Summary of Contents for MAJORITY Robinson 2DAB
- Page 1 R obin son 2DAB DAB+ Adapter Instructions Guide...
-
Page 2: Table Of Contents
Hints and Tips ..................24 Hints and Tips ........................... 24 Speci cations and Warranty ............26 Speci cation ..........................26 Support ............................28 Warranty ............................. 28 Safety Information .................29 Register your product online for a FREE 3 YEAR year extended warranty at: WARRANTY www.majority.co.uk... -
Page 3: Controls And Functions
Controls And Functions Front view 1. DISPLAY 2. q Button 3. REMOTE CONTROL SENSOR Rear view 4. DC IN SOCKET 5. LINE OUT SOCKET (RCA Jack) 6. OPTICAL OUT CONNECTION 7. ANTENNA... -
Page 4: Remote Control
Controls And Functions Remote control 1. STANDBY Button 2. SLEEP Button 3. CLOCK Button 4. DAB Button 5. FM Button 6. MODE Button 7. 12 w Button 8. 7 Button 9. SELECT Button 10. EQ Button 11. VOLUME + / – Buttons 12. -
Page 5: What's In The Box
What's In the Box? Box Contents Main Unit Instruction Manual ANTENNA Mains Adapter Remote... -
Page 6: Instructions Guide
Instructions Guide BATTERY REPLACEMENT FOR THE REMOTE CONTROL 1. Press down the battery cover at “ ” and push the battery cover outwards in the direction of the arrow. 2. Insert 2 x AAA 1.5V alkaline batteries (not included). Make sure to match the (+) and ( - ) ends of the battery with the (+) and ( - ) ends indicated in the battery compartment. -
Page 7: Remote Control Operation Range
Instructions Guide REMOTE CONTROL OPERATION RANGE The remote control sensor on the front unit is sensitive to the remote control’s commands up to a maximum of 4 metres away and within a maximum of 60° arc. Note that the operating distance may vary depending on the brightness of the room. -
Page 8: Getting Started
Instructions Guide GETTING STARTED This instruction manual explains the basic instruction for operating this unit. Unless otherwise stated, all operations described are based on remote control use. Powering ON/OFF 1. Press q STANDBY button on unit or remote control to switch the unit 2. - Page 9 Instructions Guide Turning ON/OFF the BestTuneTM 1. Press MENU button to access menu. 2. Press w / s buttons to select System Settings, and then press SELECT button to con rm. 3. Press w / s buttons to select BestTune, and then press SELECT button to con rm.
-
Page 10: Besttune Mode Operation
Instructions Guide BESTTUNE MODE OPERATION To switch the unit to BestTune mode, press MODE button repeatedly. When turning on unit for the rst time, or you have just performed a factory reset, the unit will automatically enter into BestTune mode and perform initial scan. - Page 11 Instructions Guide Station Information (Info.) The Station Information will show further information that is being broadcast. 1. To view Station Information, press INFO button. 2. The following information will be shown on display: Service Station service title Sources Source (DAB+ / FM) that is being broadcast If more than one source is available: 1.
- Page 12 Instructions Guide Presetting Stations You can access your favorite stations quickly and easily by storing up to 30 stations into Preset Station List. Storing Preset Station 1. Listen to the station that you would like to store into Preset Station List. 2.
-
Page 13: Dab+ Mode Operation
Instructions Guide DAB+ MODE OPERATION To switch the unit to DAB+ mode, press MODE button repeatedly. When you switch to DAB+ mode for the rst time, the unit will automatically perform initial scan. While scanning, the display will show “Scanning...” and a progress bar which indicates the scan progress and the amount of found stations. - Page 14 Instructions Guide Station Information (Info.) The Station Information will show further information that is being broadcast. 1. To view Station Information, press INFO button. 2. The following information will be shown on display: Service Station service title Sources Source that is being broadcast (“DAB” .displayed for DAB source) Programme type that is being broadcast Freq...
-
Page 15: Fm Mode Operation
Instructions Guide Presetting Stations Please refer to the “Presetting Stations” in BestTune operation section. Preset Station Lists are independent under BestTune, DAB and FM mode. You can only access DAB Preset Station List under DAB mode. Please switch to BestTune mode if you want to access BestTune Preset Station List;... - Page 16 Instructions Guide Station Information (Info.) The Station Information will show further information that is being broadcast. To view further information broadcast by the station, press INFO button, the display will show the following information: Service Station service title This describes the programme type that is being broadcast.
-
Page 17: Bluetooth Audio Mode Operation
“Please connect the device with: Majority Robinson 2DAB”. 3. Activate your Bluetooth device and select the search mode. 4. “Majority Robinson 2DAB” will appear on your Bluetooth device list. 5. Select “Majority Robinson 2DAB” and enter “0000” for the password if necessary. -
Page 18: Alarm And Snooze
Instructions Guide 6. When playback a soundtrack, press 12 button to pause the playback, and press 12 button again to resume playback. 7. Press 7 button to skip backward to the beginning of the track, or press and hold 7 button to skip backward to previous track. 8. - Page 19 Instructions Guide 3. Press w / s buttons to select, then press SELECT button to con rm the following parameters: Alarm Alarm On / O Frequency Daily / Once / Weekends / Weekdays Wake Up time (Alarm On time) Source When BestTune turn ON: Buzzer / DAB+ / FM When BestTune turn OFF: Buzzer / DAB/FM Duration...
-
Page 20: System Settings
Instructions Guide SLEEP SETTING This function allows you to program the unit to turn to standby mode by itself after a set period of time. 1. To activate Sleep function, press SLEEP button repeatedly. The sleep time will change in below sequence: ... - Page 21 Instructions Guide 3. For My EQ, please go to My EQ Setup for custom setting before use. 4. During My EQ Setup, press w / s buttons to select [Treble/Bass], and then press SELECT button to con rm. Press w / s buttons to select desired level, and then press SELECT button to con rm selection.
- Page 22 Instructions Guide Language 1. During System Settings, press w / s buttons to select Language, and then press SELECT button to con rm. 2. Press w / s buttons to select your preferred language, then press SELECT button to con rm selection. Factory Reset There may be times when you need to reset your unit back to the factory settings especially when you have moved house.
-
Page 23: Maintenance
Instructions Guide Maintenance Cleaning the Unit Ensure the unit is fully unplugged from the mains socket before cleaning. ● To clean the unit, wipe the case with a slightly moist, lint-free cloth. ● Do not use any cleaning uids containing alcohol, ammonia or abrasives. -
Page 24: Hints And Tips
Hints and Tips Hints and Tips If a problem does occur, it may often be due to something very minor. The following table contains troubleshooting. General Problem Solution ● Ensure the mains adaptor plug is connected. No power. ● Make sure that you select the ON mode. No sound from the unit. - Page 25 Hints and Tips Bluetooth Problem Solution ● Ensure the Bluetooth function is activated I cannot nd“Majority Robinson 2DAB” on your Bluetooth device. ● Re-pair the unit with your Bluetooth device. on my Bluetooth device. ● You may need to increase the volume on Can’t hear the music...
-
Page 26: Speci Cations And Warranty
Speci cations and Warranty Speci cation Brand Majority Model Robinson 2DAB System Section Power Supply Input: 100-240V ~ 50-60Hz 0.2A max. Output: 5.9V/1.0A Power Consumption 5.9 W Working Environment - 0 ~ 35 °C Temperature Net Weight Main unit: app. 185g Adapter: app. - Page 27 Speci cations and Warranty Power Adapter information Manufacturer’s name and address: DONGGUAN DONGNIU ELECTRONIC TECHNOLOGY CO.,LTD 3th oor, NO.8, HengLing Street, HengJiao Industrial Park, ShiJie Town, Dongguan City, Guangdong,P.R. China Model Number: DNS051-0591000-AV (EU VDE Plug) DNS051-0591000-AB (UK BS Plug) Input Voltage and Frequency: 100-240V ~ 50-60Hz 0.2A max.
-
Page 28: Support
Warranty All products come with a standard 12 month warranty. All items must be registered on www.majority.co.uk for the warranty to be valid. Once on the web page, use the menu to nd “Register Your Product”. You will also be given the chance to extend your warranty for an additional 24... -
Page 29: Safety Information
Safety Information Read all the instructions carefully before using the unit and keep them for future reference. Check that the voltage marked on the rating label matches your mains voltage. The unit must be placed on a at stable surface and should not be subjected to vibrations. - Page 30 Safety Information C AU TION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the unit’s enclosure that may be of su cient magnitude to constitute a risk of electric shock.
- Page 31 Under the environment with radio-frequency disturbance, the product may malfunction and could self-recover when the interference disappear. Keep these instructions. Instructions are all available for download at www.majority.co.uk IMPORTANT: Please read all instructions carefully before use and keep for future reference...
- Page 32 EU RP: AR Experts, P.O. Box 5047, 3620 AA Breukelen, The Netherlands US: lzilla Ltd, C/0 A.N. Deringer, Inc., 19520 Wilmington Ave, Rancho Dominguez, CA, 90220 Majority is owned and operated by iZilla Ltd. Registered in England with Company No: 08520738...
