INTRODUCTION
3.2.7 Multizone mode with combi boiler
2
Key
1 climapro thermostat "zone 1"
1
2 combi boiler
3 climapro thermostat "zone 2"
1
EN
4 connection block (not supplied)
5 Heating zone 2- 2-port valve
6 Heating zone 1- 2-port valve
7 electrical supply
8 smart Wiring center 2 control unit
9 Heating circuit zone 1
10 Heating circuit zone 2
11 Overheating safety (if underfloor heating)
- 10 -
0
8
EBUS
7
C
D
A
B
230V~
7
16A
3
EBUS
EBUS
11
8
ON OFF
DHW DHW
CH1
CYL. BUS
CH2
+
2 1
N L N L
5 6
BUS
BUS
2
16A
a boiler circuit return
B Boiler circuit flow
c cold water supply
D Domestic hot water outlet
1
5
3
6
NTC
- 1
2
4
BUS
1
0020140826_00 - 08/12 - Glow-worm
9
10
