VSPL VIRAJ SECURE FIRST SF-COMBO-ELA-1094 User Instructions

Applicable to Full Body Harness
Manufacturer
Certification Body
The Full Body Harness SF-COMBO-ELA-1094 is classed as a Personal Protective Equipment (PPE) by the European Regulation 2016/425 and has been shown to
comply with this Regulation through the Harmonized European Standard BS EN 361:2002 & EN 358:2018.
This Harness is designed to minimise the risk of/provide protection against the danger of falling from heights. However, always remember that no item of PPE can provide
full protection and care must always be taken while carrying out the risk relation activity. EU declaration of conformity can be accessed on www.vsplgroup.com
This Harness has been tested in accordance with EN 361 : 2002 and has achieved the following performance levels :
EN 361:2002 test
Clause 4.1 Design and
ergonomics
Clause 4.2 Material
1. Harness should be the personal property of its user.
2. The strength of the anchor device should conform according to EN 795 Type B (Min strength 12 KN).
3. It should not be used in highly acid or basic environments.
4. Protect the harness from mechanical hazards like sharp edges, tools, exposure to sunlight, ultraviolet degradation both during usage, transportation and storage.
5. The user should carefully read the clearing on the energy absorber.
Follow Step 1 to Step 6 to wear the harness. Both leg straps as well as shoulder straps are adjustable to fit the size of the user. A harness either too loose or too tight will
restrict movement and will not provide the optimum level of protection. The size of the harness is marked on a label attached to it and it is universal.
Visually inspect the harness before use to ensure that it is in a serviceable condition and operates correctly.
Step 1 : Hold the harness by the dorsal D-Ring as shown in figure 1, marked as 'A' on the label. Use this as an attachment element for connectors, lanyards, energy absorber etc.
Step 2 : Insert your arms into the shoulder straps (left arm into the left shoulder strap, right arm into the right shoulder strap) and close the metallic buckles on the chest
strap as shown in Figure 2.
Step 3 : The harness is now on the body with two leg straps hanging down at the back. Pull the leg straps one by one around your thighs outwards to your front, as shown
in figure 3.
Step 4 : Close the adjustable buckles of the leg strap one by one as shown in figure 5. (figure 4 shows how to close the
Step 5 : Tighten the leg straps by pulling the free ends of the straps as shown in figure 6 until the harness fits marked with A the body tightly without hindering free movement.
Step 6 : Now depending upon the condition of usage, use the front textile loops together, marked with A/2 or the dorsal metallic D-Ring marked with 'A' or both as point of
attachment of Fall Arrest Systems.
Fig. 1
USER INSTRUCTIONS
: SF-COMBO-ELA-1094
: VIRAJ SYNTEX PVT. LTD., Factory / Office : C-36, UPSIDC Industrial Area, Rooma, Kanpur - 209402 (UP) INDIA
:
Ph. +91 9839505969, 9839803488, 9839811500, 9839601191
: GEPTESZT Kft. - Budapest Gyenes u. 12. 1032, Hungary,
IDENTIFICATION NO. CE
CAREFULLY READ THESE INSTRUCTIONS BEFORE USING THIS HARNESS

PERFORMANCE AND LIMITATIONS OF USE

Considered to be sufficiently light and likely to remain in place during use without becoming incorrectly adjusted without
the wearer's knowledge. (PASS)
Material type specified on label as Polyester - application of naked flame to webbing and thread resulted in melting
consistent with synthetic material (PASS)
Different Colour webbing used for differentiating shoulders and leg straps, stitched with white thread (PASS)
Straps present in pelvic and shoulder areas (PASS)
Primary straps : 44 mm. Secondary straps : 44 mm. (PASS)
The breaking tenacity of webbing and yarns, the requirement is at least 0.6 N/tex (PASS)
Fig. 2 Fig. 3
Result/Comment

LIMITATIONS :

FITTING & SIZING :
Fig. 4
SF-COMBO-ELA-1094
TM
Web : www.vsplgroup.com , E-mail :
Contact No:- +36 1250 3531
adjustable buckles)
Fig. 5
