VSPL viraj SECURE FIRST SF-RFA-20R Instruction Manual page 2

The fall arrester must be connected with a connector conforms to EN362 to an Anchor
device, conforms to EN 795 and
CALCULATION OF WORKING HEIGHT
Arrest
Max height
Model
of person (mtr)
Distance (mtr)
SF-RFA-20R 2
The recommended service life of the equipment is 10 years (in accordance with the annual examination by a competent person
authorized by (VIRAJ SAFETY), but it may be increased or reduced according to use and/or the results of the annual
inspections. The equipment should be inspected if there is any doubt, or following a fall and at least annually, by the
manufacturer or a competent person authorised by the manufacturer to check its strength and hence the user's safety. The
product data sheet should be completed after each annual product verification.
Under the Feet of User with a mass of 100 kg.
Total = Fall Arrest Distance+person
Additional Safety
Clearance (mtr) height (max 2Mtr)+safety clearance
2 1
40°
5
40°
max 40°
5
2
