SAS disclaims any and all rights in those marks. Philips · PPX 4010...
- Page 13 X- GEM SAS / PHILIPS products or X-GEM SAS / PHILIPS approved products. X-GEM SAS shall not be held liable for any damage...
- Page 14 Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. used under license. This product was brought to the market by X-GEM SAS, further referred to in this document as X-GEM SAS, and is the manufacturer of the product.
