INSTALLATION/OPERATING MANUAL
WITH PARTS LISTING AND TROUBLESHOOTING GUIDE
For your family's comfort, safety, and convenience, we
recommend this water heater be installed and serviced by a
plumbing professional.
INDIRECT-FIRED
WATER HEATER
WARNING
To avoid damage or injury, there
must be no materials stored
against the indirect water heater
and proper care shall be taken
to avoid unnecessary contact
(especially by children) with the
indirect water heater.
• DO NOT store or use
gasoline or other flammable
liquids in the vicinity of this
water heater or any other
appliance.
238-43480-00L REV 8/20
