AutomationDirect CLICK PLUS C2-03CPU-2 Quick Start Manual

Shown with optional C2-FILL
slot cover (sold separately)
CLICK PLUS C2-03CPU(-x)
The CLICK PLUS C2-03CPU and C2-03CPU-2
have the most connectivity options in our CLICK
PLUS CPU family. They offer both Wi-Fi
and Bluetooth connection for simple wireless
provisioning and connectivity with the CLICK
Mobile app. With both RS-232 and RS-485 ports,
you can connect multiple serial devices. The RJ-45
Ethernet port allows for a separate (secondary)
network connection apart from the Wi-Fi network.
Key Features
ƒ
Real Time Clock/Calendar
ƒ
Battery backup (battery sold separately)
ƒ
RS-232 port
ƒ
RS-485 port
ƒ microB USB port
ƒ microSD Card slot
ƒ
RJ-45 Ethernet
ƒ
WLAN
ƒ
Bluetooth
Copyright© 2021, Automationdirect.com Incorporated/All Rights Reserved Worldwide
C2-03CPU Series Quick Start Guide
Before You Begin...
This guide provides a quick overview of installation and setup of your
CLICK PLUS CPU. It assumes some familiarity with the installation
and operation of industrial control equipment.
Please read and understand the information in this guide prior to
installation, operation, or servicing this equipment.
The CLICK PLUS User Manual provides full specifications and more
in-depth information on installation, setup,
programming and operation of the device. The
User Manual (C2-USER-M) is available in PDF
format by scanning this QR code or from https://
www.automationdirect.com/pn/doc/manual/
C2-USER-M. Extensive online help is also
available from within the CLICK software or at
https://www.automationdirect.com/clickplcs/free-software/
software-help.
What You'll Need
ƒ CLICK PLUS CPU
ƒ
PC, or Android or iOS mobile device (for setup/provisioning)
ƒ
Click Software ver. 3.20 or later (PC) or Click App (mobile device)
ƒ
24VDC power supply (SELV and Limited Energy)
(CLICK power supply C0-00AC or C0-01AC is recommended.)
ƒ
Appropriate enclosure with vertical surface for DIN rail or surface mount
ƒ
M4 screws, spring washers and flat washers if surface mounting
ƒ
Ferrules and crimping tool for wire terminations (recommended)
ƒ Option Slot cover(s) (part #C2-FILL) are recommended if you are not
planning to use an Option Slot module. (Sold separately.)
ƒ
Basic tools (screwdriver, wire stripper, etc.)
PLEASE REVIEW THE SAFETY WARNINGS ON THE
NEXT PAGE!
