R O B I N S O N
I N T E R N E T R A D I O A D A P T E R
ROB-ADT-BLK
Instructions Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Robinson ROB-ADT-BLK and is the answer not in the manual?

Questions and answers

Summary of Contents for MAJORITY Robinson ROB-ADT-BLK

  • Page 1 R O B I N S O N I N T E R N E T R A D I O A D A P T E R ROB-ADT-BLK Instructions Guide...
  • Page 2: Table Of Contents

    Contents What’s in the Box? Controls and Functions  Support  Instructions Guide  Basic Operation �������������������������������������������������������� Internet Radio ���������������������������������������������������������� Media Centre ����������������������������������������������������������� FM Radio ������������������������������������������������������������������ DAB/DAB+ Radio ����������������������������������������������������� Spotify Connect (Only in applicable models) ����������� Information Centre �������������������������������������������������� Bluetooth ���������������������������������������������������������������� Connections �������������������������������������������������������������...
  • Page 3: What's In The Box

    What’s in the Box? Box Contents 1. Majority Robinson Adapter 2. Remote Control 3. Telescopic Antenna 4. RCA Audio Cable 5. Power Adapter 6. Instructions Guide...
  • Page 4: Controls And Functions

    Controls and Functions Front View...
  • Page 5 Controls and Functions Back View OPTICAL OUT LINE OUT DC IN 1. Power button 2. Antenna port 3. DC IN power port 4. Line Out port 5. Optical Out port...
  • Page 6 Controls and Functions Remote Control Mode Home Preset Snooze...
  • Page 7 Controls and Functions 1. Power On/Standby 13. Mute button Switch the unit between on and Select to mute and unmute sound Standby mode track in CD mode. 14. Vol + 2. Up button Increase volume Navigate up 3. Left button 15.
  • Page 8: Support

    Support Support Thank you for your purchase of the Majority Robinson radio adapter. Please follow the guidance of the manual to set up your new purchase and begin enjoying its features. If you require further assistance with your new radio, please contact our support team on the Majority website: https://www.majorityonline.co.uk/support...
  • Page 9: Instructions Guide

    ‘DC in’ (Ref.3) and turn the power on from the mains. Press the Power button (Ref.1) at the back of the adapter to switch on and to display ‘MAJORITY’ on the screen. After the welcome screen, you will be able to select your chosen language with the remote control.
  • Page 10 Instructions Guide Manual WiFi Set-up If you select YES, you will be able to select your chosen WiFi network and enter the WiFi password in the next display screen. Type letters/numbers by scrolling with the remote until the correct digit is displayed and click ‘>’ to go to the next digit (Rem.15).
  • Page 11 Instructions Guide WiFi Connection Complete! Once your WiFi is connected by manually entering your WiFi password or via WPS, you will be taken to the main menu screen and the WiFi signal will appear in white at the top left. Your internet radio adapter is now set up!
  • Page 12: Internet Radio

    Instructions Guide Internet Radio Go to the main menu screen by selecting ‘Home’ (Rem.7) and select ‘Internet Radio’ on the display screen using the ‘<’ and ‘>’ buttons on the remote (Rem.3/15) and select with the ‘OK’ button (Rem.4). When on the ‘Internet Radio’ screen, there will be multiple options to scroll through: My Favourite: Your favourite stations will be saved here for easy listening.
  • Page 13 Instructions Guide Service: Search for an internet radio station or add a new station. To search a new station, select ‘Search Radio Station’ to go to the search tool. Type letters/numbers by scrolling with the remote until the correct digit is displayed and click ‘>’ to go to the next digit (Rem.15).
  • Page 14: Media Centre

    Instructions Guide Media Centre Go to the main menu screen by selecting ‘Home’ (Rem.7) and select ‘Media Centre’ on the display screen using the ‘<’ and ‘>’ buttons on the remote (Rem.3/15) and select with the ‘OK’ button (Rem.4). UPnP: Universal Plug and Play allows you to connect to other devices to play your music such as personal computers (Windows media player), mobile (GooglePlay) and other devices.
  • Page 15 Instructions Guide My Playlist: You can create a playlist of favourite music or media from UPnP. When you are playing the media, press the ‘OK’ button on the remote control (Rem.4) to save it into My Playlist. Access ‘My Playlist’ from the Media Centre. Clear My Playlist: If you have created a playlist via UPnP connection, you can select this option to clear the playlist.
  • Page 16: Fm Radio

    Instructions Guide FM Radio Select ‘FM mode’ on the main display screen with the Home button (Rem.7). Once selected, the FM mode will start on 87.50MHz. Please ensure that the antenna is connected into the back of the adapter (Ref.2) and the antenna extended. Press down the OK button on the remote (Rem.4) and the screen will display “Auto Scan?”.
  • Page 17 Instructions Guide Recalling your favourite FM stations View your favourite FM stations when you are on FM mode by selecting the Preset button (Rem.17). Do not hold down the button as this will open Preset Store settings. Use the navigation buttons on the remote to scroll through the presets available and select the station to play by pressing the OK button (Rem.4).
  • Page 18: Dab/Dab+ Radio

    Instructions Guide DAB/DAB+ Radio Select ‘DAB/DAB+’ on the main display screen by browsing with the navigation buttons on the remote and select by pressing down the ‘OK’ button (Rem.4). Please ensure that the antenna is connected into the back of the radio (Ref.2) and the antenna extended.
  • Page 19 Instructions Guide Pre-setting your favourite DAB/DAB+ stations When you have found your desired station to save as a preset, press and hold the ‘Preset’ button on the remote (Rem.17) for 2-3 seconds to open the ‘Add to my Favourites’ screen. Use the navigation buttons on the remote to go to the preset number you wish to save to and select the preset number by pressing the OK button (Rem.4).
  • Page 20: Spotify Connect (Only In Applicable Models)

    Please note that this is only applicable in particular models. Listen out loud with Spotify Connect 1. Connect your Majority Robinson to your WiFi network. 2. Open up the Spotify app on your phone, tablet or laptop using the same WiFi network.
  • Page 21: Information Centre

    Instructions Guide Information Centre Select ‘Information Centre’ on the main display screen by using the remote navigation buttons and the OK button (Rem.4). Weather Information: To select the weather information for a desired place, first select the continent by using the navigation buttons and OK button.
  • Page 22: Bluetooth

    Go to your device settings to connect your device to the adapter via Bluetooth. The device will display as ‘Majority Robinson’ in your device’s Bluetooth settings. Select this from your phone to connect and the adapter will show as “Connected”.
  • Page 23: Connections

    Instructions Guide Connections Line Out Port At the back of the adapter, the ‘Line Out’ (Ref.4) port allows for an external amplifier/stereo speaker to be connected. Simply connect the supplied RCA audio cable or an AUX cable (not supplied) from the ‘Line Out’ port to the amplifier/stereo. Begin playing audio from the Internet radio, DAB/DAB+ and FM radio, Media Centre, Spotify, or Bluetooth setting.
  • Page 24: Configuration Settings

    Instructions Guide Configuration Settings Select ‘Configuration’ on the main display screen to browse through a range of display, performance and audio settings. Network Select this for WiFi and network options Wireless Network Configuration On the Network settings, you can set up a Wi-Fi connection by selecting Wireless Network Configuration.
  • Page 25 Instructions Guide Settings: Date & Time Manually setting date and time There is the option to manually set the time and date instead of using auto-detect to set this up. Go to ‘Configuration’ settings and select ‘Date&Time’ by scrolling and selecting with the navigation buttons and confirm selection with the OK button (Rem.4).
  • Page 26 Instructions Guide Settings: Alarm Clock Setting Alarm 1/Alarm 2 To set an alarm on your radio, go to ‘Configuration’ settings and scroll through to select the ‘Alarm’ option with the navigation buttons. Alternatively, press the ‘Alarm’ button on the remote (Rem.9) After opening ‘Alarm’...
  • Page 27 Instructions Guide Settings: Alarm Features 00:00 Everyday Once 00:00 00:00 00:00 00:00 Alarm 1 (Turn O ) Turn On Repeat: Everyday Time Turn O Alarm 2 (turn O ) Time: 00:00 NAP Alarm (Turn O ) Sound: Melody 00 : 00 HH : MM Alarm Volume Input...
  • Page 28 Instructions Guide How to put your alarm on snooze When your alarm is sounding, press the ‘Snooze’ button on the remote (Rem.21) to stop the sound and put into Snooze mode. The Snooze function will make the radio sound again in 5 minutes.
  • Page 29: Settings: Additional Features

    Instructions Guide Settings: Additional Features The following options are available in Configuration settings: Timer In ‘Configuration’ settings, select the option for ‘Timer’ and a screen with 00:00 will display. To go up in seconds, click the ‘>’ button (Rem.15). To go down in seconds, click the ‘<’...
  • Page 30 Instructions Guide Software Update Will show here if a software update is available for the adapter. If one is available, please select for the update to initiate. Reset to default Select this option to reset your adapter and revert all of the settings and presets made.
  • Page 31: Remote Control App

    Once the app is downloaded, open the app and ensure that your adapter is switched on and out of standby mode. The app should then automatically connect to your Majority adapter, once selected via the app. You can now begin adjusting settings...
  • Page 32 Instructions Guide Additional Setting Options Time display - Select Analog or Digital Language - Select your chosen language within the list Display - Choose the display to be Colour or Monochrome Power management - Select this to configure the radio to go into standby mode automatically after a set time of inactivity or if there is no WiFi signal.
  • Page 33: Troubleshooting

    Bluetooth not connecting Ensure that you are on Bluetooth mode on the radio and the Bluetooth on your device is switched on. Select the Bluetooth device ‘Majority Robinson’ and you should now be able to play audio. Radio is not allowing me to select a...
  • Page 34: Specifications

    Specifications Specifications DC 5.9V 1.2A (output) Power Supply Internet Radio: MediaU FM: 87.5MHz - 108 MHz DAB: 174 - 240 MHz Mode: Bluetooth 3.5mm Line-Out Optical Out Network 802.11b / g / n (WLAN) Encryption: WEP, WPA, WPA 2 (PSK), WPS Dimensions 11.5 x 8.7 x 5.2 cm Warranty...
  • Page 35: Safety Information

    Safety Information ADDITIONAL WARNINGS 1. Read these instructions. 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.majorityonline.co.uk splashing and no objects filled with liquid, such as 3. Heed all Warnings vases, shall be places on the apparatus.
  • Page 37 www.majorityonline.co.uk...
